MSI Sword 17 HX B14VFKG-084XPL

Sword 17 HX B14VFKG-084XPL

Model Sword 17 HX B14VFKG-084XPLPart no. B14VFKG-084XPLEAN 4711377218191

101 specifications Checked today

Display43.2 cm (17")
Resolution2560 x 1600 pixels
ProcessorIntel® Core™ i7
Memory16 GB
Storage1 TB
GraphicsNVIDIA GeForce RTX 4060

See all specifications

Overview

Display: 43.2 cm (17")
Resolution: 2560 x 1600 pixels
Processor: Intel® Core™ i7
Memory: 16 GB
Storage: 1 TB
Graphics: NVIDIA GeForce RTX 4060

Brand: MSI
Category: Laptop
Model: Sword 17 HX B14VFKG-084XPL
Part number: B14VFKG-084XPL
EAN / UPC: 4711377218191
Also known as: MSI Sword 17 HX B14VFKG-084XPL Intel® Core™ i7 i7-14700HX Laptop 43.2 cm (17") Quad HD+ 16 GB DDR5-SDRAM 1 TB SSD NVIDIA GeForce RTX 4060 Wi-Fi 6E (802.11ax) Gr

Specifications

101 specifications in 18 groups

Design

Specification	Value
Product type	Laptop
Product colour	Grey
Colour name	Cosmos Gray
Form factor	Clamshell
Market positioning	Gaming

Display

Specification	Value
Display diagonal	43.2 cm (17")
Display resolution	2560 x 1600 pixels
HD type	Quad HD+
Panel type	IPS
Native aspect ratio	16:10
Colour gamut	100%
RGB colour space	DCI-P3
Maximum refresh rate	240 Hz

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Core™ i7
Processor generation	Intel® Core™ i7 (14th gen)
Processor model	i7-14700HX
Processor cores	20
Processor threads	28
Processor frequency	5.5 GHz
Performance cores	8
Efficient cores	12
Performance-core Max Turbo Frequency	5.5 GHz
Efficient-core Max Turbo Frequency	3.9 GHz
Performance-core base frequency	2.1 GHz
Efficient-core base frequency	1.5 GHz
Processor cache	33 MB
Processor cache type	Smart Cache
Maximum turbo power	157 W
Processor base power	55 W

Memory

Specification	Value
Internal memory	16 GB
Internal memory type	DDR5-SDRAM
Memory layout (slots x size)	2 x 8 GB
Memory slots	2x SO-DIMM
Maximum internal memory	96 GB
Memory data transfer rate	5600 MT/s

Storage

Specification	Value
Total storage capacity	1 TB
Storage media	SSD
Total SSDs capacity	1 TB
SSD capacity	1 TB
NVMe	Yes
SSD interface	PCI Express 4.0, PCI Express 5.0
SSD form factor	M.2

Graphics

Specification	Value
On-board graphics card	Yes
Discrete graphics card	Yes
Discrete GPU manufacturer	NVIDIA
Discrete graphics card model	NVIDIA GeForce RTX 4060
Discrete graphics card memory	8 GB
Discrete graphics memory type	GDDR6
On-board GPU manufacturer	Intel
On-board graphics card family	Intel Arc Graphics

Audio

Specification	Value
Audio chip	Nahimic
Audio system	Hi-Res Audio
Number of built-in speakers	2
Speaker power	2 W
Built-in subwoofer	Yes

Camera

Specification	Value
Front camera	Yes
Front camera HD type	HD
Video capturing speed	30 fps

Network

Specification	Value
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
Wi-Fi standards	Wi-Fi 6E (802.11ax)
WLAN controller manufacturer	Intel
Ethernet LAN	Yes
Ethernet LAN data rates	1000 Mbit/s
Bluetooth	Yes
Bluetooth version	5.3

Ports & interfaces

Specification	Value
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	1
HDMI ports quantity	1
HDMI version	2.1
DisplayPorts quantity	1
Headphone outputs	1
Combo headphone/mic port	Yes
Microphone in	Yes

Performance

Specification	Value
Motherboard chipset	Intel HM770

Keyboard

Specification	Value
Pointing device	Touchpad
Keyboard backlit	Yes
Numeric keypad	No
Keyboard backlit colour	RGB
Keyboard backlit zone	24-zone RGB
Copilot key	Yes

Software

Specification	Value
Operating system installed	No

Battery

Specification	Value
Number of battery cells	4
Battery capacity	4200 mAh
Battery capacity	65 Wh

Power

Specification	Value
AC adapter power	200 W
USB Power Delivery (USB PD)	Yes

Security

Specification	Value
Cable lock slot	Yes
Cable lock slot type	Kensington
Face recognition	Yes
Trusted Platform Module (TPM)	Yes
Trusted Platform Module (TPM) version	2.0

Weight & dimensions

Specification	Value
Weight	2.6 kg
Width	383.2 mm
Depth	279.9 mm
Height (front)	2.22 cm
Height (rear)	2.73 cm

Other features

Specification	Value
USB Power Delivery revision	3.0
Warranty period	2 year(s)
