HP 610 Intel® Core™2 Duo T5870

39.6 cm (15.6") 2 GB DDR2-SDRAM 160 GB Intel® GMA X3100 Windows Vista Home Premium

Model 610Part no. VC394EAEAN 884962851067

103 specifications Checked 3 days ago

Display39.6 cm (15.6")
Resolution1366 x 768 pixels
ProcessorIntel® Core™2 Duo
Memory2 GB
Storage160 GB
GraphicsIntel® GMA X3100

See all specifications

Overview

Display: 39.6 cm (15.6")
Resolution: 1366 x 768 pixels
Processor: Intel® Core™2 Duo
Memory: 2 GB
Storage: 160 GB
Graphics: Intel® GMA X3100

Brand: HP
Category: Laptop
Model: 610
Part numbers: VC394EA, NX545EA, NX546EA, NX538EA, NX538EA#ABH, NX545EA#ABH +3 more
EAN / UPC: 884962851067, 884962241318, 884962241387, 884962241394 +23 more
Also known as: HP 610 Intel® Core™2 Duo T5870 39.6 cm (15.6") 2 GB DDR2-SDRAM 160 GB Intel® GMA X3100 Windows Vista Home Premium

Specifications

103 specifications in 20 groups

Design

Specification	Value
Country of origin	China

Display

Specification	Value
Display diagonal	39.6 cm (15.6")
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Core™2 Duo
Processor model	T5870
Processor cores	2
Processor frequency	2 GHz
Processor cache	2 MB
Processor cache type	L2
Processor front side bus	800 MHz
Processor socket	LGA 3647 (Socket P)
Processor lithography	65 nm
Processor operating modes	64-bit
Processor series	Intel Core 2 Duo T5000 Series
FSB Parity	No
Stepping	M0
Thermal Design Power (TDP)	35 W
Tjunction	100 °C
Number of Processing Die Transistors	291 M
Processing Die size	143 mm²
CPU multiplier (bus/core ratio)	10

Memory

Specification	Value
Internal memory	2 GB
Internal memory type	DDR2-SDRAM
Memory layout (slots x size)	1 x 2 GB
Memory upgrade	4 GB

Storage

Specification	Value
Total storage capacity	160 GB
HDD interface	SATA
HDD speed	7200 RPM
Optical drive type	DVD Super Multi DL
Card reader integrated	Yes
Compatible memory cards	MMC, SD

Graphics

Specification	Value
Discrete graphics card	Yes
Discrete graphics card model	Intel® GMA X3100
Maximum graphics card memory	0.384 GB

Audio

Specification	Value
Audio system	High Definition Audio, mono speaker, stereo headphone/line out, stereo microphone in, integrated microphone
Number of built-in speakers	1
Audio included	High Definition Audio, mono speaker, stereo headphone/line out, stereo microphone in, integrated microphone

Optical drive

Specification	Value
LightScribe	Yes

Network

Specification	Value
Networking features	Marvell Ethernet (10/100 NIC)
Wireless technology	Intel 802.11a/b/g/n or Broadcom 802.11b/g, optional Bluetooth 2.1, HP Wireless Assistant, Y
Bluetooth	Yes
Bluetooth version	2.1+EDR

Ports & interfaces

Specification	Value
USB 2.0 ports quantity	3
Ethernet LAN (RJ-45) ports	1
HDMI ports quantity	0
DVI port	No
VGA (D-Sub) ports quantity	1
Firewire (IEEE 1394) ports	0
Headphone outputs	1
S/PDIF out port	No
Microphone in	Yes
Docking connector	No
ExpressCard slot	Yes
CardBus PCMCIA slots quantity	0
CardBus PCMCIA slot type	No
SmartCard slot	Yes
Modem (RJ-11) ports	1
TV-in port	No
TV-out	No
PS/2 ports quantity	0
Parallel ports quantity	0
Serial ports quantity	0
I/O ports	3 USB 2.0 ports, VGA, stereo microphone in, stereo headphone/line out, power connector, RJ-45, optional RJ-11

Keyboard

Specification	Value
Keyboard type	Full-sized

Software

Specification	Value
Operating system installed	Windows Vista Home Premium
Bundled software	HP Wireless Assistant, Windows Live Messenger, Windows Media Player 11, PDF Complete, HP Help and Support Center, Microsoft Office Ready with 60-day Office Professional 2007 Trial Edition (select models), McAfee Total Protection for Small Business software with free 60-day trial period, Intervideo W

Processor special features

Specification	Value
Embedded options available	No
Enhanced Intel SpeedStep Technology	Yes
Execute Disable Bit	Yes
Intel 64	Yes
Intel Demand Based Switching	No
Intel Trusted Execution Technology	No
Intel® Hyper Threading Technology (Intel® HT Technology)	No
Intel® Turbo Boost Technology	No
Processor ARK ID	37034
Processor code	SLAZR
Processor package size	35 x 35 mm

Battery

Specification	Value
Number of battery cells	6

Power

Specification	Value
DC-in jack	Yes

Security

Specification	Value
Cable lock slot	Yes
Cable lock slot type	Kensington
Security management description	McAfee Security Solution, Kensington Lock slot

Operational conditions

Specification	Value
Operating temperature (T-T)	5 - 35 °C
Storage temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	10 - 90%
Storage relative humidity (H-H)	5 - 95%

Weight & dimensions

Specification	Value
Weight	2.49 kg
Width	371.8 mm
Depth	254.3 mm
Height (front)	3.2 cm
Dimensions (WxDxH)	371.8 x 254.3 x 32 mm

Video

Specification	Value
Video card features	Intel GMA X3100

Other features

Specification	Value
Infrared data port	No
Power requirements	External 65W HP AC Adapter, HP Fast Charge 6-cell (47 WHr) Li-Ion battery
Internal modem	Yes
Modem speed	56 Kbit/s
Modem type	56K
Docking solution	HP USB 2.0 Docking Station, HP Essential USB Port Replicator, HP Basic Adjustable Stand (all sold separately)
Expansion slots	Slots available for additional devices: 1 ExpressCard/34 slot, 1 Secure Digital (SD)/MultiMedia Card (MMC) slot
Protection tools	HP Disk Sanitizer, DriveLock
Supplied AC adapter type	AC
