Lenovo Yoga 9 2-in-1 14ILL10 Copilot+ PC

Yoga 9 2-in-1 14ILL10 Copilot+ PC

Model Yoga 9 2-in-1 14ILL10 Copilot+ PCPart no. 83LC006YMBEAN 198156890832

122 specifications Checked today

Display35.6 cm (14")
Resolution3840 x 2400 pixels
ProcessorIntel Core Ultra 7
Memory32 GB
Storage1 TB
GraphicsNot available

See all specifications

Overview

Display: 35.6 cm (14")
Resolution: 3840 x 2400 pixels
Processor: Intel Core Ultra 7
Memory: 32 GB
Storage: 1 TB
Graphics: Not available

Brand: Lenovo
Category: Laptop
Model: Yoga 9 2-in-1 14ILL10 Copilot+ PC
Part numbers: 83LC006YMB, 83LC000PGE, 83LC001SSP, 83LC0008FR, 83LC004BMH, 83LC0040UK +34 more
EAN / UPC: 198156890832, 198156277169, 198156686732, 198155443107 +53 more
Also known as: Lenovo Yoga 9 2-in-1 14ILL10 Copilot+ PC Intel Core Ultra 7 258V Hybrid (2-in-1) 35.6 cm (14") Touchscreen WQUXGA 32 GB LPDDR5x-SDRAM 1 TB SSD Wi-Fi 7 (802.11be

Specifications

122 specifications in 21 groups

Design

Specification	Value
Product type	Hybrid (2-in-1)
Product colour	Grey
Colour name	Luna Grey
Form factor	Convertible (Folder)
Display back cover material	Aluminium
Housing material	Aluminium

Display

Specification	Value
Display diagonal	35.6 cm (14")
Display resolution	3840 x 2400 pixels
Touchscreen	Yes
HD type	WQUXGA
Panel type	OLED
LED backlight	Yes
Native aspect ratio	16:10
Display surface	Gloss
Display brightness	600 cd/m²
Colour gamut	100%
RGB colour space	DCI-P3
Maximum refresh rate	60 Hz
High Dynamic Range (HDR) supported	Yes
High Dynamic Range (HDR) technology	Dolby Vision

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel Core Ultra 7
Processor generation	Intel Core Ultra (Series 2)
Processor model	258V
Processor cores	8
Processor threads	8
Processor boost frequency	4.8 GHz
Performance cores	4
Low Power Efficient-cores	4
Performance-core Max Turbo Frequency	4.8 GHz
Low Power Efficient-core Max Turbo Frequency	3.7 GHz
Performance-core base frequency	2.2 GHz
Low Power Efficient-core Base Frequency	2200 MHz
Processor cache	12 MB
Processor cache type	Smart Cache
Maximum turbo power	37 W
Processor base power	17 W

Neural processor unit (NPU)

Specification	Value
Copilot+ PC	Yes
Neural processor unit (NPU)	Intel AI Boost
Sparsity support	Yes
Windows Studio effects support	Yes
AI software frameworks supported by NPU	DirectML, OpenVINO, Windows ML, ONNX RT, WebNN
Total processor performance up to	115 TOPs
NPU performance up to	47 TOPs
GPU performance up to	64 TOPs

Memory

Specification	Value
Internal memory	32 GB
Internal memory type	LPDDR5x-SDRAM
Memory clock speed	8533 MHz
Memory form factor	On-board
Maximum internal memory	32 GB

Storage

Specification	Value
Total storage capacity	1 TB
Storage media	SSD
Total SSDs capacity	1 TB
Number of SSDs installed	1
SSD capacity	1 TB
NVMe	Yes
SSD interface	PCI Express 4.0
SSD form factor	M.2
Optical drive type	No
Card reader integrated	No

Graphics

Specification	Value
On-board graphics card	Yes
Discrete graphics card	No
Discrete graphics card model	Not available
On-board GPU manufacturer	Intel
On-board graphics card family	Intel Arc Graphics
On-board graphics card model	Intel Arc Graphics 140V

Audio

Specification	Value
Audio chip	Cirrus Logic CS42L43
Number of built-in speakers	4
Built-in microphone	Yes
Number of microphones	4

Camera

Specification	Value
Front camera	Yes
Front camera resolution (numeric)	5 MP
Infrared (IR) camera	Yes
Privacy camera	Yes
Privacy type	Privacy shutter

Network

Specification	Value
Mobile network connection	No
Top Wi-Fi standard	Wi-Fi 7 (802.11be)
Wi-Fi standards	Wi-Fi 7 (802.11be)
Antenna type	2x2
Ethernet LAN	No
Bluetooth	Yes
Bluetooth version	5.4
WWAN	Not installed

Ports & interfaces

Specification	Value
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	1
USB 3.2 Gen 2x2 Type-C ports quantity	1
Thunderbolt 4 ports quantity	2
Intel® Thunderbolt 4	Yes
Combo headphone/mic port	Yes
USB Sleep-and-Charge	Yes

Performance

Specification	Value
Motherboard chipset	Intel SoC

Keyboard

Specification	Value
Pointing device	Touchpad
Keyboard backlit	Yes
Numeric keypad	No
Keyboard language	German
Copilot key	Yes

Software

Specification	Value
Operating system installed	Windows 11 Home
Operating system language	German
Microsoft Copilot	Yes
Trial software	Office

Battery

Specification	Value
Battery capacity	75 Wh

Power

Specification	Value
AC adapter power	65 W
AC adapter frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
USB Type-C charging port	Yes
USB Power Delivery (USB PD)	Yes

Security

Specification	Value
Fingerprint reader	Yes
Windows Hello	Yes
Trusted Platform Module (TPM)	Yes
Trusted Platform Module (TPM) version	2.0

Operational conditions

Specification	Value
Operating temperature (T-T)	5 - 35 °C
Storage temperature (T-T)	5 - 43 °C
Operating relative humidity (H-H)	8 - 95%
Storage relative humidity (H-H)	5 - 95%

Certificates

Specification	Value
Certification	ENERGY STAR,EPEAT Gold,RoHS

Weight & dimensions

Specification	Value
Weight	1.32 kg
Width	316 mm
Depth	220 mm
Height	15.9 mm

Packaging content

Specification	Value
AC adapter included	Yes
