Lenovo ThinkPad X1 Fold 16 Gen 1

ThinkPad X1 Fold 16 Gen 1

Model ThinkPad X1 Fold 16 Gen 1Part no. 21ES0013SPEAN 198154610968

107 specifications Checked today

Display41.4 cm (16.3")
Resolution2560 x 2024 pixels
ProcessorIntel® Core™ i7
Memory16 GB
Storage512 GB
GraphicsNot available

See all specifications

Overview

Display: 41.4 cm (16.3")
Resolution: 2560 x 2024 pixels
Processor: Intel® Core™ i7
Memory: 16 GB
Storage: 512 GB
Graphics: Not available

Brand: Lenovo
Category: Laptop
Model: ThinkPad X1 Fold 16 Gen 1
Part numbers: 21ES0013SP, 21ES0018SP, 21ES0028SQ, 21ES0029SQ, 21ES000KCA, 21ES000JCA +28 more
EAN / UPC: 198154610968, 198154611392, 196802938570, 196802938730 +29 more
Also known as: Lenovo ThinkPad X1 Fold 16 Gen 1 Intel® Core™ i7 i7-1250U Hybrid (2-in-1) 41.4 cm (16.3") Touchscreen 16 GB LPDDR5-SDRAM 512 GB SSD Wi-Fi 6E (802.11ax) Windows

Specifications

107 specifications in 20 groups

Design

Specification	Value
Product type	Hybrid (2-in-1)
Product colour	Black
Colour name	Performance Black
Form factor	Convertible (Detachable)
Housing material	Aluminium

Display

Specification	Value
Display diagonal	41.4 cm (16.3")
Display resolution	2560 x 2024 pixels
Touchscreen	Yes
Panel type	OLED
LED backlight	Yes
Display brightness	400 cd/m²
Colour gamut	100%
RGB colour space	DCI-P3
High Dynamic Range (HDR) supported	Yes
High Dynamic Range (HDR) technology	Dolby Vision

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Core™ i7
Processor generation	12th gen Intel® Core™ i7
Processor model	i7-1250U
Processor cores	10
Processor threads	12
Processor boost frequency	4.7 GHz
Performance cores	2
Efficient cores	8
Performance-core Max Turbo Frequency	4.7 GHz
Efficient-core Max Turbo Frequency	3.5 GHz
Processor cache	12 MB
Processor cache type	Smart Cache
Maximum turbo power	29 W
Processor base power	9 W

Memory

Specification	Value
Internal memory	16 GB
Internal memory type	LPDDR5-SDRAM
Memory clock speed	5200 MHz
Memory form factor	On-board
Maximum internal memory	16 GB

Storage

Specification	Value
Total storage capacity	512 GB
Storage media	SSD
Total SSDs capacity	512 GB
Number of SSDs installed	1
SSD capacity	512 GB
NVMe	Yes
SSD interface	PCI Express 4.0
SSD form factor	M.2
Optical drive type	No
Card reader integrated	No

Graphics

Specification	Value
On-board graphics card	Yes
Discrete graphics card	No
Discrete graphics card model	Not available
On-board GPU manufacturer	Intel
On-board graphics card family	Intel Iris Xe Graphics
On-board graphics card model	Intel Iris Xe Graphics

Audio

Specification	Value
Number of built-in speakers	3
Speaker power	2 W
Built-in microphone	Yes
Number of microphones	4

Camera

Specification	Value
Front camera resolution (numeric)	5 MP
Infrared (IR) camera	Yes

Network

Specification	Value
Mobile network connection	Yes
Mobile network generation	5G
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
Wi-Fi standards	Wi-Fi 6E (802.11ax)
Antenna type	2x2
WLAN controller manufacturer	Intel
WLAN controller model	Intel Wi-Fi 6E AX211
Ethernet LAN	No
Bluetooth	Yes
Bluetooth version	5.1
Near Field Communication (NFC)	No
WWAN	Installed
WWAN controller	Fibocom FM350-GL, 5G Sub-6 GHz, with Embedded eSIM

Ports & interfaces

Specification	Value
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	1
Thunderbolt 4 ports quantity	2
Intel® Thunderbolt 4	Yes

Performance

Specification	Value
Motherboard chipset	Intel SoC

Keyboard

Specification	Value
Pointing device	ThinkPad UltraNav
Numeric keypad	No
Keyboard language	German

Software

Specification	Value
Operating system installed	Windows 11 Pro
Operating system architecture	64-bit
Operating system language	English, French, German, Dutch, Italian
Bundled software	Intel Connectivity Performance Suite

Battery

Specification	Value
Battery technology	Lithium Polymer (LiPo)
Battery capacity	64 Wh

Power

Specification	Value
AC adapter power	65 W
AC adapter frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
USB Type-C charging port	Yes
USB Power Delivery (USB PD)	Yes

Security

Specification	Value
Fingerprint reader	Yes
Smart card reader	No
Windows Hello	Yes
Trusted Platform Module (TPM)	Yes
Trusted Platform Module (TPM) version	2.0

Operational conditions

Specification	Value
Operating temperature (T-T)	5 - 35 °C
Storage temperature (T-T)	5 - 43 °C
Operating relative humidity (H-H)	8 - 95%
Storage relative humidity (H-H)	5 - 95%

Certificates

Specification	Value
Certification	ENERGY STAR,TCO,EPEAT Gold,RoHS

Weight & dimensions

Specification	Value
Weight	1.31 kg
Width	176.2 mm
Depth	276.2 mm
Height	17.4 mm

Packaging content

Specification	Value
AC adapter included	Yes
Stylus pen	Yes
