Lenovo ThinkPad X1 Titanium Yoga Gen 1

ThinkPad X1 Titanium Yoga Gen 1

Model ThinkPad X1 Titanium Yoga Gen 1Part no. 20QA001QPBEAN 195477530102

96 specifications Checked today

Display34.3 cm (13.5")
Resolution2256 x 1504 pixels
ProcessorIntel® Core™ i5
Memory16 GB
Storage512 GB
GraphicsNot available

See all specifications

Overview

Display: 34.3 cm (13.5")
Resolution: 2256 x 1504 pixels
Processor: Intel® Core™ i5
Memory: 16 GB
Storage: 512 GB
Graphics: Not available

Brand: Lenovo
Category: Laptop
Model: ThinkPad X1 Titanium Yoga Gen 1
Part numbers: 20QA001QPB, 20QA003WSG, 20QA006LAU, 20QA006MAU, 20QA006NAU, 20QA000YAU +34 more
EAN / UPC: 195477530102, 195891662335, 196119690192, 196119689684 +56 more
Also known as: Lenovo ThinkPad X1 Titanium Yoga Gen 1 Intel® Core™ i5 i5-1130G7 Hybrid (2-in-1) 34.3 cm (13.5") Touchscreen 16 GB LPDDR4x-SDRAM 512 GB SSD Wi-Fi 6 (802.11ax) W

Specifications

96 specifications in 19 groups

Design

Specification	Value
Product type	Hybrid (2-in-1)
Product colour	Titanium
Form factor	Convertible (Folder)

Display

Specification	Value
Display diagonal	34.3 cm (13.5")
Display resolution	2256 x 1504 pixels
Touchscreen	Yes
Panel type	IPS
LED backlight	Yes
Display brightness	450 cd/m²
Colour gamut	72%
RGB colour space	NTSC
High Dynamic Range (HDR) supported	Yes
High Dynamic Range (HDR) technology	Dolby Vision

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Core™ i5
Processor model	i5-1130G7
Processor cores	4
Processor threads	8
Processor boost frequency	4 GHz
Processor frequency	1.8 GHz

Memory

Specification	Value
Internal memory	16 GB
Internal memory type	LPDDR4x-SDRAM
Memory clock speed	4266 MHz
Memory form factor	On-board
Maximum internal memory	16 GB

Storage

Specification	Value
Total storage capacity	512 GB
Storage media	SSD
Total SSDs capacity	512 GB
Number of SSDs installed	1
SSD capacity	512 GB
NVMe	Yes
SSD interface	PCI Express 3.0
SSD form factor	M.2
Optical drive type	No
Card reader integrated	No

Graphics

Specification	Value
On-board graphics card	Yes
Discrete graphics card	No
Discrete graphics card model	Not available
On-board GPU manufacturer	Intel
On-board graphics card model	Intel Iris Xe Graphics

Audio

Specification	Value
Audio chip	Realtek ALC3286
Number of built-in speakers	2
Speaker power	2 W
Built-in microphone	Yes
Number of microphones	4

Camera

Specification	Value
Front camera	Yes
Front camera HD type	HD
Front camera resolution	1280 x 720 pixels
Infrared (IR) camera	Yes
Privacy camera	Yes
Privacy type	Privacy shutter

Network

Specification	Value
Mobile network connection	Yes
Mobile network generation	4G
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
Wi-Fi standards	Wi-Fi 6 (802.11ax)
Antenna type	2x2
WLAN controller manufacturer	Intel
WLAN controller model	Intel Wi-Fi 6 AX201
Ethernet LAN	No
Bluetooth	Yes
Bluetooth version	5.1
Near Field Communication (NFC)	No
WWAN	Installed
WWAN controller	Fibocom L850-GL, 4G LTE CAT9

Ports & interfaces

Specification	Value
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
Thunderbolt 4 ports quantity	2
Intel® Thunderbolt 4	Yes
Combo headphone/mic port	Yes

Performance

Specification	Value
Motherboard chipset	Intel SoC

Keyboard

Specification	Value
Pointing device	ThinkPad UltraNav
Keyboard backlit	Yes
Numeric keypad	No

Software

Specification	Value
Operating system installed	Windows 10 Pro
Operating system architecture	64-bit
Operating system language	English

Battery

Specification	Value
Battery capacity	44.5 Wh
Battery life (max)	11.7 h

Power

Specification	Value
AC adapter power	65 W
USB Type-C charging port	Yes
USB Power Delivery (USB PD)	Yes

Security

Specification	Value
Cable lock slot	Yes
Cable lock slot type	Kensington
Fingerprint reader	Yes
Smart card reader	No
Windows Hello	Yes
Trusted Platform Module (TPM)	Yes
Trusted Platform Module (TPM) version	2.0

Certificates

Specification	Value
Certification	ENERGY STAR,TCO,EPEAT Gold,RoHS

Weight & dimensions

Specification	Value
Weight	1.18 kg
Width	297.5 mm
Depth	232.7 mm
Height	11.5 mm

Packaging content

Specification	Value
AC adapter included	Yes
Stylus pen	Yes
