HP EliteBook 2540p Intel® Core™ i5 i5-520M

43.2 cm (17") 4 GB DDR3-SDRAM 320 GB HDD AMD FirePro M7820 Wi-Fi 4 (802.11n) Windows 7 Professional Black QWERTY

Model 2540pPart no. WK301EA-SB1-SE-MLEAN 885631241448

190 specifications Checked 2 days ago

Display43.2 cm (17")
Resolution1680 x 1050 pixels
ProcessorIntel® Core™ i5
Memory4 GB
Storage320 GB
GraphicsAMD FirePro M7820

See all specifications

Overview

Display: 43.2 cm (17")
Resolution: 1680 x 1050 pixels
Processor: Intel® Core™ i5
Memory: 4 GB
Storage: 320 GB
Graphics: AMD FirePro M7820

Brand: HP
Category: Laptop
Model: 2540p
Part numbers: WK301EA-SB1-SE-ML, WK301EA-SB1-BE-ML#AB, WK301EA-SB1-SE-ML#ABH, XN728ES-SB2-BE-ML#ABH, XN728ES-SB2-ES-ML#AB, VB845AV-SE-SB44-AS +27 more
EAN / UPC: 885631241448, 885631069967, 885631069974, 885631077269 +56 more
Also known as: HP EliteBook 2540p Intel® Core™ i5 i5-520M 43.2 cm (17") 4 GB DDR3-SDRAM 320 GB HDD AMD FirePro M7820 Wi-Fi 4 (802.11n) Windows 7 Professional Black QWERTY

Specifications

190 specifications in 24 groups

Design

Specification	Value
Product colour	Black
Country of origin	China

Display

Specification	Value
Display diagonal	43.2 cm (17")
Display resolution	1680 x 1050 pixels
Display number of colours	16.78 million colours
LED backlight	Yes
Native aspect ratio	16:10
Display surface	Matt

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Core™ i5
Processor generation	Intel® Core™ i5
Processor model	i5-520M
Processor cores	2
Processor threads	4
Processor boost frequency	2.93 GHz
Processor frequency	2.4 GHz
System bus rate	2.5 GT/s
Processor cache	3 MB
Processor cache type	Smart Cache
Processor socket	BGA 956
Processor lithography	32 nm
Processor operating modes	64-bit
Processor series	Intel Core i5-500 Mobile Series
Processor codename	Arrandale
Bus type	DMI
FSB Parity	No
Stepping	C2
Thermal Design Power (TDP)	35 W
Tjunction	105 °C
Maximum number of PCI Express lanes	16
PCI Express configurations	1x16
PCI Express slots version	2.0
Number of Processing Die Transistors	382 M
Processing Die size	81 mm²
CPU multiplier (bus/core ratio)	18
ECC supported by processor	No
Processor technology	Intel Centrino 2 w/ vPro

Memory

Specification	Value
Internal memory	4 GB
Internal memory type	DDR3-SDRAM
Memory clock speed	1333 MHz
Memory layout (slots x size)	2 x 2 GB
Memory slots	2x SO-DIMM
Maximum internal memory	16 GB
Memory upgrade	32 GB

Storage

Specification	Value
Total storage capacity	320 GB
Storage media	HDD
Total HDDs capacity	320 GB
Number of HDDs installed	1
HDD capacity	320 GB
HDD interface	SATA
HDD speed	7200 RPM
Optical drive type	DVD Super Multi DL
Card reader integrated	Yes
Maximum HDD capacity	320 GB

Graphics

Specification	Value
On-board graphics card	Yes
Discrete graphics card	Yes
Discrete graphics card model	AMD FirePro M7820
Graphics card family	ATI
Discrete graphics memory type	GDDR5
On-board graphics card family	Intel® HD Graphics
On-board graphics card model	Intel® HD Graphics
On-board graphics card base frequency	500 MHz
On-board graphics card dynamic frequency (max)	766 MHz

Audio

Specification	Value
Audio system	High Definition Audio
Number of built-in speakers	2
Built-in microphone	Yes
Audio included	High Definition Audio, stereo speakers, stereo headphone/line out, stereo microphone in, integrated dual-microphone array, touch-sensitive controls for volume up, volume down and mute

Optical drive

Specification	Value
LightScribe	Yes
Disc types supported	CD

Network

Specification	Value
Wi-Fi	Yes
Networking features	Intel Gigabit Network Connection (10/100/1000 NIC)
Wireless technology	Intel 802.11a/b/g/n; HP Integrated Module with Bluetooth 2.1 Wireless Technology
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Wi-Fi standards	802.11a, 802.11b, 802.11g
Ethernet LAN	Yes
Bluetooth	Yes
Bluetooth version	2.1+EDR
Cabling technology	10/100/1000Base-T(X)

Ports & interfaces

Specification	Value
USB 2.0 ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
eSATA/USB 2.0 ports quantity	0
eSATA/USB 3.2 Gen 1 (3.1 Gen 1) ports quantity	0
eSATA ports quantity	1
Ethernet LAN (RJ-45) ports	1
HDMI ports quantity	0
DisplayPorts quantity	1
DVI port	No
VGA (D-Sub) ports quantity	1
Firewire (IEEE 1394) ports	1
Headphone outputs	1
S/PDIF out port	No
Microphone in	Yes
Docking connector	Yes
ExpressCard slot	Yes
CardBus PCMCIA slots quantity	0
CardBus PCMCIA slot type	No
SmartCard slot	Yes
Modem (RJ-11) ports	1
TV-in port	No
TV-out	No
PS/2 ports quantity	0
Parallel ports quantity	0
Serial ports quantity	0
I/O ports	2 USB 2.0; 2 USB 3.0; 1 1394a; 1 AC power; 1 DisplayPort; 1 docking connector; 1 eSATA; 1 RJ-11; 1 RJ-45; 1 secondary battery connector; 1 stereo headphone/line-out; 1 stereo microphone in; 1 VGA-in

Performance

Specification	Value
Motherboard chipset	Intel® QM57 Express

Keyboard

Specification	Value
Pointing device	Touchpad + Pointing Stick
Numeric keypad	Yes
Spill-resistant keyboard	Yes
Full-size keyboard	Yes
Keyboard layout	QWERTY
Keyboard type	Spill-resistant keyboard with drain

Software

Specification	Value
Operating system installed	Windows 7 Professional
Operating system architecture	64-bit
Bundled software	HP Recovery Manager HP ProtectTools Security Manager
Compatible operating systems	Genuine Windows Vista Enterprise 32; Genuine Windows Vista Enterprise 64; Genuine Windows Vista Business 64

Processor special features

Specification	Value
Intel® Wireless Display (Intel® WiDi)	No
CPU configuration (max)	1
Embedded options available	Yes
Enhanced Intel SpeedStep Technology	Yes
Execute Disable Bit	Yes
Graphics & IMC lithography	45 nm
Idle States	Yes
Intel 64	Yes
Intel Clear Video Technology	Yes
Intel Demand Based Switching	No
Intel Dual Display Capable Technology	Yes
Intel Enhanced Halt State	Yes
Intel FDI Technology	Yes
Intel Fast Memory Access	Yes
Intel Flex Memory Access	Yes
Intel Rapid Storage Technology	No
Intel Trusted Execution Technology	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Intel® Anti-Theft Technology (Intel® AT)	No
Intel® Clear Video HD Technology (Intel® CVT HD)	Yes
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)	Yes
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® InTru™ 3D Technology	No
Intel® Insider™	No
Intel® My WiFi Technology (Intel® MWT)	No
Intel® Quick Sync Video Technology	No
Intel® Turbo Boost Technology	1.0
Physical Address Extension (PAE)	36 bit
Processor ARK ID	47341
Processor package size	rPGA 37.5x 37.5, BGA 34x28
Supported instruction sets	SSE4.1/4.2
Thermal Monitoring Technologies	Yes
Conflict-Free processor	No

Battery

Specification	Value
Battery technology	Lithium-Ion (Li-Ion)
Number of battery cells	8
Battery capacity	68 Wh

Power

Specification	Value
AC adapter frequency	50 - 60 Hz
DC-in jack	Yes

Security

Specification	Value
Cable lock slot	No
Cable lock slot type	Kensington
Fingerprint reader	Yes
Trusted Platform Module (TPM)	Yes
Password protection type	BIOS
Security management description	McAfee Security Solution, HP ProtectTools Security Manager, HP Fingerprint Sensor, Integrated Smart Card Reader, Enhanced Pre-Boot Security, HP SpareKey, One-Step Logon, Setup Password, DriveLock Password, TPM 1.2 Embedded Security Chip, TPM Enhanced DriveLock, HP Disk Sanitizer, Kensington Lock slo

Operational conditions

Specification	Value
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 90%
Storage relative humidity (H-H)	5 - 95%

Certificates

Specification	Value
Certification	MCAD: AutoDesk (AutoCAD, Inventor, Revit, Alias Studio, Map 3D, Civil 3D), Bentley (In Roads XM, MicroStation, Navigator), CEI, CoCreate OneSpace, Dassault CATIA V5, ICEM Surf, Intelligent Light, MSC Software (MSC.Patran, SimXpert), PTC Pro/ENGINEER Wildfire, Sensable, Siemans PLMS (NX, NX I-deas, S

Weight & dimensions

Specification	Value
Weight	3.57 kg
Width	397.5 mm
Depth	285.5 mm
Height	36.5 mm
Height (front)	3.65 cm
Dimensions (WxDxH)	397.5 x 285.5 x 36.5 mm

Video

Specification	Value
Video adapter features	Microsoft DirectX 11 (Shader Model 4.1) and OpenGL 2.1 capable; Microsoft DirectX 10.1 (Shader Model 4.1) and OpenGL 2.1 capable

Hard drive

Specification	Value
Storage drive type	320 GB 7200 rpm SATA II
Storage drive controller	Solid State Drive SED SATA II (7200 rpm) SATA II (7200 rpm)

Packaging content

Specification	Value
AC adapter included	Yes

Other features

Specification	Value
Infrared data port	No
3D	No
Battery type	8-cell (68 WHr) Long Life Lithium-Ion Battery
Minimum storage drive space	250 GB
Power requirements	100-240 V
Power supply type	AC/DC
Internal modem	Yes
TV tuner integrated	No
Modem speed	56 Kbit/s
Modem type	56K V.92
Intel segment tagging	Enterprise
Docking solution	HP WKS Docking Station, HP Advanced WKS Docking Station, HP Display and Notebook Stand, HP Adjustable Display Stand
Expansion slots	1 Express Card/54; 1 Smart Card Reader; 1 Media Card Reader
Supplied AC adapter type	AC
