MSI Creator A16 AI+ A3HVGG 233US

Creator A16 AI+ A3HVGG 233US

Model Creator A16 AI+ A3HVGG 233USPart no. CREATOR A16 AI+ A3HVGG-233USEAN 824142388112

99 specifications Checked today

Display40.6 cm (16")
Resolution2560 x 1600 pixels
ProcessorAMD Ryzen AI 9 HX
Memory32 GB
Storage1 TB
GraphicsNVIDIA GeForce RTX 4070

See all specifications

Overview

Display: 40.6 cm (16")
Resolution: 2560 x 1600 pixels
Processor: AMD Ryzen AI 9 HX
Memory: 32 GB
Storage: 1 TB
Graphics: NVIDIA GeForce RTX 4070

Brand: MSI
Category: Laptop
Model: Creator A16 AI+ A3HVGG 233US
Part number: CREATOR A16 AI+ A3HVGG-233US
EAN / UPC: 824142388112
Also known as: MSI Creator A16 AI+ A3HVGG 233US AMD Ryzen AI 9 HX 365 Laptop 40.6 cm (16") Quad HD+ 32 GB LPDDR5x-SDRAM 1 TB SSD NVIDIA GeForce RTX 4070 Wi-Fi 7 (802.11be) Win

Specifications

99 specifications in 18 groups

Design

Specification	Value
Product type	Laptop
Product colour	Grey
Colour name	Lunar Gray
Form factor	Clamshell
Housing material	Metal, Plastic
Original brand name	MSI

Display

Specification	Value
Display diagonal	40.6 cm (16")
Display resolution	2560 x 1600 pixels
Touchscreen	No
HD type	Quad HD+
Panel type	OLED
Native aspect ratio	16:10
Colour gamut	100%
RGB colour space	DCI-P3
Maximum refresh rate	240 Hz

Processor

Specification	Value
Processor manufacturer	AMD
Processor family	AMD Ryzen AI 9 HX
Processor model	365
Processor cores	10
Processor threads	20
Processor boost frequency	5 GHz
Processor frequency	2 GHz
Processor cache	24 MB
Processor cache type	L3

Neural processor unit (NPU)

Specification	Value
Neural processor unit (NPU)	AMD Ryzen AI
Total processor performance up to	73 TOPs
NPU performance up to	50 TOPs

Memory

Specification	Value
Internal memory	32 GB
Internal memory type	LPDDR5x-SDRAM
Memory clock speed	7500 MHz
Memory form factor	On-board
Maximum internal memory	32 GB

Storage

Specification	Value
Total storage capacity	1 TB
Storage media	SSD
Total SSDs capacity	1 TB
Number of SSDs installed	1
SSD capacity	1 TB
NVMe	Yes
SSD interface	PCI Express 4.0
Optical drive type	No

Graphics

Specification	Value
On-board graphics card	Yes
Discrete graphics card	Yes
Discrete GPU manufacturer	NVIDIA
Discrete graphics card model	NVIDIA GeForce RTX 4070
Discrete graphics card memory	8 GB
Discrete graphics memory type	GDDR6
On-board GPU manufacturer	AMD
On-board graphics card family	AMD Radeon
On-board graphics card model	AMD Radeon 890M

Audio

Specification	Value
Audio system	Nahimic 3
Number of built-in speakers	2
Speaker power	4 W
Built-in subwoofer	Yes
Built-in microphone	Yes

Camera

Specification	Value
Front camera	Yes
Front camera HD type	Full HD
Front camera resolution	1920 x 1080 pixels
Video capturing speed	30 fps
Infrared (IR) camera	Yes
Privacy camera	Yes
Privacy type	Privacy shutter

Network

Specification	Value
Mobile network connection	No
Top Wi-Fi standard	Wi-Fi 7 (802.11be)
Wi-Fi standards	Wi-Fi 7 (802.11be)
WLAN controller manufacturer	Qualcomm
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Bluetooth	Yes
Bluetooth version	5.4

Ports & interfaces

Specification	Value
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	2
Ethernet LAN (RJ-45) ports	1
HDMI ports quantity	1
HDMI version	2.1
Thunderbolt 4 ports quantity	1
Intel® Thunderbolt 4	Yes
Combo headphone/mic port	Yes
USB Type-C DisplayPort Alternate Mode	Yes

Keyboard

Specification	Value
Pointing device	Touchpad
Keyboard backlit	Yes
Numeric keypad	Yes
Keyboard backlit colour	RGB

Software

Specification	Value
Operating system installed	Windows 11 Home
Bundled software	Nvidia GeForce Experience, True Color, Mystic Light, Ambient Link, Battery Master, MSI Center, DTS Audio Processing, Discrete Graphics Mode, Ambient Silent AI, Smart Auto, MSI AI Engine, Nvidia Omniverse, AMD Radeon Software, Microsoft Effect Pack (MEP)

Battery

Specification	Value
Number of battery cells	4
Battery capacity	99.9 Wh

Power

Specification	Value
AC adapter power	240 W

Security

Specification	Value
Cable lock slot	Yes
Cable lock slot type	Kensington
Fingerprint reader	Yes
Trusted Platform Module (TPM)	Yes
Trusted Platform Module (TPM) version	2.0

Weight & dimensions

Specification	Value
Weight	2.1 kg
Width	355.8 mm
Depth	259.7 mm
Height	19.9 mm

Other features

Specification	Value
Warranty period	1 year(s)
