Lenovo ThinkPad P1 Gen 3
Lenovo

ThinkPad P1 Gen 3

Model ThinkPad P1 Gen 3Part no. 20TH0039USEAN 195235872598

115 specifications Checked today
  • Display39.6 cm (15.6")
  • Resolution3840 x 2160 pixels
  • ProcessorIntel® Xeon®
  • Memory32 GB
  • Storage1 TB
  • GraphicsNVIDIA Quadro T2000
See all specifications

Overview

Display
39.6 cm (15.6")
Resolution
3840 x 2160 pixels
Processor
Intel® Xeon®
Memory
32 GB
Storage
1 TB
Graphics
NVIDIA Quadro T2000
Brand
Lenovo
Category
Laptop
Model
ThinkPad P1 Gen 3
Part numbers
20TH0039US, 20TJS0B100, 20TJS0B100-MOBI_AA, 20TJS0B100-MOBI_AB, 20TJS0B100-MOBI_AC, 20TH0034US +34 more
EAN / UPC
195235872598, 195042986501, 195891911181, 195477168435 +56 more
Also known as
Lenovo ThinkPad P1 Gen 3 Intel® Xeon® W-10855M Mobile workstation 39.6 cm (15.6") 4K Ultra HD 32 GB DDR4-SDRAM 1 TB SSD NVIDIA Quadro T2000 Wi-Fi 6 (802.11ax) W

Specifications

115 specifications in 21 groups

Design

Product typeMobile workstation
Product colourBlack
Form factorClamshell
Housing materialAcrylonitrile butadiene styrene (ABS), Aluminium, Carbon fibre, Polycarbonate (PC), Polyphenylene sulfide (PPS)

Display

Display diagonal39.6 cm (15.6")
Display resolution3840 x 2160 pixels
TouchscreenNo
HD type4K Ultra HD
LED backlightYes
Native aspect ratio16:9
Colour gamut100%
High Dynamic Range (HDR) supportedYes
High Dynamic Range (HDR) technologyDolby Vision

Processor

Processor manufacturerIntel
Processor familyIntel® Xeon®
Processor modelW-10855M
Processor cores6
Processor threads12
Processor boost frequency5.1 GHz
Processor frequency2.8 GHz
Processor cache12 MB
Processor cache typeSmart Cache

Memory

Internal memory32 GB
Internal memory typeDDR4-SDRAM
Memory clock speed2933 MHz
Memory form factorSO-DIMM
Memory layout (slots x size)2 x 16 GB
Memory slots2x SO-DIMM
Maximum internal memory64 GB
Memory channelsDual-channel
ECCYes

Storage

Total storage capacity1 TB
Storage mediaSSD
Total SSDs capacity1 TB
Number of SSDs installed1
SSD capacity1 TB
NVMeYes
SSD interfacePCI Express
M.2 SSD size2280 (22 x 80 mm)
SSD form factorM.2
Optical drive typeNo
Card reader integratedYes
Compatible memory cardsSD

Graphics

On-board graphics cardYes
Discrete graphics cardYes
Discrete graphics card modelNVIDIA Quadro T2000
Discrete graphics card memory4 GB
Discrete graphics memory typeGDDR6
On-board GPU manufacturerIntel
On-board graphics card familyIntel® UHD Graphics
On-board graphics card modelIntel® UHD Graphics
NVIDIA Max-QYes

Audio

Audio chipRealtek ALC3286
Audio systemDolby Atmos
Number of built-in speakers2

Camera

Front cameraYes
Front camera HD typeHD
Front camera resolution1280 x 720 pixels
Infrared (IR) cameraYes
Privacy cameraYes
Privacy typePrivacy shutter

Network

Mobile network connectionYes
Mobile network generation4G
4G standardLTE
Top Wi-Fi standardWi-Fi 6 (802.11ax)
Wi-Fi standardsWi-Fi 6 (802.11ax)
Antenna type2x2
WLAN controller manufacturerIntel
WLAN controller modelIntel Wi-Fi 6 AX201
BluetoothYes
Bluetooth version5.1
WWANInstalled
WWAN controllerFibocom L860-GL

Ports & interfaces

USB 2.0 ports quantity0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity2
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity0
HDMI ports quantity1
HDMI version2.0
Thunderbolt 3 ports quantity2
Combo headphone/mic portYes
USB Type-C DisplayPort Alternate ModeYes
USB Sleep-and-ChargeYes
USB Sleep-and-Charge ports1

Performance

Motherboard chipsetIntel WM490

Keyboard

Pointing deviceThinkPad UltraNav
Keyboard backlitYes
Numeric keypadNo
Spill-resistant keyboardYes

Software

Operating system installedWindows 10 Pro for Workstations
Operating system architecture64-bit
Operating system languageGerman, Dutch, English, French, Italian

Battery

Battery technologyLithium Polymer (LiPo)
Battery capacity80 Wh
Battery life (max)15.9 h

Power

USB Type-C charging portYes
USB Power Delivery (USB PD)Yes

Security

Cable lock slotYes
Cable lock slot typeKensington
Fingerprint readerYes
Smart card readerNo
Trusted Platform Module (TPM)Yes
Trusted Platform Module (TPM) version2.0
Password protectionYes
Password protection typePower on, Supervisor, HDD

Operational conditions

Operating temperature (T-T)5 - 35 °C
Storage temperature (T-T)5 - 43 °C
Operating relative humidity (H-H)8 - 95%
Storage relative humidity (H-H)5 - 95%
Maximum shipping altitude3048 m

Certificates

Compliance certificatesRoHS
CertificationMIL-STD-810G

Sustainability

Sustainability certificatesENERGY STAR, EPEAT Gold

Weight & dimensions

Width361.8 mm
Depth245.7 mm

Packaging content

AC adapter includedYes
