ASUS F3Jp Intel® Core™2 Duo T7200

Model F3Jp Intel® Core™2 Duo T7200Part no. F3JP-AP026CEAN 884840054603

121 specifications Checked 3 days ago

Display39.1 cm (15.4")
ProcessorIntel® Core™2 Duo
Memory2 GB
Storage160 GB
GraphicsAMD Mobility Radeon X1700
Battery4800 mAh

See all specifications

Overview

Display: 39.1 cm (15.4")
Processor: Intel® Core™2 Duo
Memory: 2 GB
Storage: 160 GB
Graphics: AMD Mobility Radeon X1700
Battery: 4800 mAh

Brand: ASUS
Category: Laptop
Model: F3Jp Intel® Core™2 Duo T7200
Part numbers: F3JP-AP026C, 90NL0A1312962CAC60H, 90NL0A1312932CAC60HY, 90NL0A13D2962CAC60I
EAN / UPC: 884840054603
Also known as: ASUS F3Jp Intel® Core™2 Duo T7200 39.1 cm (15.4") 2 GB DDR2-SDRAM 160 GB AMD Mobility Radeon X1700 Windows Vista Home Premium

Specifications

121 specifications in 20 groups

Display

Specification	Value
Display diagonal	39.1 cm (15.4")

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Core™2 Duo
Processor model	T7200
Processor cores	2
Processor threads	2
Processor frequency	2 GHz
Processor cache	4 MB
Processor cache type	L2
Processor front side bus	667 MHz
Processor socket	Socket 479
Processor lithography	65 nm
Processor operating modes	64-bit
Processor series	Intel Core 2 Duo T7000 Series
Processor codename	Merom
Bus type	FSB
FSB Parity	No
Stepping	B2
Thermal Design Power (TDP)	34 W
Tjunction	100 °C
Processor core voltage (AC)	1.0375 - 1.30 V
Number of Processing Die Transistors	291 M
Processing Die size	143 mm²
CPU multiplier (bus/core ratio)	12
ECC supported by processor	No

Memory

Specification	Value
Internal memory	2 GB
Internal memory type	DDR2-SDRAM

Storage

Specification	Value
Total storage capacity	160 GB
HDD interface	SATA
HDD speed	5400 RPM
Card reader integrated	Yes

Graphics

Specification	Value
On-board graphics card	No
Discrete graphics card	Yes
Discrete graphics card model	AMD Mobility Radeon X1700
On-board graphics card model	Not available
Maximum graphics card memory	0.256 GB

Audio

Specification	Value
Audio system	Intel HDA
Number of built-in speakers	2
Built-in subwoofer	No

Camera

Specification	Value
Front camera	Yes
Front camera resolution (numeric)	1.3 MP

Optical drive

Specification	Value
LightScribe	Yes

Network

Specification	Value
Networking features	Ethernet, Fast Ethernet, Gigabit Ethernet
Wireless technology	IEEE 802.11a, IEEE 802.11b, IEEE 802.11g
Bluetooth	Yes
Bluetooth version	2.0+EDR

Ports & interfaces

Specification	Value
USB 2.0 ports quantity	4
Ethernet LAN (RJ-45) ports	1
DVI port	Yes
VGA (D-Sub) ports quantity	1
Firewire (IEEE 1394) ports	1
Headphone outputs	1
S/PDIF out port	No
Microphone in	Yes
Docking connector	No
ExpressCard slot	Yes
CardBus PCMCIA slots quantity	0
CardBus PCMCIA slot type	No
SmartCard slot	No
Modem (RJ-11) ports	1
TV-in port	No
TV-out	Yes
TV-out type	S-Video
PS/2 ports quantity	0
Parallel ports quantity	0
Serial ports quantity	0
USB 1.1 ports quantity	0

Performance

Specification	Value
Motherboard chipset	Intel® 945PM Express

Keyboard

Specification	Value
Pointing device	Touchpad

Software

Specification	Value
Operating system installed	Windows Vista Home Premium
Bundled software	ASUSDVD XP 6.0 Power Director V3.0 DE Medi@Show V2.0 SE Symantec Norton Internet Security 2005 Adobe Acrobat Reader 7.0 NERO Express V6.0 ASUS WinFlash ASUS Live Update ASUS ChkMail ASUS Hotkey ASUS Power4 Gear+ ASUS Live Update ASUS LifFrame2 Net 4 Switch ASUS Wireless Console ASUS Multi-Frame ASUS

Processor special features

Specification	Value
Intel® Wireless Display (Intel® WiDi)	No
Embedded options available	No
Enhanced Intel SpeedStep Technology	Yes
Execute Disable Bit	Yes
Idle States	No
Intel 64	Yes
Intel Clear Video Technology	No
Intel Demand Based Switching	No
Intel Dual Display Capable Technology	No
Intel Enhanced Halt State	No
Intel FDI Technology	No
Intel Fast Memory Access	No
Intel Flex Memory Access	No
Intel Rapid Storage Technology	No
Intel Trusted Execution Technology	No
Intel VT-x with Extended Page Tables (EPT)	No
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	No
Intel® AES New Instructions (Intel® AES-NI)	No
Intel® Anti-Theft Technology (Intel® AT)	No
Intel® Clear Video HD Technology (Intel® CVT HD)	No
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)	No
Intel® Hyper Threading Technology (Intel® HT Technology)	No
Intel® InTru™ 3D Technology	No
Intel® Insider™	No
Intel® My WiFi Technology (Intel® MWT)	No
Intel® Quick Sync Video Technology	No
Intel® Turbo Boost Technology	No
Processor ARK ID	27255
Processor package size	35 x 35 mm
Thermal Monitoring Technologies	No
Conflict-Free processor	No

Battery

Specification	Value
Number of battery cells	6
Battery capacity	4800 mAh

Power

Specification	Value
AC adapter power	90 W
AC adapter input voltage	100/240 V
AC adapter output voltage	19 V
DC-in jack	Yes

Security

Specification	Value
Cable lock slot	Yes
Cable lock slot type	Kensington
Trusted Platform Module (TPM)	Yes
Password protection type	BIOS
HDD user password	Yes

Weight & dimensions

Specification	Value
Weight	2.95 kg
Width	365 mm
Height	269.5 mm

Packaging content

Specification	Value
AC adapter included	Yes

Other features

Specification	Value
Infrared data port	No
Internal modem	Yes
Modem speed	56 Kbit/s
