Dell Pro Max 16 Premium MA16250 Intel Core Ultra 9 285H Mobile workstation

Pro Max 16 Premium MA16250 Intel Core Ultra 9 285H Mobile workstation

40.6 cm (16") Full HD+ 64 GB LPDDR5x-SDRAM 1 TB SSD NVIDIA RTX PRO 2000 Blackwell Wi-

Model MA16250Part no. BTS101_MA16250_CAXEAN 5397184966167

154 specifications Checked today

Display40.6 cm (16")
Resolution1920 x 1200 pixels
ProcessorIntel Core Ultra 9
Memory64 GB
Storage1 TB
GraphicsNVIDIA RTX PRO 2000 Blackwell

See all specifications

Overview

Display: 40.6 cm (16")
Resolution: 1920 x 1200 pixels
Processor: Intel Core Ultra 9
Memory: 64 GB
Storage: 1 TB
Graphics: NVIDIA RTX PRO 2000 Blackwell

Brand: Dell
Category: Laptop
Model: MA16250
Part numbers: BTS101_MA16250_CAX, BTS104_MA16250_CAX, BTS103_MA16250_CAX, BTS102_MA16250_CAX, XCTO_MA16250_EMEA, T7KRV +34 more
EAN / UPC: 5397184966167, 5397184966174, 5397184966143, 5397184966136 +29 more
Also known as: DELL Pro Max 16 Premium MA16250 Intel Core Ultra 9 285H Mobile workstation 40.6 cm (16") Full HD+ 64 GB LPDDR5x-SDRAM 1 TB SSD NVIDIA RTX PRO 2000 Blackwell Wi-

Specifications

154 specifications in 22 groups

Design

Specification	Value
Product type	Mobile workstation
Product colour	Black
Form factor	Clamshell
Intel® vPro™ Platform Eligibility	Yes

Display

Specification	Value
Display diagonal	40.6 cm (16")
Display resolution	1920 x 1200 pixels
Touchscreen	No
HD type	Full HD+
Panel type	WVA
Native aspect ratio	16:10
Anti-glare screen	Yes
Display brightness	500 cd/m²
Pixel density	142 ppi
Colour gamut	100%
RGB colour space	DCI-P3
Display response rise/fall	35 ms
Maximum refresh rate	120 Hz
Contrast ratio (typical)	1500:1

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel Core Ultra 9
Processor generation	Intel Core Ultra (Series 2)
Processor model	285H
Processor cores	16
Processor threads	16
Processor boost frequency	5.4 GHz
Performance cores	6
Efficient cores	8
Low Power Efficient-cores	2
Performance-core Max Turbo Frequency	5.4 GHz
Efficient-core Max Turbo Frequency	4.5 GHz
Low Power Efficient-core Max Turbo Frequency	2.5 GHz
Performance-core base frequency	2.9 GHz
Efficient-core base frequency	2.7 GHz
Low Power Efficient-core Base Frequency	1000 MHz
Processor cache	24 MB
Maximum turbo power	115 W
Processor base power	45 W

Neural processor unit (NPU)

Specification	Value
Neural processor unit (NPU)	Intel AI Boost
Sparsity support	Yes
Windows Studio effects support	Yes
AI software frameworks supported by NPU	DirectML, OpenVINO, Windows ML, ONNX RT, WebNN
Total processor performance up to	99 TOPs
NPU performance up to	13 TOPs
GPU performance up to	77 TOPs

Memory

Specification	Value
Internal memory	64 GB
Internal memory type	LPDDR5x-SDRAM
Memory form factor	On-board
Maximum internal memory	64 GB
Memory data transfer rate	8400 MT/s

Storage

Specification	Value
Total storage capacity	1 TB
Storage media	SSD
Total SSDs capacity	1 TB
Number of SSDs installed	1
SSD capacity	1 TB
NVMe	Yes
SSD interface	PCI Express 4.0
SSD form factor	M.2
Optical drive type	No
Card reader integrated	Yes
Compatible memory cards	SD, SDHC, SDXC

Graphics

Specification	Value
On-board graphics card	Yes
Discrete graphics card	Yes
Discrete GPU manufacturer	NVIDIA
Discrete graphics card model	NVIDIA RTX PRO 2000 Blackwell
Discrete graphics card memory	8 GB
Discrete graphics memory type	GDDR7
On-board GPU manufacturer	Intel
On-board graphics card family	Intel Arc Graphics
On-board graphics card model	Intel Arc 140T

Audio

Specification	Value
Audio chip	Cirrus Logic CS42L43
Audio system	Dolby Atmos
Number of built-in speakers	4
Built-in microphone	Yes

Camera

Specification	Value
Front camera	Yes
Front camera resolution (numeric)	8 MP
Front camera resolution	2560 x 1440 pixels
Video capturing speed	30 fps
Infrared (IR) camera	Yes

Network

Specification	Value
Mobile network connection	No
Top Wi-Fi standard	Wi-Fi 7 (802.11be)
Wi-Fi band	Tri-band (2.4 GHz / 5 GHz / 6 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 7 (802.11be)
Antenna type	2x2
WLAN controller manufacturer	Intel
WLAN controller model	Intel Wi-Fi 7 BE201
Ethernet LAN	No
Bluetooth	Yes
MIMO	Yes
MIMO type	Multi User MIMO

Ports & interfaces

Specification	Value
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
HDMI ports quantity	1
HDMI version	2.1
Thunderbolt 4 ports quantity	1
Thunderbolt 5 ports quantity	2
Intel® Thunderbolt 4	Yes
Intel® Thunderbolt 5	Yes
Combo headphone/mic port	Yes
USB Type-C DisplayPort Alternate Mode	Yes

Performance

Specification	Value
Motherboard chipset	Intel SoC
Accelerometer	Yes
Ambient light sensor	Yes
Hall sensor	Yes

Keyboard

Specification	Value
Pointing device	Touchpad
Keyboard backlit	Yes
Numeric keypad	No
Spill-resistant keyboard	Yes
Keyboard language	English
Copilot key	Yes

Software

Specification	Value
Operating system installed	Windows 11 Pro
Operating system architecture	64-bit
Trial software	McAfee® Business Protection 1-year (Disti Only),No Microsoft Office License included (Fed and Premier, Exception Only)

Brand-specific features

Specification	Value
Brand specific technologies	Battery-saving Mini-LED, Express Charge Boost capable, ExpressSign-In, Intelligent Privacy, TNR

Battery

Specification	Value
Battery technology	Lithium-Ion (Li-Ion)
Number of battery cells	6
Battery capacity	96 Wh
Battery voltage	11.7 V
Battery recharge time	3 h
Fast charging	Yes
Battery weight	351 g

Power

Specification	Value
AC adapter power	165 W
AC adapter frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
USB Type-C charging port	Yes
USB Power Delivery (USB PD)	Yes
USB charging voltage	5,9,15,20 V

Security

Specification	Value
Cable lock slot	Yes
Cable lock slot type	Wedge
Fingerprint reader	Yes
Trusted Platform Module (TPM)	Yes
Trusted Platform Module (TPM) version	2.0

Operational conditions

Specification	Value
Operating temperature (T-T)	0 - 35 °C
Storage temperature (T-T)	-40 - 65 °C
Operating relative humidity (H-H)	10 - 90%
Storage relative humidity (H-H)	0 - 95%
Operating altitude	-15.2 - 3048 m
Non-operating altitude	-15.2 - 10668 m
Operating shock	110 G
Non-operating shock	160 G
Operating vibration	0.66 G
Non-operating vibration	1.3 G

Weight & dimensions

Specification	Value
Weight	2.19 kg
Width	353.8 mm
Depth	240.3 mm
Height (front)	2.08 cm
Height (rear)	2.08 cm

Carbon footprint

Specification	Value
Carbon emissions, end-of-life (kg of CO2e)	1.93
Carbon emissions, energy usage (kg of CO2e)	30.1
Carbon emissions, logistics (kg of CO2e)	6.48
Carbon emissions, manufacturing (kg of CO2e)	136.5
PAIA version	GaBi version 1, 2025
Total carbon footprint (kg of CO2e)	175

Packaging content

Specification	Value
AC adapter included	Yes
