HP Pavilion A9E63EA netbook Intel Atom® N2800

25.6 cm (10.1") 1 GB DDR3-SDRAM 320 GB Windows 7 Starter Pink QWERTY

Model A9E63EAEAN 886112630553

119 specifications Checked 3 days ago

Display25.6 cm (10.1")
Resolution1024 x 600 pixels
ProcessorIntel Atom®
Memory1 GB
Storage320 GB
TypeNetbook

See all specifications

Overview

Display: 25.6 cm (10.1")
Resolution: 1024 x 600 pixels
Processor: Intel Atom®
Memory: 1 GB
Storage: 320 GB
Type: Netbook

Brand: HP
Category: Laptop
Model: A9E63EA
Part number: A9E63EA
EAN / UPC: 886112630553
Also known as: HP Pavilion A9E63EA netbook Intel Atom® N2800 25.6 cm (10.1") 1 GB DDR3-SDRAM 320 GB Windows 7 Starter Pink QWERTY

Specifications

119 specifications in 19 groups

Design

Specification	Value
Product type	Netbook
Product colour	Pink
Country of origin	China

Display

Specification	Value
Display diagonal	25.6 cm (10.1")
Display resolution	1024 x 600 pixels
Display number of colours	16.78 million colours
LED backlight	Yes
Native aspect ratio	5:3
Display surface	Matt

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel Atom®
Processor model	N2800
Processor cores	2
Processor threads	4
Processor frequency	1.86 GHz
System bus rate	2.5 GT/s
Processor cache	1 MB
Processor cache type	L2
Processor socket	BGA 559
Processor lithography	32 nm
Processor operating modes	64-bit
Processor series	Intel Atom N2800 Series
Processor codename	Cedarview
Bus type	DMI
FSB Parity	No
Stepping	B3
Motherboard southbridge	Intel ICH8M
Thermal Design Power (TDP)	6.5 W
ECC supported by processor	No

Memory

Specification	Value
Internal memory	1 GB
Internal memory type	DDR3-SDRAM
Memory layout (slots x size)	1 x 1 GB
Maximum internal memory	1 GB

Storage

Specification	Value
Total storage capacity	320 GB
Total HDDs capacity	320 GB
HDD capacity	320 GB
HDD interface	SATA
HDD speed	5400 RPM
Optical drive type	No

Graphics

Specification	Value
On-board graphics card	Yes
Graphics card family	Intel
On-board graphics card base frequency	640 MHz
Maximum graphics card memory	0.218 GB
Graphics card	GMA 3650

Audio

Specification	Value
Audio system	Beats Audio
Built-in microphone	Yes

Network

Specification	Value
Wi-Fi	Yes
Wireless technology	IEEE 802.11b/g/n
Ethernet LAN	Yes
Ethernet LAN data rates	10,100 Mbit/s
Bluetooth	Yes
Data network	Not supported
Cabling technology	10/100Base-T(X)

Ports & interfaces

Specification	Value
USB 2.0 ports quantity	3
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
eSATA ports quantity	0
Ethernet LAN (RJ-45) ports	1
HDMI ports quantity	0
VGA (D-Sub) ports quantity	1
Firewire (IEEE 1394) ports	0
Thunderbolt ports quantity	0
Headphone outputs	1
Microphone in	Yes
TV-out	No

Performance

Specification	Value
Motherboard chipset	Intel NM10
GPS (satellite)	No

Keyboard

Specification	Value
Pointing device	Touchpad
Keyboard layout	QWERTY

Software

Specification	Value
Operating system installed	Windows 7 Starter
Operating system architecture	32-bit
Trial software	Symantec Norton Internet Security
Bundled software	Microsoft Office Starter

Processor special features

Specification	Value
Intel® Wireless Display (Intel® WiDi)	No
Embedded options available	Yes
Enhanced Intel SpeedStep Technology	Yes
Execute Disable Bit	Yes
Intel 64	Yes
Intel Clear Video Technology	No
Intel Demand Based Switching	No
Intel Dual Display Capable Technology	No
Intel Enhanced Halt State	No
Intel FDI Technology	No
Intel Fast Memory Access	No
Intel Flex Memory Access	No
Intel Rapid Storage Technology	No
Intel Trusted Execution Technology	No
Intel VT-x with Extended Page Tables (EPT)	No
Intel Virtualization Technology (VT-x)	No
Intel Virtualization Technology for Directed I/O (VT-d)	No
Intel® AES New Instructions (Intel® AES-NI)	No
Intel® Anti-Theft Technology (Intel® AT)	No
Intel® Clear Video HD Technology (Intel® CVT HD)	No
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)	No
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® InTru™ 3D Technology	No
Intel® Insider™	No
Intel® My WiFi Technology (Intel® MWT)	No
Intel® Quick Sync Video Technology	No
Intel® Turbo Boost Technology	No
Physical Address Extension (PAE)	Yes
Processor ARK ID	58917
Processor code	SR0W1
Supported instruction sets	SSE2, SSE3, SSSE3
Thermal Monitoring Technologies	Yes
Conflict-Free processor	No

Battery

Specification	Value
Battery technology	Lithium-Ion (Li-Ion)
Number of battery cells	6

Power

Specification	Value
AC adapter power	40 W
AC adapter frequency	50 - 60 Hz
DC-in jack	Yes

Operational conditions

Specification	Value
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80%

Sustainability

Specification	Value
Sustainability certificates	EPEAT Silver, ENERGY STAR

Weight & dimensions

Specification	Value
Weight	1.38 kg
Width	268 mm
Depth	191 mm
Height	32.7 mm

Other features

Specification	Value
Power requirements	100 - 240 V
Supplied AC adapter type	AC
