Dynabook Satellite Pro R50-EC-10F Intel® Core™ i3 i3-8130U Laptop
Dynabook

Satellite Pro R50-EC-10F Intel® Core™ i3 i3-8130U Laptop

39.6 cm (15.6") HD 8 GB DDR4-SDRAM 256 GB SSD Wi-Fi 5 (802.11ac) Windows 10 Pro Graphite

Model R50-EC-10FPart no. PT5A1E-00R008GREAN 4062507008947

137 specifications Checked today
  • Display39.6 cm (15.6")
  • Resolution1366 x 768 pixels
  • ProcessorIntel® Core™ i3
  • Memory8 GB
  • Storage256 GB
  • GraphicsNot available
See all specifications

Overview

Display
39.6 cm (15.6")
Resolution
1366 x 768 pixels
Processor
Intel® Core™ i3
Memory
8 GB
Storage
256 GB
Graphics
Not available
Brand
Dynabook
Category
Laptop
Model
R50-EC-10F
Part number
PT5A1E-00R008GR
EAN / UPC
4062507008947
Also known as
Dynabook Satellite Pro R50-EC-10F Intel® Core™ i3 i3-8130U Laptop 39.6 cm (15.6") HD 8 GB DDR4-SDRAM 256 GB SSD Wi-Fi 5 (802.11ac) Windows 10 Pro Graphite

Specifications

137 specifications in 19 groups

Design

Product typeLaptop
Product colourGraphite
Form factorClamshell

Display

Display diagonal39.6 cm (15.6")
Display resolution1366 x 768 pixels
TouchscreenNo
HD typeHD
LED backlightYes
Native aspect ratio16:9
Dual-screenNo

Processor

Processor manufacturerIntel
Processor familyIntel® Core™ i3
Processor generation8th gen Intel® Core™ i3
Processor modeli3-8130U
Processor cores2
Processor threads4
Processor boost frequency3.4 GHz
Processor frequency2.2 GHz
System bus rate4 GT/s
Processor cache4 MB
Processor cache typeSmart Cache
Processor lithography14 nm
Processor operating modes64-bit
Processor codenameKaby Lake
Thermal Design Power (TDP)15 W
Configurable TDP-down10 W
Configurable TDP-down frequency0.8 GHz
Tjunction100 °C
Maximum number of PCI Express lanes12
PCI Express configurations1x2+2x1, 1x4, 2x2, 4x1
PCI Express slots version3.0
ECC supported by processorNo

Memory

Internal memory8 GB
Internal memory typeDDR4-SDRAM
Memory clock speed2400 MHz
Memory form factorSO-DIMM
Memory slots2x SO-DIMM
Maximum internal memory32 GB

Storage

Total storage capacity256 GB
Storage mediaSSD
Total SSDs capacity256 GB
Number of SSDs installed1
SSD capacity256 GB
SSD form factorM.2
Optical drive typeDVD Super Multi DL
Card reader integratedYes
Compatible memory cardsMMC, SD, SDHC, SDXC

Graphics

On-board graphics cardYes
Discrete graphics cardNo
Discrete graphics card modelNot available
On-board graphics card modelIntel® UHD Graphics 620
Maximum on-board graphics card memory32 GB
On-board graphics card base frequency300 MHz
On-board graphics card dynamic frequency (max)1000 MHz
On-board graphics card DirectX version12.0
On-board graphics card OpenGL version4.4

Audio

Audio systemDTS Studio Sound
Number of built-in speakers2
Built-in microphoneYes
Number of microphones2

Camera

Front cameraYes
Front camera resolution (numeric)0.9 MP
Front camera resolution1280 x 720 pixels

Network

Wi-FiYes
Top Wi-Fi standardWi-Fi 5 (802.11ac)
Wi-Fi standards802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
WLAN controller modelIntel Dual Band Wireless-AC 8265
Ethernet LANYes
Ethernet LAN data rates10,100,1000 Mbit/s
BluetoothYes
Bluetooth version4.2

Ports & interfaces

USB 2.0 ports quantity0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity3
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity1
Ethernet LAN (RJ-45) ports1
HDMI ports quantity1
DisplayPorts quantity0
VGA (D-Sub) ports quantity1
Thunderbolt 3 ports quantity0
Headphone outputs1
Combo headphone/mic portYes

Keyboard

Pointing deviceClickpad
Numeric keypadYes
Keyboard number of keys102
Windows keysYes

Software

Operating system installedWindows 10 Pro
Operating system architecture64-bit
Trial softwareMicrosoft Office

Processor special features

CPU configuration (max)1
Embedded options availableNo
Enhanced Intel SpeedStep TechnologyYes
Execute Disable BitYes
Idle StatesYes
Intel 64Yes
Intel Clear Video TechnologyYes
Intel Flex Memory AccessYes
Intel Software Guard Extensions (Intel SGX)Yes
Intel Stable Image Platform Program (SIPP)Yes
Intel TSX-NINo
Intel Trusted Execution TechnologyNo
Intel VT-x with Extended Page Tables (EPT)Yes
Intel Virtualization Technology (VT-x)Yes
Intel Virtualization Technology for Directed I/O (VT-d)Yes
Intel® AES New Instructions (Intel® AES-NI)Yes
Intel® Clear Video HD Technology (Intel® CVT HD)Yes
Intel® Hyper Threading Technology (Intel® HT Technology)Yes
Intel® Identity Protection Technology (Intel® IPT)Yes
Intel® My WiFi Technology (Intel® MWT)Yes
Intel® OS GuardYes
Intel® Quick Sync Video TechnologyYes
Intel® Secure KeyYes
Intel® Smart Response TechnologyYes
Intel® Turbo Boost Technology2.0
Processor ARK ID137977
Processor package size42 x 42 mm
Supported instruction setsAVX 2.0, SSE4.1, SSE4.2
Thermal Monitoring TechnologiesYes

Battery

Battery technologyLithium-Ion (Li-Ion)
Number of battery cells4
Battery life (max)10.5 h

Power

AC adapter frequency50 - 60 Hz
AC adapter input voltage100 - 240 V
AC adapter output current2.37 A
AC adapter output voltage19 V

Security

Cable lock slotYes
Cable lock slot typeKensington
Trusted Platform Module (TPM)Yes
Password protectionYes
Password protection typeHDD, Supervisor, User

Sustainability

Sustainability certificatesENERGY STAR

Weight & dimensions

Weight2 kg
Width379 mm
Depth258 mm
Height24.1 mm

Packaging content

AC adapter includedYes
ManualYes
Power cord includedYes
