ASUS Vivobook TN3604YA-MY081W AMD Ryzen™ 9 8945HS Laptop

Vivobook TN3604YA-MY081W AMD Ryzen™ 9 8945HS Laptop

40.6 cm (16") 32 GB LPDDR5x-SDRAM 1 TB SSD Wi-Fi 6E (802.11ax) Windows 11 Home Silver

Model TN3604YA-MY081WPart no. 90NB1042-M00370EAN 4711387507346

89 specifications Checked today

Display40.6 cm (16")
Resolution3200 x 2000 pixels
ProcessorAMD Ryzen™ 9
Memory32 GB
Storage1 TB
Battery75 Wh

See all specifications

Overview

Display: 40.6 cm (16")
Resolution: 3200 x 2000 pixels
Processor: AMD Ryzen™ 9
Memory: 32 GB
Storage: 1 TB
Battery: 75 Wh

Brand: ASUS
Category: Laptop
Model: TN3604YA-MY081W
Part number: 90NB1042-M00370
EAN / UPC: 4711387507346
Also known as: ASUS Vivobook TN3604YA-MY081W AMD Ryzen™ 9 8945HS Laptop 40.6 cm (16") 32 GB LPDDR5x-SDRAM 1 TB SSD Wi-Fi 6E (802.11ax) Windows 11 Home Silver

Specifications

89 specifications in 20 groups

Design

Specification	Value
Product type	Laptop
Product colour	Silver
Colour name	Cool Silver
Form factor	Convertible (Folder)

Display

Specification	Value
Display diagonal	40.6 cm (16")
Display resolution	3200 x 2000 pixels
Touchscreen	No
Panel type	OLED
Native aspect ratio	16:10
Display brightness	400 cd/m²
Maximum display brightness (HDR)	550 cd/m²
Colour gamut	100%
Display diagonal (metric)	40.6 cm
RGB colour space	DCI-P3
Maximum refresh rate	120 Hz

Processor

Specification	Value
Processor manufacturer	AMD
Processor family	AMD Ryzen™ 9
Processor generation	AMD Ryzen 8000 Series
Processor model	8945HS
Processor cores	8
Processor threads	16
Processor boost frequency	5.2 GHz
Processor frequency	4 GHz
Processor cache	24 MB
Processor cache type	L2 & L3

Memory

Specification	Value
Internal memory	32 GB
Internal memory type	LPDDR5x-SDRAM
Memory form factor	On-board
Maximum internal memory	32 GB

Storage

Specification	Value
Total storage capacity	1 TB
Storage media	SSD
Total SSDs capacity	1 TB
Number of SSDs installed	1
SSD capacity	1 TB
SSD interface	PCI Express 4.0
SSD form factor	M.2
Optical drive type	No
Card reader integrated	Yes
Compatible memory cards	MicroSD (TransFlash)

Graphics

Specification	Value
On-board graphics card	Yes
Discrete graphics card	No
On-board GPU manufacturer	AMD
On-board graphics card family	AMD Radeon
On-board graphics card model	AMD Radeon 780M

Audio

Specification	Value
Audio system	Smart Amp
Built-in microphone	Yes

Camera

Specification	Value
Front camera	Yes
Front camera HD type	Full HD
Front camera resolution	1920 x 1080 pixels

Network

Specification	Value
Mobile network connection	No
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
Wi-Fi standards	Wi-Fi 6E (802.11ax)
Antenna type	2x2
Bluetooth	Yes
Bluetooth version	5.3

Ports & interfaces

Specification	Value
USB 2.0 ports quantity	1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	1
HDMI ports quantity	1
HDMI version	2.1
Combo headphone/mic port	Yes
USB Type-C DisplayPort Alternate Mode	Yes

Performance

Specification	Value
Repairability index	9.3

Keyboard

Specification	Value
Pointing device	Touchpad
Keyboard backlit	Yes
Numeric keypad	Yes
Keyboard backlit colour	RGB

Software

Specification	Value
Operating system installed	Windows 11 Home
Operating system architecture	64-bit

Battery

Specification	Value
Number of battery cells	4
Battery capacity	75 Wh

Power

Specification	Value
AC adapter power	90 W
AC adapter output current	4.5 A
AC adapter output voltage	20 V
USB Type-C charging port	Yes
USB Power Delivery (USB PD)	Yes

Security

Specification	Value
Windows Hello	Yes
Trusted Platform Module (TPM)	Yes

Weight & dimensions

Specification	Value
Weight	1.9 kg
Width	352 mm
Depth	252 mm
Height (front)	1.96 cm
Height (rear)	1.97 cm

Packaging data

Specification	Value
Package width	65 mm
Package depth	488 mm
Package height	310 mm
Package weight	2.15 kg

Packaging content

Specification	Value
AC adapter included	Yes

Other features

Specification	Value
Warranty period	2 year(s)
