HP TouchSmart tm2-2190ea

Model TouchSmart tm2-2190eaPart no. LB847EAEAN 886111340385

117 specifications Checked 5 days ago

Display30.7 cm (12.1")
Resolution1280 x 800 pixels
ProcessorIntel® Pentium®
Memory3 GB
Storage320 GB
TypeHybrid (2-in-1)

See all specifications

Overview

Display: 30.7 cm (12.1")
Resolution: 1280 x 800 pixels
Processor: Intel® Pentium®
Memory: 3 GB
Storage: 320 GB
Type: Hybrid (2-in-1)

Brand: HP
Category: Laptop
Model: TouchSmart tm2-2190ea
Part number: LB847EA
EAN / UPC: 886111340385
Also known as: HP TouchSmart tm2-2190ea Intel® Pentium® U5400 Hybrid (2-in-1) 30.7 cm (12.1") Touchscreen 3 GB Windows 7 Home Premium

Specifications

117 specifications in 17 groups

Design

Specification	Value
Product type	Hybrid (2-in-1)
Form factor	Convertible (Swivel)
Country of origin	China

Display

Specification	Value
Display diagonal	30.7 cm (12.1")
Display resolution	1280 x 800 pixels
Touchscreen	Yes
Native aspect ratio	16:10

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Pentium®
Processor model	U5400
Processor cores	2
Processor threads	2
Processor frequency	1.2 GHz
System bus rate	2.5 GT/s
Processor cache	2 MB
Processor cache type	L3
Processor socket	BGA 1288
Processor lithography	32 nm
Processor operating modes	64-bit
Processor series	Intel Pentium U5000 Series for Mobile
Processor codename	Arrandale
Bus type	DMI
FSB Parity	No
Stepping	K0
Thermal Design Power (TDP)	18 W
Tjunction	105 °C
Maximum number of PCI Express lanes	1
PCI Express configurations	1x16
PCI Express slots version	2.0
Number of Processing Die Transistors	382 M
Processing Die size	81 mm²
CPU multiplier (bus/core ratio)	9
ECC supported by processor	No

Memory

Specification	Value
Internal memory	3 GB
Memory layout (slots x size)	1 x 1 + 1 x 2 GB
Maximum internal memory	8 GB

Storage

Specification	Value
HDD capacity	320 GB
HDD interface	SATA
HDD speed	7200 RPM
Optical drive type	DVD Super Multi DL
Card reader integrated	Yes
Compatible memory cards	Memory Stick (MS), MMC, MS PRO, SD, xD

Graphics

Specification	Value
On-board graphics card	Yes
Graphics card family	AMD
Discrete graphics memory type	GDDR3
On-board graphics card family	Intel® HD Graphics
On-board graphics card model	Intel® HD Graphics
On-board graphics card base frequency	166 MHz
On-board graphics card dynamic frequency (max)	500 MHz
Maximum graphics card memory	0.5 GB
Graphics card	Mobility Radeon HD 5450

Audio

Specification	Value
Audio system	Dolby
Number of built-in speakers	2
Built-in microphone	Yes

Optical drive

Specification	Value
LightScribe	Yes

Network

Specification	Value
Wi-Fi	Yes
Networking features	Gigabit Ethernet
Ethernet LAN data rates	10,100,1000 Mbit/s
Bluetooth	Yes
Cabling technology	10/100/1000Base-T(X)

Ports & interfaces

Specification	Value
USB 2.0 ports quantity	3
Ethernet LAN (RJ-45) ports	1
VGA (D-Sub) ports quantity	1
Headphone outputs	1
Microphone in	Yes
Docking connector	No

Performance

Specification	Value
GPS (satellite)	No

Software

Specification	Value
Operating system installed	Windows 7 Home Premium
Operating system architecture	64-bit

Processor special features

Specification	Value
Intel® Wireless Display (Intel® WiDi)	No
CPU configuration (max)	1
Embedded options available	No
Enhanced Intel SpeedStep Technology	Yes
Execute Disable Bit	Yes
Graphics & IMC lithography	45 nm
Idle States	Yes
Intel 64	Yes
Intel Clear Video Technology	Yes
Intel Demand Based Switching	No
Intel Dual Display Capable Technology	Yes
Intel Enhanced Halt State	Yes
Intel FDI Technology	Yes
Intel Fast Memory Access	Yes
Intel Flex Memory Access	Yes
Intel Rapid Storage Technology	No
Intel Trusted Execution Technology	No
Intel VT-x with Extended Page Tables (EPT)	No
Intel Virtualization Technology (VT-x)	No
Intel Virtualization Technology for Directed I/O (VT-d)	No
Intel® AES New Instructions (Intel® AES-NI)	No
Intel® Anti-Theft Technology (Intel® AT)	No
Intel® Clear Video HD Technology (Intel® CVT HD)	Yes
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)	Yes
Intel® Hyper Threading Technology (Intel® HT Technology)	No
Intel® InTru™ 3D Technology	No
Intel® Insider™	No
Intel® My WiFi Technology (Intel® MWT)	No
Intel® Quick Sync Video Technology	No
Intel® Smart Cache	Yes
Intel® Turbo Boost Technology	No
Physical Address Extension (PAE)	36 bit
Physical Address Extension (PAE)	Yes
Processor ARK ID	49156
Processor code	SLBUH
Processor package size	BGA 34 x 28
Thermal Monitoring Technologies	Yes
Conflict-Free processor	No

Battery

Specification	Value
Battery technology	Lithium-Ion (Li-Ion)
Number of battery cells	6

Power

Specification	Value
AC adapter power	65 W
DC-in jack	Yes

Weight & dimensions

Specification	Value
Weight	1.89 kg
Width	326 mm
Depth	230 mm
Height (front)	2.43 cm
Height (rear)	3 cm

Packaging data

Specification	Value
Package weight	4.25 kg
