Lenovo ThinkPad T43p 2668

Model ThinkPad T43p 2668Part no. UC3PFUK

117 specifications Checked 3 days ago

Display35.8 cm (14.1")
Resolution1400 x 1050 pixels
ProcessorIntel Pentium Mobile
Memory1 GB
Storage80 GB
GraphicsAMD Mobility FireGL V3200

See all specifications

Overview

Display: 35.8 cm (14.1")
Resolution: 1400 x 1050 pixels
Processor: Intel Pentium Mobile
Memory: 1 GB
Storage: 80 GB
Graphics: AMD Mobility FireGL V3200

Brand: Lenovo
Category: Laptop
Model: ThinkPad T43p 2668
Part number: UC3PFUK
Also known as: Lenovo ThinkPad T43p 2668 Intel Pentium Mobile 770 35.8 cm (14.1") 1 GB DDR2-SDRAM 80 GB AMD Mobility FireGL V3200 Windows XP Home Edition QWERTY

Specifications

117 specifications in 21 groups

Display

Specification	Value
Display diagonal	35.8 cm (14.1")
Display resolution	1400 x 1050 pixels
Native aspect ratio	4:3

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel Pentium Mobile
Processor model	770
Processor cores	1
Processor threads	1
Processor frequency	2.13 GHz
Processor cache	2 MB
Processor cache type	L2
Processor front side bus	533 MHz
Processor socket	Socket 479
Processor lithography	90 nm
Processor operating modes	32-bit
Processor series	Intel Pentium M 700 Series
Processor codename	Dothan
Bus type	FSB
FSB Parity	No
Stepping	C0
Thermal Design Power (TDP)	27 W
Tjunction	100 °C
Number of Processing Die Transistors	144 M
Processing Die size	87 mm²
CPU multiplier (bus/core ratio)	16
ECC supported by processor	No

Memory

Specification	Value
Internal memory	1 GB
Internal memory type	DDR2-SDRAM
Memory layout (slots x size)	1 x 1 GB
Maximum internal memory	2 GB

Storage

Specification	Value
Total storage capacity	80 GB
HDD speed	5400 RPM
Optical drive type	DVD-RW

Graphics

Specification	Value
Discrete graphics card	Yes
Discrete graphics card model	AMD Mobility FireGL V3200

Audio

Specification	Value
Audio system	AC'97, SoundMAX
Number of built-in speakers	2

Camera

Specification	Value
Front camera	No

Network

Specification	Value
Networking features	Gigabit Ethernet, WLAN
Wireless technology	IEEE 802.11a/b/g
Bluetooth	Yes
Bluetooth version	2.0+EDR

Ports & interfaces

Specification	Value
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	1
DVI port	No
VGA (D-Sub) ports quantity	1
Firewire (IEEE 1394) ports	0
Headphone outputs	1
S/PDIF out port	No
Microphone in	Yes
Docking connector	Yes
ExpressCard slot	Yes
CardBus PCMCIA slots quantity	1
CardBus PCMCIA slot type	Type II
SmartCard slot	No
Modem (RJ-11) ports	1
TV-in port	No
TV-out	Yes
TV-out type	S-Video
PS/2 ports quantity	0
Parallel ports quantity	1
Serial ports quantity	0
USB 1.1 ports quantity	0

Performance

Specification	Value
Motherboard chipset	Intel® 915PM Express

Keyboard

Specification	Value
Pointing device	ThinkPad UltraNav
Keyboard layout	QWERTY

Software

Specification	Value
Operating system installed	Windows XP Home Edition

Processor special features

Specification	Value
Intel® Wireless Display (Intel® WiDi)	No
Embedded options available	No
Enhanced Intel SpeedStep Technology	Yes
Execute Disable Bit	Yes
Idle States	No
Intel 64	No
Intel Clear Video Technology	No
Intel Demand Based Switching	No
Intel Dual Display Capable Technology	No
Intel Enhanced Halt State	No
Intel FDI Technology	No
Intel Fast Memory Access	No
Intel Flex Memory Access	No
Intel Rapid Storage Technology	No
Intel Trusted Execution Technology	No
Intel VT-x with Extended Page Tables (EPT)	No
Intel Virtualization Technology (VT-x)	No
Intel Virtualization Technology for Directed I/O (VT-d)	No
Intel® AES New Instructions (Intel® AES-NI)	No
Intel® Anti-Theft Technology (Intel® AT)	No
Intel® Clear Video HD Technology (Intel® CVT HD)	No
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)	No
Intel® Hyper Threading Technology (Intel® HT Technology)	No
Intel® InTru™ 3D Technology	No
Intel® Insider™	No
Intel® My WiFi Technology (Intel® MWT)	No
Intel® Quick Sync Video Technology	No
Intel® Turbo Boost Technology	No
Physical Address Extension (PAE)	32 bit
Processor ARK ID	27597
Processor code	SL868
Processor package size	35 x 35 mm
Thermal Monitoring Technologies	No
Conflict-Free processor	No

Battery

Specification	Value
Number of battery cells	6
Battery life (max)	4.5 h

Power

Specification	Value
AC adapter input voltage	100/240 V
DC-in jack	Yes

Security

Specification	Value
Fingerprint reader	Yes
Trusted Platform Module (TPM)	Yes

Operational conditions

Specification	Value
Operating relative humidity (H-H)	8 - 95%

Certificates

Specification	Value
Certification	ACPI 2.0, ACPI 1.0b, CE, MPR II, BSMI, cUL, NOM, VCCI-II, UL 60950, CB, FCC Part 15 B, CCC, MIC, AS/NZS 3548

Weight & dimensions

Specification	Value
Weight	2.2 kg
Width	311 mm
Depth	255 mm
Height	31 mm

Packaging content

Specification	Value
AC adapter included	Yes

Other features

Specification	Value
Infrared data port	Yes
Internal modem	Yes
Modem speed	56 Kbit/s
