Acer Aspire Switch 10 SW5-012-102W Intel Atom® Z3735F Hybrid (2-in-1)
25.6 cm (10.1") Touchscreen WXGA 2 GB DDR3L-SDRAM 500 GB HDD Wi-Fi 4 (802.11n) Windows 8.1
Model SW5-012-102WPart no. NT.L4SEG.003EAN 4713147587995
88 specifications Checked 2 days ago
- Display25.6 cm (10.1")
- Resolution1280 x 800 pixels
- ProcessorIntel Atom®
- Memory2 GB
- Storage500 GB
- GraphicsNot available
Overview
- Display
- 25.6 cm (10.1")
- Resolution
- 1280 x 800 pixels
- Processor
- Intel Atom®
- Memory
- 2 GB
- Storage
- 500 GB
- Graphics
- Not available
- Brand
- Acer
- Category
- Laptop
- Model
- SW5-012-102W
- Part number
- NT.L4SEG.003
- EAN / UPC
- 4713147587995
- Also known as
- Acer Aspire Switch 10 SW5-012-102W Intel Atom® Z3735F Hybrid (2-in-1) 25.6 cm (10.1") Touchscreen WXGA 2 GB DDR3L-SDRAM 500 GB HDD Wi-Fi 4 (802.11n) Windows 8.1
Specifications
88 specifications in 19 groups
Design
| Specification | Value |
|---|---|
| Product type | Hybrid (2-in-1) |
| Product colour | White |
| Form factor | Convertible (Detachable) |
Display
| Specification | Value |
|---|---|
| Display diagonal | 25.6 cm (10.1") |
| Display resolution | 1280 x 800 pixels |
| Touchscreen | Yes |
| HD type | WXGA |
| Touch technology | Multi-touch |
| LED backlight | Yes |
| Native aspect ratio | 16:10 |
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel Atom® |
| Processor model | Z3735F |
| Processor cores | 4 |
| Processor threads | 4 |
| Processor boost frequency | 1.83 GHz |
| Processor frequency | 1.33 GHz |
| Processor cache | 2 MB |
| Processor cache type | L2 |
| Processor socket | BGA 592 |
| Processor lithography | 22 nm |
| Processor operating modes | 32-bit, 64-bit |
| Processor series | Intel Atom Z3700 Series |
| Processor codename | Bay Trail |
| Stepping | C0 |
| Scenario Design Power (SDP) | 2.2 W |
Memory
| Specification | Value |
|---|---|
| Internal memory | 2 GB |
| Internal memory type | DDR3L-SDRAM |
Storage
| Specification | Value |
|---|---|
| Total storage capacity | 500 GB |
| Storage media | HDD |
| Number of HDDs installed | 1 |
| HDD capacity | 500 GB |
| HDD interface | SATA |
| HDD speed | 5400 RPM |
| Optical drive type | No |
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash), MicroSDXC |
Graphics
| Specification | Value |
|---|---|
| On-board graphics card | Yes |
| Discrete graphics card | No |
| Discrete graphics card model | Not available |
| On-board graphics card model | Intel® HD Graphics |
| On-board graphics card base frequency | 311 MHz |
| On-board graphics card burst frequency | 646 MHz |
Audio
| Specification | Value |
|---|---|
| Built-in microphone | Yes |
Camera
| Specification | Value |
|---|---|
| Front camera | Yes |
| Front camera resolution (numeric) | 2 MP |
Network
| Specification | Value |
|---|---|
| Wi-Fi | Yes |
| Top Wi-Fi standard | Wi-Fi 4 (802.11n) |
| Wi-Fi standards | 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| Ethernet LAN | No |
| Bluetooth | Yes |
| Bluetooth version | 4.0 |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 0 |
| Micro-USB 2.0 ports quantity | 1 |
| HDMI ports quantity | 0 |
| DisplayPorts quantity | 0 |
| Thunderbolt ports quantity | 0 |
| Micro HDMI ports quantity | 1 |
| Combo headphone/mic port | Yes |
| Docking connector | Yes |
Performance
| Specification | Value |
|---|---|
| Accelerometer | Yes |
| Ambient light sensor | Yes |
| Electronic compass | Yes |
| Gyroscope | Yes |
Keyboard
| Specification | Value |
|---|---|
| Pointing device | Touchpad |
| Numeric keypad | No |
Software
| Specification | Value |
|---|---|
| Operating system installed | Windows 8.1 with Bing |
| Operating system architecture | 32-bit |
Processor special features
| Specification | Value |
|---|---|
| CPU configuration (max) | 1 |
| Embedded options available | No |
| Graphics & IMC lithography | 22 nm |
| Intel 64 | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel® Turbo Boost Technology | No |
| Processor ARK ID | 80274 |
| Processor code | SR1UB |
| Processor package size | 17 x 17 mm |
| Conflict-Free processor | Yes |
Battery
| Specification | Value |
|---|---|
| Battery technology | Lithium Polymer (LiPo) |
| Number of battery cells | 2 |
| Battery capacity | 5930 mAh |
Power
| Specification | Value |
|---|---|
| AC adapter power | 18 W |
Certificates
| Specification | Value |
|---|---|
| Certification | ACPI 5.0 |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 261.6 mm |
| Depth | 177.1 mm |
| Height | 8.9 mm |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
