HP ZBook Studio 16 G11
HP

ZBook Studio 16 G11

Model ZBook Studio 16 G11Part no. AW4H4UP#ABAEAN 198701736981

146 specifications Checked today
  • Display40.6 cm (16")
  • Resolution3840 x 2400 pixels
  • ProcessorIntel Core Ultra 7
  • Memory32 GB
  • Storage512 GB
  • GraphicsNVIDIA GeForce RTX 4070
See all specifications

Overview

Display
40.6 cm (16")
Resolution
3840 x 2400 pixels
Processor
Intel Core Ultra 7
Memory
32 GB
Storage
512 GB
Graphics
NVIDIA GeForce RTX 4070
Brand
HP
Category
Laptop
Model
ZBook Studio 16 G11
Part numbers
AW4H4UP#ABA, AW4H4UP
EAN / UPC
198701736981
Also known as
HP ZBook Studio 16 G11 Intel Core Ultra 7 165H Mobile workstation 40.6 cm (16") WQUXGA 32 GB DDR5-SDRAM 512 GB SSD NVIDIA GeForce RTX 4070 Wi-Fi 7 (802.11be) Wi

Specifications

146 specifications in 24 groups

Design

Product typeMobile workstation
Product colourSilver
Form factorClamshell
Market positioningPerformance
Intel® vPro™ Platform EligibilityYes
Original brand nameHP

Display

Display diagonal40.6 cm (16")
Display resolution3840 x 2400 pixels
TouchscreenNo
HD typeWQUXGA
Panel typeIPS
Native aspect ratio16:10
Anti-glare screenYes
Display bezel technologyMicro-Edge
Display brightness500 cd/m²
Colour gamut100%
Display diagonal (metric)40.6 cm
RGB colour spaceDCI-P3
Maximum refresh rate120 Hz
DCI-P3 coverage100%

Processor

Processor manufacturerIntel
Processor familyIntel Core Ultra 7
Processor generationIntel® Core™ Ultra (Series 1)
Processor model165H
Processor cores16
Processor threads22
Processor boost frequency5 GHz
Performance cores6
Efficient cores8
Low Power Efficient-cores2
Performance-core Max Turbo Frequency5 GHz
Efficient-core Max Turbo Frequency3.8 GHz
Low Power Efficient-core Max Turbo Frequency2.5 GHz
Performance-core base frequency1.4 GHz
Efficient-core base frequency0.9 GHz
Low Power Efficient-core Base Frequency700 MHz
Processor cache24 MB
Processor cache typeSmart Cache
Processor socketBGA 2049
Maximum turbo power115 W
Processor base power28 W

Neural processor unit (NPU)

Neural processor unit (NPU)Intel AI Boost
Sparsity supportYes
Windows Studio effects supportYes
AI software frameworks supported by NPUDirectML, ONNX RT, OpenVINO, Windows ML
Total processor performance up to34 TOPs
NPU performance up to11 TOPs
GPU performance up to19 TOPs

Memory

Internal memory32 GB
Internal memory typeDDR5-SDRAM
Memory clock speed5600 MHz
Memory form factorSO-DIMM
Memory layout (slots x size)2 x 16 GB
Memory slots2x SO-DIMM
Maximum internal memory64 GB
Memory channelsDual-channel
Memory data transfer rate5600 MT/s

Storage

Total storage capacity512 GB
Storage mediaSSD
Total SSDs capacity512 GB
Number of SSDs installed1
SSD capacity512 GB
SSD memory typeTLC
NVMeYes
SSD interfacePCI Express 4.0
SSD form factorM.2
Optical drive typeNo

Graphics

On-board graphics cardYes
Discrete graphics cardYes
Discrete GPU manufacturerNVIDIA
Discrete graphics card modelNVIDIA GeForce RTX 4070
Discrete graphics card memory8 GB
Discrete graphics memory typeGDDR6
On-board GPU manufacturerIntel
On-board graphics card familyIntel Arc Graphics
On-board graphics card modelIntel Arc Graphics

Audio

Built-in speaker(s)Yes
Number of built-in speakers2
Built-in microphoneYes
Number of microphones2

Camera

Front cameraYes
Front camera HD typeHD
Infrared (IR) cameraYes

Network

Mobile network connectionNo
Wi-FiYes
Top Wi-Fi standardWi-Fi 7 (802.11be)
Wi-Fi standardsWi-Fi 7 (802.11be)
Antenna type2x2
WLAN controller manufacturerIntel
WLAN controller modelIntel Wi-Fi 7 BE200
BluetoothYes
Bluetooth version5.4

Ports & interfaces

USB 2.0 ports quantity0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity1
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity1
Thunderbolt 4 ports quantity2
Intel® Thunderbolt 4Yes
Combo headphone/mic portYes
Microphone inYes
USB Type-C DisplayPort Alternate ModeYes
USB Sleep-and-ChargeYes
USB Sleep-and-Charge ports2

Keyboard

Pointing deviceClickpad
Keyboard backlitYes
Numeric keypadNo
Spill-resistant keyboardYes
Full-size keyboardYes
Input device modelHP Premium Quiet Keyboard

Software

Operating system installedWindows 11 Pro

Processor special features

Intel® Turbo Boost TechnologyYes

Brand-specific features

HP speaker typeHP Dual Speakers
HP Connection OptimizerYes
HP Support AssistantYes
HP front cameraHP Webcam HD IR
HP segmentBusiness

Battery

Battery technologyLithium Polymer (LiPo)
Number of battery cells6
Battery capacity86 Wh
Fast chargingYes
Fast charging time (50%)30 min

Power

AC adapter power200 W
AC adapter frequency50 - 60 Hz
AC adapter input voltage100 - 240 V
USB Type-C charging portYes
USB Power Delivery (USB PD)Yes

Security

Cable lock slotYes
Cable lock slot typeNano
Fingerprint readerYes
Trusted Platform Module (TPM)Yes
Trusted Platform Module (TPM) version2.0
Password protectionYes
Password protection typeBIOS

Certificates

Low halogenYes

Sustainability

Sustainability certificatesENERGY STAR, TCO
Sustainability complianceYes

Weight & dimensions

Weight1.73 kg
Width356 mm
Depth242 mm
Height19 mm

Packaging data

Package width552 mm
Package depth69 mm
Package height345 mm

Packaging content

AC adapter includedNo
Keyboard includedYes

Other features

UNSPSC-code43211503
