HP EliteBook Folio G1 Win10 CH Touch

Model EliteBook Folio G1 Win10 CH TouchPart no. X2F46ES

145 specifications Checked 3 days ago

Display31.8 cm (12.5")
Resolution3840 x 2160 pixels
ProcessorIntel® Core™ m5
Memory8 GB
Storage512 GB
OSWindows 10 Home

See all specifications

Overview

Display: 31.8 cm (12.5")
Resolution: 3840 x 2160 pixels
Processor: Intel® Core™ m5
Memory: 8 GB
Storage: 512 GB
OS: Windows 10 Home

Brand: HP
Category: Laptop
Model: EliteBook Folio G1 Win10 CH Touch
Part number: X2F46ES
Also known as: HP EliteBook Folio G1 Win10 CH Touch

Specifications

145 specifications in 20 groups

Design

Specification	Value
Country of origin	China

Display

Specification	Value
Display diagonal	31.8 cm (12.5")
Display resolution	3840 x 2160 pixels
Touchscreen	Yes
Panel type	IPS
Native aspect ratio	16:9
Display surface	Gloss

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Core™ m5
Processor generation	6th gen Intel® Core™ m5
Processor model	m5-6Y54
Processor cores	2
Processor threads	4
Processor boost frequency	2.7 GHz
Processor frequency	1.1 GHz
Processor cache	4 MB
Processor cache type	Smart Cache
L3 cache	4 MB
L2 cache	0.512 MB
Processor socket	BGA 1515
Processor lithography	14 nm
Processor operating modes	32-bit, 64-bit
Processor series	Intel Core m5-6Y Series
Processor codename	Skylake
Bus type	OPI
Stepping	D1
Thermal Design Power (TDP)	4.5 W
Configurable TDP-up	7 W
Configurable TDP-down	3.5 W
Tjunction	100 °C
Maximum number of PCI Express lanes	10
PCI Express configurations	1x2+2x1, 2x2, 1x4, 4x1
PCI Express slots version	3.0
ECC supported by processor	No

Memory

Specification	Value
Internal memory	8 GB
Internal memory type	LPDDR3-SDRAM
Memory clock speed	1866 MHz
Memory form factor	On-board
Maximum internal memory	8 GB

Storage

Specification	Value
Storage media	SSD
Total SSDs capacity	512 GB
SSD capacity	512 GB
SSD interface	SATA III
SSD form factor	M.2
Optical drive type	No
Card reader integrated	No

Graphics

Specification	Value
On-board graphics card	Yes
On-board graphics card family	Intel® HD Graphics
On-board graphics card model	Intel® HD Graphics 515
Maximum on-board graphics card memory	1.74 GB
On-board graphics card base frequency	300 MHz
On-board graphics card dynamic frequency (max)	900 MHz
On-board graphics card DirectX version	12.0
On-board graphics card OpenGL version	4.4
On-board graphics card ID	0x191E

Camera

Specification	Value
Front camera signal format	720p

Network

Specification	Value
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Antenna type	2x2
WLAN controller model	Intel Dual Band Wireless-AC 8260
Ethernet LAN	No
Bluetooth version	4.2
WWAN	Not installed

Ports & interfaces

Specification	Value
USB 2.0 ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	2
Ethernet LAN (RJ-45) ports	0
HDMI ports quantity	0
DisplayPorts quantity	0
VGA (D-Sub) ports quantity	0
Thunderbolt 3 ports quantity	2
Combo headphone/mic port	Yes
Docking connector	Yes

Performance

Specification	Value
Accelerometer	No
Ambient light sensor	No
Electronic compass	No
GPS (satellite)	No
Gyroscope	No
Orientation sensor	No
Proximity sensor	No

Keyboard

Specification	Value
Pointing device	Clickpad
Keyboard backlit	Yes
Keyboard layout	QWERTZ
Keyboard language	Swiss
Number of pointing stick buttons	1

Software

Specification	Value
Operating system installed	Windows 10 Home
Operating system architecture	64-bit

Processor special features

Specification	Value
Intel® Wireless Display (Intel® WiDi)	Yes
CPU configuration (max)	1
Embedded options available	No
Enhanced Intel SpeedStep Technology	Yes
Execute Disable Bit	Yes
Graphics & IMC lithography	14 nm
Idle States	Yes
Intel 64	Yes
Intel Clear Video Technology	Yes
Intel Enhanced Halt State	Yes
Intel Flex Memory Access	Yes
Intel Secure Key Technology version	1.00
Intel Small Business Advantage (SBA) version	1.00
Intel Smart Response Technology version	1.00
Intel Software Guard Extensions (Intel SGX)	Yes
Intel Stable Image Platform Program (SIPP)	No
Intel Stable Image Platform Program (SIPP) version	0.00
Intel TSX-NI	No
Intel TSX-NI version	1.00
Intel Trusted Execution Technology	No
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Intel® Clear Video HD Technology (Intel® CVT HD)	Yes
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)	Yes
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® InTru™ 3D Technology	Yes
Intel® Insider™	Yes
Intel® My WiFi Technology (Intel® MWT)	Yes
Intel® OS Guard	Yes
Intel® Quick Sync Video Technology	Yes
Intel® Secure Key	Yes
Intel® Small Business Advantage (Intel® SBA)	Yes
Intel® Smart Cache	Yes
Intel® Smart Response Technology	Yes
Intel® Turbo Boost Technology	2.0
Processor ARK ID	88202
Processor code	SR2EM
Processor package size	20 X 16.5 mm
Supported instruction sets	SSE4.1, SSE4.2, AVX 2.0
Thermal Monitoring Technologies	Yes
Conflict-Free processor	Yes

Battery

Specification	Value
Number of battery cells	4

Power

Specification	Value
AC adapter power	45 W
DC-in jack	Yes

Security

Specification	Value
Cable lock slot	No
Fingerprint reader	No
Trusted Platform Module (TPM)	Yes

Weight & dimensions

Specification	Value
Weight	1.05 kg
Width	291 mm
Depth	210 mm
Height (front)	1.3 cm
Height (rear)	1.5 cm

Video

Specification	Value
External video modes non-interlaced resolution with max. refresh rate	4096 x 2160 pixels
External video modes refresh rate (max)	60 Hz

Packaging content

Specification	Value
Docking station included	Yes
Stylus pen	No

Other features

Specification	Value
Number of WLAN antennas	2
Power adapter weight	180 g
