Lenovo Legion 83LY002YMX laptop Intel® Core™ i7 i7-13650HX

Legion 83LY002YMX laptop Intel® Core™ i7 i7-13650HX

38.4 cm (15.1") QWXGA 24 GB DDR5-SDRAM 1 TB SSD NVIDIA GeForce RTX 5070 Wi-Fi 7 (802.11be) Windows 11

Model 83LY002YMXEAN 198158203715

151 specifications Checked today

Display38.4 cm (15.1")
Resolution2560 x 1680 pixels
ProcessorIntel® Core™ i7
Memory24 GB
Storage1 TB
GraphicsNVIDIA GeForce RTX 5070

See all specifications

Overview

Display: 38.4 cm (15.1")
Resolution: 2560 x 1680 pixels
Processor: Intel® Core™ i7
Memory: 24 GB
Storage: 1 TB
Graphics: NVIDIA GeForce RTX 5070

Brand: Lenovo
Category: Laptop
Model: 83LY002YMX
Part number: 83LY002YMX
EAN / UPC: 198158203715
Also known as: Lenovo Legion 83LY002YMX laptop Intel® Core™ i7 i7-13650HX 38.4 cm (15.1") QWXGA 24 GB DDR5-SDRAM 1 TB SSD NVIDIA GeForce RTX 5070 Wi-Fi 7 (802.11be) Windows 11

Specifications

151 specifications in 23 groups

Design

Specification	Value
Product type	Laptop
Product colour	Black
Colour name	Eclipse Black
Form factor	Clamshell
Housing material	Acrylonitrile butadiene styrene (ABS), Aluminium, Polycarbonate (PC)
Market positioning	Gaming
Introduction year	2025
Introduction month	January
Country of origin	China
Original brand name	Lenovo

Display

Specification	Value
Display diagonal	38.4 cm (15.1")
Display resolution	2560 x 1680 pixels
Touchscreen	No
HD type	QWXGA
Panel type	OLED
Native aspect ratio	16:10
Display surface	Gloss
Display brightness	500 cd/m²
Colour gamut	100%
Low Blue Light technology	Yes
RGB colour space	DCI-P3
Maximum refresh rate	165 Hz
High Dynamic Range (HDR) supported	Yes
High Dynamic Range (HDR) technology	DisplayHDR True Black 600, Dolby Vision
Number of external displays supported	3

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Core™ i7
Processor generation	13th gen Intel® Core™ i7
Processor model	i7-13650HX
Processor cores	14
Processor threads	20
Processor boost frequency	4.9 GHz
Processor frequency	3.6 GHz
Performance cores	6
Efficient cores	8
Processor cache	24 MB
Processor cache type	Smart Cache
Maximum turbo power	157 W
Processor base power	55 W

Neural processor unit (NPU)

Specification	Value
Copilot+ PC	No
Neural processor unit (NPU)	No

Memory

Specification	Value
Internal memory	24 GB
Internal memory type	DDR5-SDRAM
Memory clock speed	4800 MHz
Memory form factor	SO-DIMM
Memory layout (slots x size)	2 x 12 GB
Memory slots	2x SO-DIMM
Maximum internal memory	32 GB
Memory channels	Dual-channel

Storage

Specification	Value
Total storage capacity	1 TB
Storage media	SSD
Total SSDs capacity	1 TB
Number of SSDs installed	1
SSD capacity	1 TB
NVMe	Yes
SSD interface	PCI Express 4.0
M.2 SSD size	2242 (22 x 42 mm)
SSD form factor	M.2
Optical drive type	No

Graphics

Specification	Value
On-board graphics card	Yes
Discrete graphics card	Yes
Discrete GPU manufacturer	NVIDIA
Discrete graphics card model	NVIDIA GeForce RTX 5070
Discrete graphics card memory	8 GB
Discrete graphics memory type	GDDR7
On-board GPU manufacturer	Intel
On-board graphics card family	Intel® UHD Graphics
On-board graphics card model	Intel® UHD Graphics
NVIDIA Max-Q	Yes
CUDA	Yes
CUDA cores	4608
NVIDIA Advanced Optimus	Yes
NVIDIA G-SYNC	Yes
Ray tracing acceleration	Yes

Audio

Specification	Value
Audio chip	Realtek ALC3287
Audio system	Nahimic Audio
Spatial audio	Yes
Number of built-in speakers	2
Speakers manufacturer	Harman Kardon
Speaker power	2 W
Built-in microphone	Yes
Number of microphones	2

Camera

Specification	Value
Front camera	Yes
Front camera resolution (numeric)	5 MP
Privacy type	Privacy shutter

Network

Specification	Value
Mobile network connection	No
Top Wi-Fi standard	Wi-Fi 7 (802.11be)
Wi-Fi standards	Wi-Fi 7 (802.11be)
Antenna type	2x2
Ethernet LAN	Yes
Bluetooth	Yes
Bluetooth version	5.4

Ports & interfaces

Specification	Value
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	2
Ethernet LAN (RJ-45) ports	1
HDMI ports quantity	1
HDMI version	2.1
Combo headphone/mic port	Yes
USB Type-C DisplayPort Alternate Mode	Yes
USB Sleep-and-Charge	Yes
USB Sleep-and-Charge ports	1

Performance

Specification	Value
Motherboard chipset	Intel HM770

Keyboard

Specification	Value
Pointing device	Touchpad
Keyboard backlit	Yes
Numeric keypad	Yes
Keyboard backlit colour	RGB
Keyboard backlit zone	24-zone RGB
Full-size keyboard	Yes
Keyboard language	Nordic
Copilot key	Yes

Software

Specification	Value
Operating system installed	Windows 11 Home
Operating system architecture	64-bit
Operating system language	Danish, Finnish, Norwegian, Swedish
Microsoft Copilot	Yes
Trial software	1
Bundled software	3 Months Xbox Game Pass Ultimate Trial

Battery

Specification	Value
Battery technology	Lithium-Ion (Li-Ion)
Number of battery cells	4
Battery capacity	60 Wh
Continuous video playback time (max)	6 h
Fast charging	Yes
Battery charge indicator	Yes

Power

Specification	Value
AC adapter power	245 W
AC adapter frequency	50-60 Hz
AC adapter output voltage	100-140 V
Power auto-sensing	Yes
USB Type-C charging port	Yes
USB Type-C required charging power (max)	100 W
USB Type-C required charging power (min)	65 W
USB Power Delivery (USB PD)	Yes

Security

Specification	Value
Trusted Platform Module (TPM)	Yes
Trusted Platform Module (TPM) version	2.0

Operational conditions

Specification	Value
Operating temperature (T-T)	5 - 35 °C
Storage temperature (T-T)	5 - 43 °C
Operating relative humidity (H-H)	8 - 95%
Storage relative humidity (H-H)	5 - 95%

Certificates

Specification	Value
Wi-Fi certified	Yes
Certification	ErP Lot 6/26 RoHS compliant TÜV Rheinland® Flicker Free TÜV Rheinland® High Gaming Performance TÜV Rheinland® Low Blue Light (Hardware Solution)

Sustainability

Specification	Value
Sustainability certificates	ErP

Weight & dimensions

Specification	Value
Weight	1.9 kg
Width	344.9 mm
Depth	255.3 mm
Height	21.5 mm

Packaging data

Specification	Value
Package width	518 mm
Package depth	88 mm
Package height	329 mm
Package weight	3.75 kg

Packaging content

Specification	Value
AC adapter included	Yes
