Fujitsu AMILO Pi 3660

Model AMILO Pi 3660Part no. VFY:P3660MF032NLEAN 4049699197697

148 specifications Checked 3 days ago

Display46.7 cm (18.4")
Resolution1680 x 945 pixels
ProcessorIntel® Core™2 Duo
Memory4 GB
Storage500 GB
GraphicsNVIDIA® GeForce® GT 240M

See all specifications

Overview

Display: 46.7 cm (18.4")
Resolution: 1680 x 945 pixels
Processor: Intel® Core™2 Duo
Memory: 4 GB
Storage: 500 GB
Graphics: NVIDIA® GeForce® GT 240M

Brand: Fujitsu
Category: Laptop
Model: AMILO Pi 3660
Part numbers: VFY:P3660MF032NL, VFY:P3660MF032DE, VFY:P3660MF042DE, VFY:P3660MF022NL, VFY:P3660MF042NL
EAN / UPC: 4049699197697, 4049699214196
Also known as: Fujitsu AMILO Pi 3660 Intel® Core™2 Duo T6600 46.7 cm (18.4") WSXGA+ 4 GB DDR2-SDRAM 500 GB NVIDIA® GeForce® GT 240M Windows 7 Home Premium

Specifications

148 specifications in 22 groups

Display

Specification	Value
Display diagonal	46.7 cm (18.4")
Display resolution	1680 x 945 pixels
HD type	WSXGA+
Native aspect ratio	16:9
Display response rise/fall	16 ms
Contrast ratio (typical)	600:1

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Core™2 Duo
Processor model	T6600
Processor cores	2
Processor threads	2
Processor frequency	2.2 GHz
Processor cache	2 MB
Processor cache type	L2
Processor front side bus	800 MHz
Processor socket	Socket 478
Processor lithography	45 nm
Processor operating modes	64-bit
Processor series	Intel Core 2 Duo T6000 Series
Processor codename	Penryn
Bus type	FSB
FSB Parity	No
Stepping	R0
Thermal Design Power (TDP)	35 W
Tjunction	90 °C
Number of Processing Die Transistors	410 M
Processing Die size	107 mm²
CPU multiplier (bus/core ratio)	11
ECC supported by processor	No

Memory

Specification	Value
Internal memory	4 GB
Internal memory type	DDR2-SDRAM
Memory clock speed	800 MHz
Memory layout (slots x size)	2 x 2 GB
Maximum internal memory	8 GB

Storage

Specification	Value
Total storage capacity	500 GB
HDD interface	SATA
HDD speed	5400 RPM
Optical drive type	DVD Super Multi
Card reader integrated	Yes
Compatible memory cards	MMC, MS PRO, SD, xD

Graphics

Specification	Value
Discrete graphics card	Yes
Discrete graphics card model	NVIDIA® GeForce® GT 240M
Maximum graphics card memory	2.798 GB
Maximum resolution	1280 x 1024 pixels

Audio

Specification	Value
Audio system	Realtek ALC272
Number of built-in speakers	2
Speaker power	2 W

Camera

Specification	Value
Front camera resolution (numeric)	1.3 MP
Video capturing speed	30 fps

Optical drive

Specification	Value
CD read speed	24x
CD-R write speed	24x
Optical drive interface	SATA
CD-RW write speed	16x
DVD-R write speed	8x
DVD-R Double Layer write speed	6x
DVD-RW write speed	6x
DVD+R write speed	8x
DVD+R Double Layer write speed	6x
DVD+RW write speed	8x
DVD-RAM write speed	5x
HD DVD-ROM read speed	2x
DVD read speed	8x

Network

Specification	Value
Networking features	Gigabit Ethernet
Wireless technology	IEEE 802.11b/g/pre-n
Bluetooth	Yes
Bluetooth version	2.1+EDR

Ports & interfaces

Specification	Value
USB 2.0 ports quantity	2
eSATA ports quantity	1
Ethernet LAN (RJ-45) ports	1
HDMI ports quantity	1
DVI port	No
VGA (D-Sub) ports quantity	1
Firewire (IEEE 1394) ports	0
Headphone outputs	1
S/PDIF out port	Yes
Line-in	Yes
Microphone in	Yes
Docking connector	No
ExpressCard slot	Yes
CardBus PCMCIA slots quantity	0
CardBus PCMCIA slot type	No
SmartCard slot	No
Modem (RJ-11) ports	0
TV-in port	No
TV-out	No
PS/2 ports quantity	0
Parallel ports quantity	0
Serial ports quantity	0

Performance

Specification	Value
Motherboard chipset	Intel® PM45 Express

Keyboard

Specification	Value
Keyboard number of keys	85

Software

Specification	Value
Operating system installed	Windows 7 Home Premium
Trial software	Microsoft Office Ready, Symantec Norton Internet Security
Bundled software	Adobe Acrobat Reader, Nero Essentials S, Windows Media Player, Windows Media Center, CyberLink YouCam, Microsoft Internet Explorer
Compatible operating systems	Microsoft Windows Vista Home Premium (64 bit)

Processor special features

Specification	Value
Intel® Wireless Display (Intel® WiDi)	No
Embedded options available	No
Enhanced Intel SpeedStep Technology	Yes
Execute Disable Bit	Yes
Intel 64	Yes
Intel Clear Video Technology	No
Intel Demand Based Switching	No
Intel Dual Display Capable Technology	No
Intel Enhanced Halt State	No
Intel FDI Technology	No
Intel Fast Memory Access	No
Intel Flex Memory Access	No
Intel Rapid Storage Technology	No
Intel Trusted Execution Technology	No
Intel VT-x with Extended Page Tables (EPT)	No
Intel Virtualization Technology (VT-x)	No
Intel Virtualization Technology for Directed I/O (VT-d)	No
Intel® AES New Instructions (Intel® AES-NI)	No
Intel® Anti-Theft Technology (Intel® AT)	No
Intel® Clear Video HD Technology (Intel® CVT HD)	No
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)	No
Intel® Hyper Threading Technology (Intel® HT Technology)	No
Intel® InTru™ 3D Technology	No
Intel® Insider™	No
Intel® My WiFi Technology (Intel® MWT)	No
Intel® Quick Sync Video Technology	No
Intel® Turbo Boost Technology	No
Processor ARK ID	37255
Processor code	SLGF5
Processor package size	35 x 35 mm
Thermal Monitoring Technologies	No
Conflict-Free processor	No

Battery

Specification	Value
Number of battery cells	6
Battery capacity	2400 mAh
Battery life (max)	3 h

Power

Specification	Value
AC adapter power	90 W
AC adapter input voltage	100 - 240 V
AC adapter output current	4.5 A
AC adapter output voltage	20 V
DC-in jack	Yes

Security

Specification	Value
Cable lock slot	Yes
Cable lock slot type	Kensington
Password protection type	BIOS

Operational conditions

Specification	Value
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 90%

Certificates

Specification	Value
Certification	CE Marking, R&TTE, RoHS, ISO9241-307, GOST

Weight & dimensions

Specification	Value
Weight	3.4 kg
Width	438 mm
Depth	285 mm
Height	21 mm

Video

Specification	Value
Video card features	NVIDIA PhysX, NVIDIA Cuda, NVIDIA PureVideo, DirectX 10.1

Other features

Specification	Value
Infrared data port	No
Internal modem	No
Supplied AC adapter type	AC
