AI 16-ay0502sa
Model AI 16-ay0502saPart no. BL1E2EAEAN 199251203893
159 specifications Checked today
- Display40.6 cm (16")
- Resolution2560 x 1600 pixels
- ProcessorIntel Core Ultra 5
- Memory16 GB
- Storage1 TB
- GraphicsNot available
Overview
- Display
- 40.6 cm (16")
- Resolution
- 2560 x 1600 pixels
- Processor
- Intel Core Ultra 5
- Memory
- 16 GB
- Storage
- 1 TB
- Graphics
- Not available
- Brand
- HP
- Category
- Laptop
- Model
- AI 16-ay0502sa
- Part number
- BL1E2EA
- EAN / UPC
- 199251203893
- Also known as
- HP OmniBook 7 AI 16-ay0502sa Intel Core Ultra 5 225H Laptop 40.6 cm (16") 2.5K 16 GB DDR5-SDRAM 1 TB SSD Wi-Fi 6E (802.11ax) Windows 11 Home AI PC Silver
Specifications
159 specifications in 26 groups
Design
| Specification | Value |
|---|---|
| Product type | Laptop |
| Product colour | Silver |
| Colour name | Glacier silver |
| Form factor | Clamshell |
| Market positioning | Premium |
| Introduction year | 2025 |
| Country of origin | China, Thailand |
| Original brand name | HP |
Display
| Specification | Value |
|---|---|
| Display diagonal | 40.6 cm (16") |
| Display resolution | 2560 x 1600 pixels |
| Touchscreen | No |
| HD type | 2.5K |
| Panel type | IPS |
| Native aspect ratio | 16:10 |
| Anti-glare screen | Yes |
| Display bezel technology | Micro-Edge |
| Display brightness | 500 cd/m² |
| Colour gamut | 100% |
| Display diagonal (metric) | 40.6 cm |
| RGB colour space | sRGB |
| Display response rise/fall | 7 ms |
| Maximum refresh rate | 240 Hz |
| sRGB coverage (typical) | 100% |
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel Core Ultra 5 |
| Processor generation | Intel Core Ultra (Series 2) |
| Processor model | 225H |
| Processor cores | 14 |
| Processor threads | 14 |
| Processor boost frequency | 4.9 GHz |
| Performance cores | 4 |
| Efficient cores | 8 |
| Low Power Efficient-cores | 2 |
| Performance-core Max Turbo Frequency | 4.9 GHz |
| Efficient-core Max Turbo Frequency | 4.3 GHz |
| Low Power Efficient-core Max Turbo Frequency | 2.5 GHz |
| Performance-core base frequency | 1.7 GHz |
| Efficient-core base frequency | 1.3 GHz |
| Low Power Efficient-core Base Frequency | 700 MHz |
| Processor cache | 18 MB |
| Processor cache type | L3 |
| Maximum turbo power | 115 W |
| Processor base power | 28 W |
Neural processor unit (NPU)
| Specification | Value |
|---|---|
| Neural processor unit (NPU) | Intel AI Boost |
| Sparsity support | Yes |
| Windows Studio effects support | Yes |
| AI software frameworks supported by NPU | DirectML, OpenVINO, Windows ML, ONNX RT, WebNN |
| Total processor performance up to | 83 TOPs |
| NPU performance up to | 13 TOPs |
| GPU performance up to | 63 TOPs |
Memory
| Specification | Value |
|---|---|
| Internal memory | 16 GB |
| Internal memory type | DDR5-SDRAM |
| Memory clock speed | 5600 MHz |
| Memory form factor | On-board |
| Memory layout (slots x size) | Not available |
| Memory slots (available) | 0 |
| Maximum internal memory | 16 GB |
Storage
| Specification | Value |
|---|---|
| Total storage capacity | 1 TB |
| Storage media | SSD |
| Total SSDs capacity | 1 TB |
| Number of SSDs installed | 1 |
| SSD capacity | 1 TB |
| NVMe | Yes |
| SSD interface | PCI Express 4.0 |
| SSD form factor | M.2 |
| Optical drive type | No |
Graphics
| Specification | Value |
|---|---|
| On-board graphics card | Yes |
| Discrete graphics card | No |
| Discrete graphics card model | Not available |
| On-board GPU manufacturer | Intel |
| On-board graphics card family | Intel Arc Graphics |
| On-board graphics card model | Intel Arc 130T |
Audio
| Specification | Value |
|---|---|
| Audio system | DTS:X Ultra |
| Built-in speaker(s) | Yes |
| Number of built-in speakers | 2 |
| Built-in microphone | Yes |
| Number of microphones | 2 |
Camera
| Specification | Value |
|---|---|
| Front camera | Yes |
| Front camera resolution (numeric) | 5 MP |
| Infrared (IR) camera | Yes |
Network
| Specification | Value |
|---|---|
| Mobile network connection | No |
| Wi-Fi | Yes |
| Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
| Wi-Fi standards | Wi-Fi 6E (802.11ax) |
| Antenna type | 2x2 |
| WLAN controller manufacturer | Intel |
| WLAN controller model | Intel Wi-Fi 6E AX211 |
| Bluetooth | Yes |
| Bluetooth version | 5.3 |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| USB4 Gen 3x2 ports quantity | 1 |
| HDMI ports quantity | 1 |
| HDMI version | 2.1 |
| Thunderbolt 4 ports quantity | 1 |
| Intel® Thunderbolt 4 | Yes |
| Combo headphone/mic port | Yes |
| Microphone in | Yes |
| USB Type-C DisplayPort Alternate Mode | Yes |
| USB Sleep-and-Charge | Yes |
| USB Sleep-and-Charge ports | 2 |
Performance
| Specification | Value |
|---|---|
| Motherboard chipset | Intel SoC |
Keyboard
| Specification | Value |
|---|---|
| Pointing device | Touchpad |
| Keyboard backlit | Yes |
| Numeric keypad | Yes |
| Full-size keyboard | Yes |
| Keyboard colour name | soft grey |
Software
| Specification | Value |
|---|---|
| Operating system installed | Windows 11 Home |
| Pre-installed software | Poly Camera Pro, 1 month trial for new Microsoft 365 customers, McAfee Online Protection 30-day trial; 1-month Adobe free trial offer; PC Game Pass 3-month trial |
| Trial software | 100 GB Dropbox storage for 3 months |
Processor special features
| Specification | Value |
|---|---|
| Intel® Turbo Boost Technology | Yes |
Brand-specific features
| Specification | Value |
|---|---|
| HP Audio Boost | Yes |
| HP speaker type | HP Dual Speakers |
| HP Imagepad | Yes |
| HP Security tools | Mic mute key; Camera privacy shutter; Trusted Platform Module (Firmware TPM) support |
| HP Software provided | HP Support Assistant; HP Connection Optimizer; HP Enhanced Lighting |
| HP Artificial Intelligence | AI PC |
| HP segment | Home |
| HP GTIN (EAN/UPC) | 199251203893 |
Battery
| Specification | Value |
|---|---|
| Battery technology | Lithium Polymer (LiPo) |
| Number of battery cells | 4 |
| Battery capacity | 70 Wh |
| Battery life (max) | 11 h |
| Continuous video playback time (max) | 16.5 h |
| Fast charging | Yes |
| Fast charging time (50%) | 30 min |
Power
| Specification | Value |
|---|---|
| AC adapter power | 100 W |
| AC adapter frequency | 50 - 60 Hz |
| AC adapter input voltage | 100 - 240 V |
| USB Type-C charging port | Yes |
| USB Power Delivery (USB PD) | Yes |
Security
| Specification | Value |
|---|---|
| Trusted Platform Module (TPM) | Yes |
| Password protection | Yes |
| Password protection type | BIOS, Power on |
Sustainability
| Specification | Value |
|---|---|
| Sustainability certificates | ENERGY STAR, EPEAT, EPEAT Gold |
| Sustainable technologies and materials | Ocean-bound plastic in speaker enclosure(s) and bezel; Recycled metal in cover, keyboard frame, base and hinge cap(s); Keyboard keycaps and scissors contain post-consumer recycled plastic |
| Sustainability compliance | Yes |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 1.91 kg |
| Width | 357.8 mm |
| Depth | 254.8 mm |
| Height | 15 mm |
Packaging data
| Specification | Value |
|---|---|
| Package width | 80 mm |
| Package depth | 423 mm |
| Package height | 303 mm |
| Package weight | 3.42 kg |
Carbon footprint
| Specification | Value |
|---|---|
| Carbon emissions, end-of-life (kg of CO2e) | 0.699 |
| Carbon emissions, logistics (kg of CO2e) | 6.097 |
| Carbon emissions, manufacturing (kg of CO2e) | 288.758 |
| Total carbon emissions, w/o use phase (kg of CO2e) | 12.235 |
| Total carbon footprint (kg of CO2e) | 307.789 |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
| Keyboard included | Yes |
Other features
| Specification | Value |
|---|---|
| Manufacturer warranty | 1 year (1/1/0) limited warranty includes 1 year of parts and labor. No on-site repair. Terms and conditions vary by country. Certain restrictions and exclusions apply. |
| Supplied AC adapter type | Sandblasted anodized finish |
| UNSPSC-code | 43211503 |
Technical details
| Specification | Value |
|---|---|
| General Product Safety Regulation (GPSR) URL | https://support.hp.com/us-en/document/ish_6126692-6126777-16?openCLC=true ; HP REG 23010, 08028 Barcelona, Spain ; reg@hp.com |
