17 XE4
Model 17 XE4Part no. 17 XE4-73DE514SH
104 specifications Checked today
- Display43.9 cm (17.3")
- Resolution1920 x 1080 pixels
- ProcessorIntel® Core™ i7
- Memory64 GB
- GraphicsNVIDIA GeForce RTX 3070 Ti
- Battery99 Wh
Overview
- Display
- 43.9 cm (17.3")
- Resolution
- 1920 x 1080 pixels
- Processor
- Intel® Core™ i7
- Memory
- 64 GB
- Graphics
- NVIDIA GeForce RTX 3070 Ti
- Battery
- 99 Wh
- Brand
- GIGABYTE
- Category
- Laptop
- Model
- 17 XE4
- Part number
- 17 XE4-73DE514SH
- Also known as
- GIGABYTE AORUS 17 XE4 Intel® Core™ i7 i7-12700H Laptop 43.9 cm (17.3") Full HD 64 GB DDR4-SDRAM SSD NVIDIA GeForce RTX 3070 Ti Wi-Fi 6E (802.11ax) Windows 11 Ho
Specifications
104 specifications in 17 groups
Design
| Specification | Value |
|---|---|
| Product type | Laptop |
| Product colour | Black |
| Form factor | Clamshell |
| Market positioning | Gaming |
| Intel® vPro™ Platform Eligibility | Yes |
Display
| Specification | Value |
|---|---|
| Display diagonal | 43.9 cm (17.3") |
| Display resolution | 1920 x 1080 pixels |
| Touchscreen | No |
| Foldable display | No |
| HD type | Full HD |
| Colour gamut | 72% |
| RGB colour space | NTSC |
| Maximum refresh rate | 360 Hz |
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel® Core™ i7 |
| Processor generation | 12th gen Intel® Core™ i7 |
| Processor model | i7-12700H |
| Processor cores | 14 |
| Processor threads | 20 |
| Processor boost frequency | 4.7 GHz |
| Processor frequency | 2.3 GHz |
| Processor cache | 24 MB |
| Processor cache type | Smart Cache |
| Processor socket | BGA 1744 |
| Configurable TDP-down | 35 W |
| Tjunction | 100 °C |
| Maximum number of PCI Express lanes | 28 |
| Maximum turbo power | 115 W |
| Processor base power | 45 W |
Memory
| Specification | Value |
|---|---|
| Internal memory | 64 GB |
| Internal memory type | DDR4-SDRAM |
| Memory clock speed | 3200 MHz |
| Maximum internal memory | 64 GB |
| Memory channels | Dual-channel |
| ECC | No |
Storage
| Specification | Value |
|---|---|
| Storage media | SSD |
| Number of SSDs installed | 2 |
| NVMe | Yes |
| SSD interface | NVMe, PCI Express 4.0 |
| SSD form factor | M.2 |
| Optical drive type | No |
Graphics
| Specification | Value |
|---|---|
| On-board graphics card | Yes |
| Discrete graphics card | Yes |
| Discrete GPU manufacturer | NVIDIA |
| Discrete graphics card model | NVIDIA GeForce RTX 3070 Ti |
| Discrete graphics card memory | 8 GB |
| Discrete graphics memory type | GDDR6 |
| On-board graphics card model | Intel Iris Xe Graphics |
| NVIDIA Max-Q | Yes |
Audio
| Specification | Value |
|---|---|
| Audio system | DTS:X Ultra |
| Number of built-in speakers | 2 |
| Speaker power | 2.5 W |
| Built-in microphone | Yes |
| Number of microphones | 1 |
Camera
| Specification | Value |
|---|---|
| Front camera | Yes |
| Front camera HD type | HD |
Network
| Specification | Value |
|---|---|
| Mobile network connection | No |
| Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax) |
| WLAN controller manufacturer | Intel |
| WLAN controller model | Intel Wi-Fi 6E AX211 |
| Bluetooth | Yes |
| Bluetooth version | 5.2 |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| HDMI ports quantity | 1 |
| HDMI version | 2.1 |
| Thunderbolt 4 ports quantity | 1 |
| Microphone in | Yes |
Keyboard
| Specification | Value |
|---|---|
| Pointing device | Touchpad |
| Keyboard backlit | Yes |
| Numeric keypad | Yes |
| Keyboard backlit colour | RGB |
| Keyboard backlit zone | Per-key RGB |
Software
| Specification | Value |
|---|---|
| Operating system installed | Windows 11 Home |
Processor special features
| Specification | Value |
|---|---|
| CPU configuration (max) | 1 |
| Embedded options available | No |
| Execute Disable Bit | Yes |
| Intel Flex Memory Access | Yes |
| Intel QuickAssist Technology | Yes |
| Intel Standard Manageability | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel® High Definition Audio (Intel® HD Audio) | Yes |
| Intel® OS Guard | Yes |
| Intel® Secure Key | Yes |
| Intel® Smart Sound Technology | Yes |
| Intel® Turbo Boost Technology | 3.0 |
| Thermal Monitoring Technologies | Yes |
Battery
| Specification | Value |
|---|---|
| Battery technology | Lithium Polymer (LiPo) |
| Battery capacity | 99 Wh |
Power
| Specification | Value |
|---|---|
| AC adapter power | 240 W |
| DC-in jack | Yes |
Security
| Specification | Value |
|---|---|
| Trusted Platform Module (TPM) | Yes |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 2.7 kg |
| Width | 398 mm |
| Depth | 254 mm |
| Height | 27 mm |
| Height (front) | 2.4 cm |
| Height (rear) | 2.7 cm |
