-RW Multibay Graphics WXP HE Notebook PC

Model Compaq nx8220 Intel Pentium-M 740 512M/80G 15.4" WXGA WVA DVD+/-RW Multibay Graphics WXP HE Notebook PCPart no. PY544EA#ABH

69 specifications Checked yesterday

Display39.1 cm (15.4")
Resolution1200 x 800 pixels
Memory0.5 GB
Storage80 GB
GraphicsAMD Mobility Radeon X600
Weight2.6 kg

See all specifications

Overview

Display: 39.1 cm (15.4")
Resolution: 1200 x 800 pixels
Memory: 0.5 GB
Storage: 80 GB
Graphics: AMD Mobility Radeon X600
Weight: 2.6 kg

Brand: HP
Category: Laptop
Model: Compaq nx8220 Intel Pentium-M 740 512M/80G 15.4" WXGA WVA DVD+/-RW Multibay Graphics WXP HE Notebook PC
Part number: PY544EA#ABH
Also known as: HP Compaq nx8220 Intel Pentium-M 740 512M/80G 15.4" WXGA WVA DVD+/-RW Multibay Graphics WXP HE Notebook PC 39.1 cm (15.4") 0.5 GB DDR2-SDRAM 80 GB AMD Mobility

Specifications

69 specifications in 16 groups

Design

Specification	Value
Country of origin	China

Display

Specification	Value
Display diagonal	39.1 cm (15.4")
Display resolution	1200 x 800 pixels
HD type	Not supported
Native aspect ratio	16:10

Processor

Specification	Value
Processor manufacturer	Intel
Processor frequency	1.73 GHz
Processor cache	2 MB
Processor cache type	L2
Processor front side bus	533 MHz
Processor technology	Intel SpeedStep

Memory

Specification	Value
Internal memory	0.5 GB
Internal memory type	DDR2-SDRAM
Memory slots	2x SO-DIMM
Maximum internal memory	2 GB

Storage

Specification	Value
Total storage capacity	80 GB
HDD speed	5400 RPM
Optical drive type	DVD±RW

Graphics

Specification	Value
Discrete graphics card	Yes
Discrete graphics card model	AMD Mobility Radeon X600
Maximum graphics card memory	0.064 GB
Graphics card interface	PCI Express

Audio

Specification	Value
Audio system	HP Premier, Sound 16-bit

Network

Specification	Value
Networking features	Gigabit Ethernet, Wireless LAN, Bluetooth
Wireless technology	mini-PCI Intel, Y
Ethernet LAN data rates	10,100,1000 Mbit/s
Wireless compliance	IEEE 802.11g, IEEE 802.11b

Ports & interfaces

Specification	Value
USB 2.0 ports quantity	3
Ethernet LAN (RJ-45) ports	1
DVI port	No
VGA (D-Sub) ports quantity	1
Firewire (IEEE 1394) ports	1
Headphone outputs	1
S/PDIF out port	No
Microphone in	Yes
Docking connector	No
CardBus PCMCIA slots quantity	1
CardBus PCMCIA slot type	Type II
SmartCard slot	Yes
Modem (RJ-11) ports	1
TV-in port	No
TV-out	Yes
TV-out type	S-Video
PS/2 ports quantity	0
Parallel ports quantity	0
Serial ports quantity	0
I/O ports	1x HP Travel Battery 1x Docking
USB 1.1 ports quantity	0

Performance

Specification	Value
Motherboard chipset	Intel® 915PM Express

Keyboard

Specification	Value
Pointing device	Touchpad
Keyboard layout	QWERTY

Software

Specification	Value
Bundled software	InterVideo WinDVD Creator – DVD Authoring
Compatible operating systems	Microsoft Windows XP Home

Power

Specification	Value
AC adapter power	90 W
DC-in jack	Yes

Operational conditions

Specification	Value
Operating temperature (T-T)	10 - 35 °C
Storage temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	10 - 90%
Storage relative humidity (H-H)	5 - 90%

Weight & dimensions

Specification	Value
Weight	2.6 kg
Dimensions (WxDxH)	356 x 264 x 28 mm

Other features

Specification	Value
Security features	HP ProtectTools HP Drivelock
Infrared data port	Yes
Wake-on-LAN ready	No
Wake-on-Ring ready	No
Internal modem	Yes
Modem speed	56 Kbit/s
Modem type	V.92
Expansion slots	1x Type I/II PCMCIA (16/32-bit) 1x Integrated Smart Card Reader 1x Secure Digital
