ASUS Chromebook CM32 CM3206DM4A-TR0145 MediaTek Kompanio Kompanio 540

Chromebook CM32 CM3206DM4A-TR0145 MediaTek Kompanio Kompanio 540

30.7 cm (12.1") Touchscreen WQXGA 8 GB LPDDR5x-SDRAM 128 GB eMMC Wi-Fi 6 (802.11ax) Chrome

Model CM3206DM4A-TR0145Part no. 90CB0A81-M00520EAN 199291626799

90 specifications Checked today

Display30.7 cm (12.1")
Resolution2560 x 1600 pixels
ProcessorMediaTek Kompanio
Memory8 GB
Storage128 GB
GraphicsNot available

See all specifications

Overview

Display: 30.7 cm (12.1")
Resolution: 2560 x 1600 pixels
Processor: MediaTek Kompanio
Memory: 8 GB
Storage: 128 GB
Graphics: Not available

Brand: ASUS
Category: Laptop
Model: CM3206DM4A-TR0145
Part number: 90CB0A81-M00520
EAN / UPC: 199291626799, 4711636626798
Also known as: ASUS Chromebook CM32 CM3206DM4A-TR0145 MediaTek Kompanio Kompanio 540 30.7 cm (12.1") Touchscreen WQXGA 8 GB LPDDR5x-SDRAM 128 GB eMMC Wi-Fi 6 (802.11ax) Chrome

Specifications

90 specifications in 20 groups

Design

Specification	Value
Product type	Chromebook
Product colour	Titanium
Colour name	Cloud Titanium
Form factor	Convertible (Detachable)
Market positioning	Home
Certified refurbished	No

Display

Specification	Value
Display diagonal	30.7 cm (12.1")
Display resolution	2560 x 1600 pixels
Touchscreen	Yes
HD type	WQXGA
Panel type	IPS
LED backlight	Yes
Native aspect ratio	16:10
Anti-glare screen	Yes
Display brightness	600 cd/m²
Colour gamut	98%
RGB colour space	DCI-P3
Maximum refresh rate	120 Hz

Processor

Specification	Value
Processor manufacturer	MediaTek
Processor family	MediaTek Kompanio
Processor model	Kompanio 540
Processor cores	8
Processor boost frequency	2.6 GHz
Processor frequency	2 GHz
Processor cache	1 MB

Neural processor unit (NPU)

Specification	Value
Copilot+ PC	No

Memory

Specification	Value
Internal memory	8 GB
Internal memory type	LPDDR5x-SDRAM
Memory form factor	On-board
Maximum internal memory	8 GB

Storage

Specification	Value
Total storage capacity	128 GB
Storage media	eMMC
Flash memory	128 GB
Optical drive type	No

Graphics

Specification	Value
On-board graphics card	Yes
Discrete graphics card	No
Discrete graphics card model	Not available
On-board GPU manufacturer	ARM
On-board graphics card family	ARM Mali
On-board graphics card model	ARM Mali-G57 MC2

Audio

Specification	Value
Audio system	Dolby Atmos
Built-in microphone	Yes

Camera

Specification	Value
Front camera	Yes
Front camera resolution (numeric)	5 MP
Rear camera	Yes
Rear camera resolution (numeric)	5 MP

Network

Specification	Value
Mobile network connection	No
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
Wi-Fi standards	Wi-Fi 6 (802.11ax)
Antenna type	2x2
Ethernet LAN	No
Bluetooth	Yes
Bluetooth version	5.4

Ports & interfaces

Specification	Value
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	1
HDMI ports quantity	0
Combo headphone/mic port	Yes
USB Type-C DisplayPort Alternate Mode	Yes

Keyboard

Specification	Value
Pointing device	Touchpad
Numeric keypad	No
Keyboard layout	QWERTZ
Keyboard language	German

Software

Specification	Value
Operating system installed	ChromeOS

Battery

Specification	Value
Battery technology	Lithium-Ion (Li-Ion)
Number of battery cells	2
Battery capacity	42 Wh

Power

Specification	Value
AC adapter power	45 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	3 A
AC adapter output voltage	15 V
USB Type-C charging port	Yes
USB Type-C required charging power (max)	45 W
USB Type-C required charging power (min)	35 W
USB Power Delivery (USB PD)	Yes

Certificates

Specification	Value
Compliance certificates	REACH
Certification	US MIL-STD 810H military-grade standard

Sustainability

Specification	Value
Sustainability certificates	ENERGY STAR, EPEAT Gold

Weight & dimensions

Specification	Value
Weight	635 g
Width	279.1 mm
Depth	190 mm
Height (front)	2.2 cm
Height (rear)	2.3 cm

Packaging data

Specification	Value
Package width	317 mm
Package depth	88 mm
Package height	223 mm

Packaging content

Specification	Value
AC adapter included	No
Stylus pen	Yes
