Pro 5 14 P514260 Copilot+ PC Intel Core Ultra 5 335 Laptop

35.6 cm (14") Touchscreen WUXGA 32 GB DDR5-SDRAM 256 GB SSD Wi-Fi 7 (802.11be) Windows 11 Pro Bl

Model P514260Part no. BTS005_P514260_USX

152 specifications Checked today

Display35.6 cm (14")
Resolution1920 x 1200 pixels
ProcessorIntel Core Ultra 5
Memory32 GB
Storage256 GB
GraphicsNot available

See all specifications

Overview

Display: 35.6 cm (14")
Resolution: 1920 x 1200 pixels
Processor: Intel Core Ultra 5
Memory: 32 GB
Storage: 256 GB
Graphics: Not available

Brand: Dell
Category: Laptop
Model: P514260
Part numbers: BTS005_P514260_USX, 210-BWFS, CTO515_P514260_AU, CTO535_P514260_AU, 210-BWCR, XCTO_P514260_USX +8 more
Also known as: DELL Pro 5 14 P514260 Copilot+ PC Intel Core Ultra 5 335 Laptop 35.6 cm (14") Touchscreen WUXGA 32 GB DDR5-SDRAM 256 GB SSD Wi-Fi 7 (802.11be) Windows 11 Pro Bl

Specifications

152 specifications in 21 groups

Design

Specification	Value
Product type	Laptop
Product colour	Black
Form factor	Clamshell
Housing material	Aluminium
Intel® vPro™ Platform Eligibility	Yes

Display

Specification	Value
Display diagonal	35.6 cm (14")
Display resolution	1920 x 1200 pixels
Touchscreen	Yes
HD type	WUXGA
Display technology marketing name	ComfortView Plus
Panel type	WLED
Native aspect ratio	16:10
Anti-glare screen	Yes
Display brightness	400 cd/m²
Pixel density	162 ppi
Colour gamut	100%
Low Blue Light technology	Yes
RGB colour space	sRGB
Display response rise/fall	35 ms
Maximum refresh rate	60 Hz
Contrast ratio (typical)	1000:1

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel Core Ultra 5
Processor generation	Intel® Core™ Ultra (Series 3)
Processor model	335
Processor cores	8
Processor threads	8
Processor boost frequency	4.6 GHz
Performance cores	4
Efficient cores	0
Low Power Efficient-cores	4
Performance-core Max Turbo Frequency	4.6 GHz
Low Power Efficient-core Max Turbo Frequency	3.4 GHz
Performance-core base frequency	2.2 GHz
Efficient-core base frequency	1.6 GHz
Low Power Efficient-core Base Frequency	1600 MHz
Processor cache	12 MB
Processor cache type	Smart Cache
Processor socket	FCBGA2540
Maximum turbo power	55 W
Processor base power	25 W

Neural processor unit (NPU)

Specification	Value
Copilot+ PC	Yes
Neural processor unit (NPU)	Intel AI Boost
Sparsity support	Yes
Windows Studio effects support	Yes
AI software frameworks supported by NPU	OpenVINO, Windows ML, ONNX RT, WebNN
NPU performance up to	47 TOPs
GPU performance up to	40 TOPs

Memory

Specification	Value
Internal memory	32 GB
Internal memory type	DDR5-SDRAM
Memory form factor	SO-DIMM
Memory layout (slots x size)	2 x 16 GB
Memory slots	2x SO-DIMM
Maximum internal memory	64 GB
Memory channels	Dual-channel
Memory data transfer rate	5600 MT/s

Storage

Specification	Value
Total storage capacity	256 GB
Storage media	SSD
Total SSDs capacity	256 GB
Number of SSDs installed	1
SSD capacity	256 GB
SSD memory type	TLC
NVMe	Yes
SSD form factor	M.2
Optical drive type	No

Graphics

Specification	Value
On-board graphics card	Yes
Discrete graphics card	No
Discrete graphics card model	Not available
On-board GPU manufacturer	Intel
On-board graphics card family	Intel® Graphics
On-board graphics card model	Intel® Graphics
Ray tracing acceleration	Yes

Audio

Specification	Value
Number of built-in speakers	2
Speaker power	2.5 W
Built-in microphone	Yes
Number of microphones	2

Camera

Specification	Value
Front camera	Yes
Front camera resolution (numeric)	8.29 MP
Front camera HD type	Quad HD
Front camera resolution	2560 x 1440 pixels
Video capturing speed	30 fps
Infrared (IR) camera	Yes
Privacy camera	Yes
Privacy type	Privacy shutter

Network

Specification	Value
Mobile network connection	No
Top Wi-Fi standard	Wi-Fi 7 (802.11be)
Wi-Fi band	Tri-band (2.4 GHz / 5 GHz / 6 GHz)
Wi-Fi standards	802.11a, 802.11b, Wi-Fi 4 (802.11n), 802.11g, Wi-Fi 5 (802.11ac), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be)
Antenna type	2x2
Wi-Fi data rate (max)	5760 Mbit/s
WLAN controller manufacturer	Intel
WLAN controller model	Intel Wi-Fi 7 BE211
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Bluetooth	Yes

Ports & interfaces

Specification	Value
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
Ethernet LAN (RJ-45) ports	1
HDMI ports quantity	1
HDMI version	2.1
Thunderbolt 4 ports quantity	2
Intel® Thunderbolt 4	Yes
Combo headphone/mic port	Yes
USB Type-C DisplayPort Alternate Mode	Yes
PowerShare	Yes
Number of USB ports with PowerShare support	1

Keyboard

Specification	Value
Pointing device	Touchpad
Keyboard backlit	Yes
Numeric keypad	No
Keyboard language	Nordic

Software

Specification	Value
Operating system installed	Windows 11 Pro
Operating system architecture	64-bit
Trial software	Microsoft Office Activate Your Microsoft 365 For A 30 Day Trial

Brand-specific features

Specification	Value
Brand specific technologies	Presence Detection, TNR, HDR Camera, Express Charge Boost capable, Battery-saving Mini-LED

Battery

Specification	Value
Battery technology	Lithium-Ion (Li-Ion)
Number of battery cells	3
Battery capacity	57 Wh
Battery voltage	11.25 V
Battery recharge time	3 h
Battery weight	240 g

Power

Specification	Value
AC adapter power	65 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
USB Type-C charging port	Yes
USB Type-C required charging power (max)	75 W
USB Type-C required charging power (min)	27 W
USB Power Delivery (USB PD)	Yes
USB charging voltage	9,5,15,20 V
USB charging current	3.25 A

Security

Specification	Value
Cable lock slot	Yes
Cable lock slot type	Wedge
Trusted Platform Module (TPM)	Yes
Trusted Platform Module (TPM) version	2.0

Operational conditions

Specification	Value
Operating temperature (T-T)	0 - 35 °C
Storage temperature (T-T)	-40 - 65 °C
Operating relative humidity (H-H)	10 - 90%
Storage relative humidity (H-H)	0 - 95%
Operating altitude	-15.2 - 3048 m
Non-operating altitude	-15.2 - 10668 m
Operating shock	110 G
Non-operating shock	160 G
Operating vibration	0.66 G
Non-operating vibration	1.3 G

Sustainability

Specification	Value
Sustainability certificates	EPEAT Gold, EPEAT Climate +

Weight & dimensions

Specification	Value
Weight	1.34 kg
Width	315.5 mm
Depth	226 mm
Height	18.1 mm
Height (front)	1.08 cm
Height (rear)	1.47 cm

Packaging content

Specification	Value
AC adapter included	Yes
