HP EliteBook 8530w Mobile Workstation (ENERGY STAR)

Model EliteBook 8530w Mobile Workstation (ENERGY STAR)Part no. FU466EA#ABHEAN 884420722380

141 specifications Checked 3 days ago

Display39.1 cm (15.4")
Resolution1680 x 1050 pixels
ProcessorIntel® Core™2 Duo
Memory2 GB
Storage250 GB
GraphicsAMD Mobility FireGL V5700

See all specifications

Overview

Display: 39.1 cm (15.4")
Resolution: 1680 x 1050 pixels
Processor: Intel® Core™2 Duo
Memory: 2 GB
Storage: 250 GB
Graphics: AMD Mobility FireGL V5700

Brand: HP
Category: Laptop
Model: EliteBook 8530w Mobile Workstation (ENERGY STAR)
Part numbers: FU466EA#ABH, FU461EA#ABH, FU462EA#ABH, FU462EA#AKD?ADVANCEDDOC, FU462EA#AKD?PORTREP, NU915AW#ABH +34 more
EAN / UPC: 884420722380, 884420812319, 884420812326, 884420812333 +56 more
Also known as: HP EliteBook 8530w Mobile Workstation (ENERGY STAR) Intel® Core™2 Duo P8600 39.1 cm (15.4") 2 GB DDR2-SDRAM 250 GB AMD Mobility FireGL V5700 Windows Vista Busin

Specifications

141 specifications in 22 groups

Design

Specification	Value
Country of origin	China

Display

Specification	Value
Display diagonal	39.1 cm (15.4")
Display resolution	1680 x 1050 pixels
Native aspect ratio	16:10
Display surface	Matt

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Core™2 Duo
Processor model	P8600
Processor cores	2
Processor threads	2
Processor frequency	2.4 GHz
Processor cache	3 MB
Processor cache type	L2
Processor front side bus	1066 MHz
Processor socket	Socket 479
Processor lithography	45 nm
Processor operating modes	64-bit
Processor series	Intel Core 2 Duo P8000 Series
Processor codename	Penryn
Bus type	FSB
FSB Parity	No
Stepping	R1
Thermal Design Power (TDP)	25 W
Tjunction	105 °C
Number of Processing Die Transistors	410 M
Processing Die size	107 mm²
CPU multiplier (bus/core ratio)	9
ECC supported by processor	No
Processor technology	Intel Centrino 2 w/ vPro

Memory

Specification	Value
Internal memory	2 GB
Internal memory type	DDR2-SDRAM
Memory slots	2x SO-DIMM
Maximum internal memory	8 GB

Storage

Specification	Value
Total storage capacity	250 GB
HDD interface	SATA
HDD speed	7200 RPM
Optical drive type	DVD±RW
Card reader integrated	Yes
Maximum HDD capacity	80 GB

Graphics

Specification	Value
Discrete graphics card	Yes
Discrete graphics card model	AMD Mobility FireGL V5700
Discrete graphics card memory	0.25 GB

Audio

Specification	Value
Audio system	High Definition Audio
Number of built-in speakers	2
Audio included	High Definition Audio, stereo speakers, stereo headphone/line out, stereo microphone in, integrated dual-microphone array

Network

Specification	Value
Networking features	Gigabit Ethernet
Wireless technology	IEEE 802.11a/b/g/n, Y
Bluetooth	Yes
Bluetooth version	2.0+EDR

Ports & interfaces

Specification	Value
USB 2.0 ports quantity	4
eSATA ports quantity	1
Ethernet LAN (RJ-45) ports	1
HDMI ports quantity	1
DVI port	No
VGA (D-Sub) ports quantity	1
Firewire (IEEE 1394) ports	1
Headphone outputs	1
S/PDIF out port	No
Microphone in	Yes
Docking connector	Yes
ExpressCard slot	Yes
CardBus PCMCIA slots quantity	0
CardBus PCMCIA slot type	No
SmartCard slot	Yes
Modem (RJ-11) ports	1
TV-in port	No
TV-out	No
PS/2 ports quantity	0
Parallel ports quantity	0
Serial ports quantity	0
I/O ports	4 USB 2.0 ports, VGA, eSATA, stereo microphone in, stereo headphone/line out, Firewire (1394a), HDMI, power connector, docking connector, secondary battery connector, RJ-11, RJ-45

Performance

Specification	Value
Motherboard chipset	Intel® PM45 Express

Keyboard

Specification	Value
Pointing device	Touchpad
Keyboard layout	QWERTY
Keyboard type	Full-sized

Software

Specification	Value
Operating system installed	Windows Vista Business
Bundled software	HP Recovery Manager (Vista Only), HP Client Manager Software, HP Client Configuration Management Agent, HP OpenView PC Configuration Management Solutions, HP Performance Tuning Framework
Compatible operating systems	Genuine Windows XP Professional, SuSe Linux Enterprise Desktop 10

Processor special features

Specification	Value
Intel® Wireless Display (Intel® WiDi)	No
Embedded options available	No
Enhanced Intel SpeedStep Technology	Yes
Execute Disable Bit	Yes
Idle States	Yes
Intel 64	Yes
Intel Clear Video Technology	No
Intel Demand Based Switching	No
Intel Dual Display Capable Technology	No
Intel Enhanced Halt State	Yes
Intel FDI Technology	No
Intel Fast Memory Access	No
Intel Flex Memory Access	No
Intel Rapid Storage Technology	No
Intel Trusted Execution Technology	Yes
Intel VT-x with Extended Page Tables (EPT)	No
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	No
Intel® AES New Instructions (Intel® AES-NI)	No
Intel® Anti-Theft Technology (Intel® AT)	No
Intel® Clear Video HD Technology (Intel® CVT HD)	No
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)	No
Intel® Hyper Threading Technology (Intel® HT Technology)	No
Intel® InTru™ 3D Technology	No
Intel® Insider™	No
Intel® My WiFi Technology (Intel® MWT)	No
Intel® Quick Sync Video Technology	No
Intel® Turbo Boost Technology	No
Processor ARK ID	35568
Processor code	SLGDZ
Processor package size	35 x 35 mm
Thermal Monitoring Technologies	No
Conflict-Free processor	No

Battery

Specification	Value
Number of battery cells	8
Battery life (max)	5 h

Power

Specification	Value
DC-in jack	Yes

Security

Specification	Value
Trusted Platform Module (TPM)	Yes
Security management description	McAfee Security Solution, Kensington Lock slot, HP Privacy Filter (optional)

Operational conditions

Specification	Value
Operating temperature (T-T)	0 - 80 °C
Storage temperature (T-T)	-40 - 80 °C
Operating relative humidity (H-H)	10 - 90%
Storage relative humidity (H-H)	5 - 95%

Certificates

Specification	Value
Certification	MCAD: AutoDesk (AutoCAD, Inventor, Revit, Alias Studio, Map 3D, Civil 3D), Bentley (In Roads XM, MicroStation, Navigator), CEI, CoCreate OneSpace, Dassault CATIA V5, ICEM Surf, Intelligent Light, MSC Software (MSC.Patran, SimXpert), PTC Pro/ENGINEER Wildfire, Sensable, Siemans PLMS (NX, NX I-deas, S

Weight & dimensions

Specification	Value
Weight	2.86 kg
Width	355 mm
Depth	263.5 mm
Height	28.2 mm

Hard drive

Specification	Value
Storage drive type	250 GB 7200 rpm SATA
Storage drive controller	SATA (7200 rpm) SATA (5400 rpm) Solid State Drive

Video

Specification	Value
Video card features	ATI Mobility FireGL V5700

Other features

Specification	Value
Infrared data port	No
Battery type	8-cell (73 WHr) Lithium-Ion battery
Minimum storage drive space	250 GB
Power requirements	External 120W HP Smart AC adapter, HP Fast Charge Technology 8-cell (73 WHr) Lithium-Ion battery, optional HP (52 WHr) Extended Life Battery, optional HP (95 WHr) Ultra-Capacity Battery
Wake-on-Ring ready	Yes
Internal modem	Yes
Modem speed	56 Kbit/s
Modem type	V.92
Intel segment tagging	Enterprise
Docking solution	HP Docking Station, HP Advanced Docking Station, HP Monitor Stand, HP Adjustable Notebook Stand (all sold separately)
Expansion slots	Slots available for additional devices: 1 ExpressCard/54 slot, Media Card Reader
Protection tools	HP ProtectTools, TPM Embedded Security Chip 1.2, HP Fingerprint Sensor, HP Disk Sanitizer, integrated Smart Card Reader
Supplied AC adapter type	AC
