Pro Max 16 Plus MB16250 Intel Core Ultra 7 265HX Mobile workstation

40.6 cm (16") Full HD+ 32 GB DDR5-SDRAM 1 TB SSD NVIDIA RTX PRO 3000 Blackwell Wi-Fi 7

Model MB16250Part no. BTS104_MB16250_USXEAN 5397184966723

160 specifications Checked today

Display40.6 cm (16")
Resolution1920 x 1200 pixels
ProcessorIntel Core Ultra 7
Memory32 GB
Storage1 TB
GraphicsNVIDIA RTX PRO 3000 Blackwell

See all specifications

Overview

Display: 40.6 cm (16")
Resolution: 1920 x 1200 pixels
Processor: Intel Core Ultra 7
Memory: 32 GB
Storage: 1 TB
Graphics: NVIDIA RTX PRO 3000 Blackwell

Brand: Dell
Category: Laptop
Model: MB16250
Part numbers: BTS104_MB16250_USX, BTO106_MB16250_EMEA, BTO108_MB16250_EMEA, BTO104_MB16250_EMEA, BTO102_MB16250_EMEA, XCTO_MB16250_USX +34 more
EAN / UPC: 5397184966723, 662919124132, 662919125474, 662919124101 +56 more
Also known as: DELL Pro Max 16 Plus MB16250 Intel Core Ultra 7 265HX Mobile workstation 40.6 cm (16") Full HD+ 32 GB DDR5-SDRAM 1 TB SSD NVIDIA RTX PRO 3000 Blackwell Wi-Fi 7

Specifications

160 specifications in 22 groups

Design

Specification	Value
Product type	Mobile workstation
Product colour	Black
Form factor	Clamshell
Intel® vPro™ Platform Eligibility	Yes

Display

Specification	Value
Display diagonal	40.6 cm (16")
Display resolution	1920 x 1200 pixels
Touchscreen	No
HD type	Full HD+
Display technology marketing name	ComfortView Plus
Panel type	WVA
Native aspect ratio	16:10
Anti-glare screen	Yes
Display brightness	500 cd/m²
Pixel density	141 ppi
Colour gamut	100%
RGB colour space	DCI-P3
Display response rise/fall	35 ms
Maximum refresh rate	120 Hz
Contrast ratio (typical)	1500:1

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel Core Ultra 7
Processor generation	Intel Core Ultra (Series 2)
Processor model	265HX
Processor cores	20
Processor threads	20
Processor boost frequency	5.3 GHz
Performance cores	8
Efficient cores	12
Performance-core Max Turbo Frequency	5.3 GHz
Efficient-core Max Turbo Frequency	4.6 GHz
Performance-core base frequency	2.6 GHz
Efficient-core base frequency	2.3 GHz
Processor cache	30 MB
Maximum turbo power	160 W
Processor base power	55 W

Neural processor unit (NPU)

Specification	Value
Neural processor unit (NPU)	Intel AI Boost
Sparsity support	Yes
Windows Studio effects support	Yes
AI software frameworks supported by NPU	DirectML, OpenVINO, Windows ML, ONNX RT, WebNN
Total processor performance up to	33 TOPs
NPU performance up to	13 TOPs
GPU performance up to	8 TOPs

Memory

Specification	Value
Internal memory	32 GB
Internal memory type	DDR5-SDRAM
Memory form factor	CSODIMM
Memory layout (slots x size)	2 x 16 GB
Memory slots	2x CSoDIMM
Maximum internal memory	64 GB
Memory channels	Dual-channel
Memory data transfer rate	6400 MT/s
Non-ECC	Yes

Storage

Specification	Value
Total storage capacity	1 TB
Storage media	SSD
Total SSDs capacity	1 TB
Number of SSDs installed	1
SSD capacity	1 TB
NVMe	Yes
SSD interface	PCI Express 4.0
SSD form factor	M.2
Optical drive type	No
Card reader integrated	Yes
Compatible memory cards	SD, SDHC, SDXC

Graphics

Specification	Value
On-board graphics card	Yes
Discrete graphics card	Yes
Discrete GPU manufacturer	NVIDIA
Discrete graphics card model	NVIDIA RTX PRO 3000 Blackwell
Discrete graphics card memory	12 GB
Discrete graphics memory type	GDDR7
On-board GPU manufacturer	Intel
On-board graphics card family	Intel® Graphics
On-board graphics card model	Intel® Graphics

Audio

Specification	Value
Audio chip	Cirrus Logic CS42L43
Number of built-in speakers	2
Speaker power	2 W
Built-in microphone	Yes
Number of microphones	2

Camera

Specification	Value
Front camera	Yes
Front camera resolution (numeric)	8.29 MP
Front camera HD type	Full HD
Front camera resolution	1920 x 1080 pixels
Video capturing speed	30 fps
Infrared (IR) camera	Yes
Privacy camera	Yes
Privacy type	Privacy shutter

Network

Specification	Value
Mobile network connection	No
Top Wi-Fi standard	Wi-Fi 7 (802.11be)
Wi-Fi band	Tri-band (2.4 GHz / 5 GHz / 6 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 7 (802.11be)
Wi-Fi data rate (max)	5760 Mbit/s
WLAN controller manufacturer	Intel
WLAN controller model	Intel Wi-Fi 7 BE200
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000,2500 Mbit/s
Bluetooth	Yes
Near Field Communication (NFC)	Yes

Ports & interfaces

Specification	Value
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
Ethernet LAN (RJ-45) ports	1
HDMI ports quantity	1
HDMI version	2.1
Thunderbolt 4 ports quantity	1
Thunderbolt 5 ports quantity	2
Intel® Thunderbolt 4	Yes
Intel® Thunderbolt 5	Yes
Combo headphone/mic port	Yes
USB Type-C DisplayPort Alternate Mode	Yes

Performance

Specification	Value
Accelerometer	Yes
Ambient light sensor	Yes
Hall sensor	Yes

Keyboard

Specification	Value
Pointing device	Touchpad
Keyboard backlit	Yes
Numeric keypad	Yes
Keyboard language	English
Copilot key	Yes

Software

Specification	Value
Operating system installed	Windows 11 Pro
Operating system architecture	64-bit
Trial software	McAfee® Business Protection 1-year (Disti Only),Activate Your Microsoft 365 For A 30 Day Trial

Brand-specific features

Specification	Value
Brand specific technologies	Express Charge Boost capable, TNR

Battery

Specification	Value
Battery technology	Lithium-Ion (Li-Ion)
Number of battery cells	6
Battery capacity	96 Wh
Battery voltage	11.7 V
Battery recharge time	3 h
Fast charging	Yes

Power

Specification	Value
AC adapter power	280 W
AC adapter frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
USB Type-C charging port	Yes
USB Power Delivery (USB PD)	Yes

Security

Specification	Value
Cable lock slot	Yes
Cable lock slot type	Noble
Fingerprint reader	Yes
Smart card reader	Yes
Windows Hello	Yes
Trusted Platform Module (TPM)	Yes
Trusted Platform Module (TPM) version	2.0
Dell ControlVault	Yes

Operational conditions

Specification	Value
Operating temperature (T-T)	0 - 35 °C
Storage temperature (T-T)	-40 - 65 °C
Operating relative humidity (H-H)	10 - 90%
Storage relative humidity (H-H)	0 - 95%
Operating altitude	-15.2 - 3048 m
Non-operating altitude	-15.2 - 10668 m
Operating shock	110 G
Non-operating shock	160 G
Operating vibration	0.66 G
Non-operating vibration	1.3 G

Weight & dimensions

Specification	Value
Weight	2.55 kg
Width	360 mm
Depth	258.6 mm
Height (front)	1.73 cm
Height (rear)	1.9 cm

Carbon footprint

Specification	Value
Carbon emissions, end-of-life (kg of CO2e)	4.85
Carbon emissions, energy usage (kg of CO2e)	47.87
Carbon emissions, logistics (kg of CO2e)	7.88
Carbon emissions, manufacturing (kg of CO2e)	141.4
PAIA version	GaBi version 1, 2025
Total carbon footprint (kg of CO2e)	202

Packaging content

Specification	Value
AC adapter included	Yes
