Lenovo Yoga Book Intel Atom® x5-Z8550 Hybrid (2-in-1)

Yoga Book Intel Atom® x5-Z8550 Hybrid (2-in-1)

25.6 cm (10.1") Touchscreen Full HD 4 GB LPDDR3-SDRAM 64 GB Windows 10 Home Black

Model BookPart no. ZA150033CNEAN 191200314896

95 specifications Checked today

Display25.6 cm (10.1")
Resolution1920 x 1200 pixels
ProcessorIntel Atom®
Memory4 GB
Storage64 GB
GraphicsNot available

See all specifications

Overview

Display: 25.6 cm (10.1")
Resolution: 1920 x 1200 pixels
Processor: Intel Atom®
Memory: 4 GB
Storage: 64 GB
Graphics: Not available

Brand: Lenovo
Category: Laptop
Model: Book
Part numbers: ZA150033CN, ZA160033GB
EAN / UPC: 191200314896
Also known as: Lenovo Yoga Book Intel Atom® x5-Z8550 Hybrid (2-in-1) 25.6 cm (10.1") Touchscreen Full HD 4 GB LPDDR3-SDRAM 64 GB Windows 10 Home Black

Specifications

95 specifications in 16 groups

Design

Specification	Value
Product type	Hybrid (2-in-1)
Product colour	Black
Form factor	Convertible (Folder)
Housing material	Metal

Display

Specification	Value
Display diagonal	25.6 cm (10.1")
Display resolution	1920 x 1200 pixels
Touchscreen	Yes
Touchscreen type	Capacitive
HD type	Full HD
Panel type	IPS
Display number of colours	16.78 million colours
LED backlight	Yes
Native aspect ratio	16:10
Display brightness	400 cd/m²

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel Atom®
Processor model	x5-Z8550
Processor cores	4
Processor threads	4
Processor boost frequency	2.4 GHz
Processor frequency	1.44 GHz
Processor cache	2 MB
Processor cache type	L3
Processor socket	BGA 1380
Processor lithography	14 nm
Processor operating modes	64-bit
Processor series	Intel Atom x5 Series
Processor codename	Cherry Trail
Scenario Design Power (SDP)	2 W
Tjunction	90 °C
Maximum number of PCI Express lanes	2
PCI Express configurations	2x1, 1x2
PCI Express slots version	2.0

Memory

Specification	Value
Internal memory	4 GB
Internal memory type	LPDDR3-SDRAM

Storage

Specification	Value
Total storage capacity	64 GB
Optical drive type	No
Card reader integrated	Yes
Compatible memory cards	MicroSD (TransFlash)

Graphics

Specification	Value
On-board graphics card	Yes
Discrete graphics card	No
Discrete graphics card model	Not available
On-board graphics card family	Intel® HD Graphics
On-board graphics card model	Intel® HD Graphics 400
Maximum on-board graphics card memory	8 GB
Number of execution units	12
On-board graphics card base frequency	200 MHz
On-board graphics card burst frequency	600 MHz
On-board graphics card dynamic frequency (max)	600 MHz

Audio

Specification	Value
Number of built-in speakers	2
Built-in microphone	Yes

Camera

Specification	Value
Front camera	Yes
Front camera resolution (numeric)	2 MP
Auto focus	Yes
Rear camera	Yes
Rear camera resolution (numeric)	8 MP

Network

Specification	Value
Wi-Fi	Yes
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth	Yes
Bluetooth version	4.0

Ports & interfaces

Specification	Value
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Micro-USB 2.0 ports quantity	1
HDMI ports quantity	0
DisplayPorts quantity	0
DVI port	No
VGA (D-Sub) ports quantity	0
Thunderbolt ports quantity	0
Micro HDMI ports quantity	1

Keyboard

Specification	Value
Numeric keypad	No

Software

Specification	Value
Operating system installed	Windows 10 Home

Processor special features

Specification	Value
Intel® Wireless Display (Intel® WiDi)	Yes
Embedded options available	No
Intel 64	Yes
Intel Identity Protection Technology version	1.00
Intel Secure Boot	Yes
Intel Secure Boot Technology version	1.00
Intel Stable Image Platform Program (SIPP)	No
Intel Stable Image Platform Program (SIPP) version	0.00
Intel Virtualization Technology (VT-x)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Intel® Identity Protection Technology (Intel® IPT)	Yes
Intel® Turbo Boost Technology	No
Processor ARK ID	93360
Processor code	SR2KH
Processor package size	17 x 17 mm
Conflict-Free processor	Yes

Battery

Specification	Value
Battery technology	Lithium Polymer (LiPo)
Battery capacity	8500 mAh
Battery life (max)	13 h

Power

Specification	Value
DC-in jack	Yes

Weight & dimensions

Specification	Value
Weight	690 g
Width	256.6 mm
Depth	9.6 mm
Height	170.8 mm
