Lenovo ThinkBook 13x G4 IMH

ThinkBook 13x G4 IMH

Model ThinkBook 13x G4 IMHPart no. 21KR001EJPEAN 4580550142437

134 specifications Checked today

Display34.3 cm (13.5")
Resolution2880 x 1920 pixels
ProcessorIntel Core Ultra 9
Memory16 GB
Storage512 GB
GraphicsNot available

See all specifications

Overview

Display: 34.3 cm (13.5")
Resolution: 2880 x 1920 pixels
Processor: Intel Core Ultra 9
Memory: 16 GB
Storage: 512 GB
Graphics: Not available

Brand: Lenovo
Category: Laptop
Model: ThinkBook 13x G4 IMH
Part numbers: 21KR001EJP, 21KR002HUS, 21KR002JUS, 21KR002KUS, 21KR0022ID, 21KR0006UK +28 more
EAN / UPC: 4580550142437, 199271558737, 199271558744, 199271558751 +30 more
Also known as: Lenovo ThinkBook 13x G4 IMH Intel Core Ultra 9 185H Laptop 34.3 cm (13.5") Touchscreen 2.8K 16 GB LPDDR5x-SDRAM 512 GB SSD Wi-Fi 6E (802.11ax) Windows 11 Pro Gr

Specifications

134 specifications in 22 groups

Design

Specification	Value
Product type	Laptop
Product colour	Grey
Colour name	Luna Grey
Form factor	Clamshell
Housing material	Aluminium

Display

Specification	Value
Display diagonal	34.3 cm (13.5")
Display resolution	2880 x 1920 pixels
Touchscreen	Yes
HD type	2.8K
Panel type	IPS
LED backlight	Yes
Native aspect ratio	3:2
Display surface	Gloss
Display glass type	Gorilla Glass
Display brightness	500 cd/m²
Colour gamut	100%
RGB colour space	sRGB
Maximum refresh rate	120 Hz
Contrast ratio (typical)	1500:1
High Dynamic Range (HDR) supported	Yes
High Dynamic Range (HDR) technology	DisplayHDR 400, Dolby Vision

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel Core Ultra 9
Processor generation	Intel® Core™ Ultra (Series 1)
Processor model	185H
Processor cores	16
Processor boost frequency	5.1 GHz
Performance cores	6
Efficient cores	8
Performance-core Max Turbo Frequency	5.1 GHz
Efficient-core Max Turbo Frequency	3.8 GHz
Performance-core base frequency	2.3 GHz
Efficient-core base frequency	1.8 GHz
Processor cache	24 MB
Processor cache type	Smart Cache
Maximum turbo power	115 W
Processor base power	45 W

Neural processor unit (NPU)

Specification	Value
Neural processor unit (NPU)	Intel AI Boost
Maximum frequency NPU	1.4 GHz
Sparsity support	Yes
Windows Studio effects support	Yes
AI datatype support on NPU	FP16, FP32, Int8
AI software frameworks supported by NPU	DirectML, ONNX RT, OpenVINO, Windows ML

Memory

Specification	Value
Internal memory	16 GB
Internal memory type	LPDDR5x-SDRAM
Memory clock speed	8400 MHz
Memory form factor	On-board
Maximum internal memory	16 GB
Memory channels	Dual-channel

Storage

Specification	Value
Total storage capacity	512 GB
Storage media	SSD
Total SSDs capacity	512 GB
Number of SSDs installed	1
SSD capacity	512 GB
NVMe	Yes
SSD interface	PCI Express 4.0
M.2 SSD size	2242 (22 x 42 mm)
SSD form factor	M.2
Optical drive type	No
Card reader integrated	No

Graphics

Specification	Value
On-board graphics card	Yes
Discrete graphics card	No
Discrete graphics card model	Not available
On-board GPU manufacturer	Intel
On-board graphics card family	Intel Arc Graphics
On-board graphics card model	Intel Arc Graphics

Audio

Specification	Value
Audio chip	Realtek ALC3306-CG
Audio system	Dolby Atmos
Number of built-in speakers	2
Speakers manufacturer	Harman Kardon
Speaker power	2 W
Built-in microphone	Yes
Number of microphones	4

Camera

Specification	Value
Front camera	Yes
Front camera HD type	Full HD
Front camera resolution	1920 x 1080 pixels
Infrared (IR) camera	Yes
Privacy camera	Yes

Network

Specification	Value
Mobile network connection	No
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
Wi-Fi standards	Wi-Fi 6E (802.11ax)
Antenna type	2x2
Ethernet LAN	No
Bluetooth	Yes
Bluetooth version	5.1
WWAN	Not installed

Ports & interfaces

Specification	Value
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	0
HDMI ports quantity	0
Thunderbolt 4 ports quantity	3
Intel® Thunderbolt 4	Yes
Combo headphone/mic port	Yes
USB Type-C DisplayPort Alternate Mode	Yes

Performance

Specification	Value
Motherboard chipset	Intel SoC

Keyboard

Specification	Value
Pointing device	Touchpad
Keyboard backlit	Yes
Numeric keypad	No
Spill-resistant keyboard	Yes
Keyboard language	US English

Software

Specification	Value
Operating system installed	Windows 11 Pro
Operating system language	English
Bundled software	Office Trial

Battery

Specification	Value
Battery technology	Lithium Polymer (LiPo)
Battery capacity	74 Wh
Battery life (max)	12.92 h
Continuous video playback time (max)	27.2 h
Fast charging	Yes

Power

Specification	Value
AC adapter power	65 W
AC adapter frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
USB Type-C charging port	Yes
USB Power Delivery (USB PD)	Yes

Security

Specification	Value
Fingerprint reader	Yes
Windows Hello	Yes
Trusted Platform Module (TPM)	Yes
Trusted Platform Module (TPM) version	2.0
Password protection	Yes
Password protection type	BIOS, HDD, Power on, Supervisor

Operational conditions

Specification	Value
Operating temperature (T-T)	5 - 35 °C
Storage temperature (T-T)	5 - 43 °C
Operating relative humidity (H-H)	8 - 95%
Storage relative humidity (H-H)	5 - 95%
Maximum shipping altitude	3048 m

Certificates

Specification	Value
Compliance certificates	RoHS
Certification	Carbon Neutral Certified ErP Lot 6 ErP Lot 26 Intel® Evo™ Platform Eyesafe® Certified 2.0 TÜV Rheinland® Eye Comfort Certification 2.0 TÜV Rheinland® Low Blue Light (Hardware Solution)

Sustainability

Specification	Value
Sustainability certificates	ENERGY STAR, EPEAT Gold, TCO

Weight & dimensions

Specification	Value
Weight	1.23 kg
Width	292.9 mm
Depth	205 mm
Height	12.9 mm

Packaging content

Specification	Value
AC adapter included	Yes
Stylus pen	No
