OmniBook 5 AI 16-af1037nr
Model OmniBook 5 AI 16-af1037nrPart no. B7ND0UA#ABA
122 specifications Checked today
- Display40.6 cm (16")
- Resolution1920 x 1200 pixels
- ProcessorIntel Core Ultra 7
- Memory16 GB
- Storage512 GB
- GraphicsNot available
Overview
- Display
- 40.6 cm (16")
- Resolution
- 1920 x 1200 pixels
- Processor
- Intel Core Ultra 7
- Memory
- 16 GB
- Storage
- 512 GB
- Graphics
- Not available
- Brand
- HP
- Category
- Laptop
- Model
- OmniBook 5 AI 16-af1037nr
- Part number
- B7ND0UA#ABA
- Also known as
- HP OmniBook 5 AI 16-af1037nr Intel Core Ultra 7 255U Laptop 40.6 cm (16") 2K 16 GB LPDDR5x-SDRAM 512 GB SSD Wi-Fi 6E (802.11ax) Windows 11 Home Silver
Specifications
122 specifications in 20 groups
Design
| Specification | Value |
|---|---|
| Product type | Laptop |
| Product colour | Silver |
| Colour name | Glacier silver |
| Form factor | Clamshell |
| Market positioning | Premium |
| Introduction year | 2025 |
| Original brand name | HP |
Display
| Specification | Value |
|---|---|
| Display diagonal | 40.6 cm (16") |
| Display resolution | 1920 x 1200 pixels |
| Touchscreen | No |
| HD type | 2K |
| Panel type | IPS |
| Anti-glare screen | Yes |
| Display brightness | 300 cd/m² |
| Colour gamut | 62.5% |
| Display diagonal (metric) | 40.6 cm |
| RGB colour space | sRGB |
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel Core Ultra 7 |
| Processor generation | Intel Core Ultra (Series 2) |
| Processor model | 255U |
| Processor cores | 12 |
| Processor threads | 14 |
| Processor boost frequency | 5.2 GHz |
| Performance cores | 2 |
| Efficient cores | 8 |
| Low Power Efficient-cores | 2 |
| Performance-core Max Turbo Frequency | 5.2 GHz |
| Efficient-core Max Turbo Frequency | 4.2 GHz |
| Low Power Efficient-core Max Turbo Frequency | 2.4 GHz |
| Performance-core base frequency | 2 GHz |
| Efficient-core base frequency | 1.7 GHz |
| Low Power Efficient-core Base Frequency | 700 MHz |
| Processor cache | 12 MB |
| Processor cache type | Smart Cache |
| Processor socket | BGA 2049 |
| Maximum turbo power | 57 W |
| Processor base power | 15 W |
Neural processor unit (NPU)
| Specification | Value |
|---|---|
| Neural processor unit (NPU) | Intel AI Boost |
| Sparsity support | Yes |
| Windows Studio effects support | Yes |
| AI software frameworks supported by NPU | DirectML, ONNX RT, OpenVINO, Windows ML |
| Total processor performance up to | 24 TOPs |
| NPU performance up to | 12 TOPs |
| GPU performance up to | 8 TOPs |
Memory
| Specification | Value |
|---|---|
| Internal memory | 16 GB |
| Internal memory type | LPDDR5x-SDRAM |
| Memory clock speed | 7467 MHz |
| Memory form factor | On-board |
| Maximum internal memory | 16 GB |
| Memory data transfer rate | 7467 MT/s |
Storage
| Specification | Value |
|---|---|
| Total storage capacity | 512 GB |
| Storage media | SSD |
| Total SSDs capacity | 512 GB |
| Number of SSDs installed | 1 |
| SSD capacity | 512 GB |
| NVMe | Yes |
| SSD interface | PCI Express 4.0 |
| SSD form factor | M.2 |
| Optical drive type | No |
Graphics
| Specification | Value |
|---|---|
| On-board graphics card | Yes |
| Discrete graphics card | No |
| Discrete graphics card model | Not available |
| On-board GPU manufacturer | Intel |
| On-board graphics card family | Intel® Graphics |
| On-board graphics card model | Intel® Graphics |
Audio
| Specification | Value |
|---|---|
| Audio system | DTS:X Ultra |
| Number of built-in speakers | 2 |
Camera
| Specification | Value |
|---|---|
| Front camera | Yes |
| Front camera HD type | Full HD |
| Infrared (IR) camera | Yes |
Network
| Specification | Value |
|---|---|
| Mobile network connection | No |
| Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
| Wi-Fi standards | Wi-Fi 6E (802.11ax) |
| Antenna type | 2x2 |
| WLAN controller manufacturer | Intel |
| WLAN controller model | Intel Wi-Fi 6E AX211 |
| Bluetooth | Yes |
| Bluetooth version | 5.3 |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 2 |
| HDMI ports quantity | 1 |
| HDMI version | 2.1 |
| Combo headphone/mic port | Yes |
| USB Type-C DisplayPort Alternate Mode | Yes |
| USB Sleep-and-Charge | Yes |
Keyboard
| Specification | Value |
|---|---|
| Pointing device | Touchpad |
| Keyboard backlit | Yes |
| Numeric keypad | Yes |
| Full-size keyboard | Yes |
| Keyboard colour name | soft grey |
Software
| Specification | Value |
|---|---|
| Operating system installed | Windows 11 Home |
Brand-specific features
| Specification | Value |
|---|---|
| HP speaker type | HP Dual Speakers |
| HP front camera | HP TrueVision FHD IR |
| HP segment | Home |
Battery
| Specification | Value |
|---|---|
| Battery technology | Lithium Polymer (LiPo) |
| Number of battery cells | 3 |
| Battery capacity | 59 Wh |
| Battery life (max) | 13 h |
| Fast charging | Yes |
| Fast charging time (50%) | 30 min |
Power
| Specification | Value |
|---|---|
| AC adapter power | 65 W |
| AC adapter frequency | 50 - 60 Hz |
| AC adapter input voltage | 100 - 240 V |
| USB Type-C charging port | Yes |
| USB Power Delivery (USB PD) | Yes |
Security
| Specification | Value |
|---|---|
| Trusted Platform Module (TPM) | Yes |
| Password protection | Yes |
| Password protection type | BIOS, Power on |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 1.77 kg |
| Width | 357.7 mm |
| Depth | 254.8 mm |
| Height (front) | 1.79 cm |
| Height (rear) | 1.86 cm |
Packaging data
| Specification | Value |
|---|---|
| Package width | 63 mm |
| Package depth | 504 mm |
| Package height | 305 mm |
| Package weight | 2.52 kg |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
