Predator Helios Neo 14 AI PHN14-71 - Intel Core Ultra 7 255HX
32GB, 1TB SSD, NVIDIA GeForce RTX 5070, 14" OLED 120Hz, Windows 11 Gaming Laptop
Model PHN14-71-77T3Part no. NH.QY1EK.004EAN 4711474604545
113 specifications Checked today
- Display36.8 cm (14.5")
- Resolution2880 x 1800 pixels
- ProcessorIntel Core Ultra 7
- Memory32 GB
- Storage1 TB
- GraphicsNVIDIA GeForce RTX 5070
Overview
- Display
- 36.8 cm (14.5")
- Resolution
- 2880 x 1800 pixels
- Processor
- Intel Core Ultra 7
- Memory
- 32 GB
- Storage
- 1 TB
- Graphics
- NVIDIA GeForce RTX 5070
- Brand
- Acer
- Category
- Laptop
- Model
- PHN14-71-77T3
- Part number
- NH.QY1EK.004
- EAN / UPC
- 4711474604545
- Also known as
- Acer Predator Helios Neo 14 AI PHN14-71 - Intel Core Ultra 7 255HX, 32GB, 1TB SSD, NVIDIA GeForce RTX 5070, 14" OLED 120Hz, Windows 11 Gaming Laptop
Specifications
113 specifications in 19 groups
Design
| Specification | Value |
|---|---|
| Product type | Laptop |
| Product colour | Black |
| Form factor | Clamshell |
| Market positioning | Gaming |
| Country of origin | China |
Display
| Specification | Value |
|---|---|
| Display diagonal | 36.8 cm (14.5") |
| Display resolution | 2880 x 1800 pixels |
| Touchscreen | No |
| HD type | WQXGA+ |
| Display technology marketing name | CineCrystal |
| Panel type | OLED |
| Native aspect ratio | 16:10 |
| Maximum refresh rate | 120 Hz |
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel Core Ultra 7 |
| Processor generation | Intel Core Ultra (Series 2) |
| Processor model | 255H |
| Processor cores | 16 |
| Processor threads | 16 |
| Processor boost frequency | 5.1 GHz |
| Processor frequency | 2 GHz |
| Performance cores | 6 |
| Efficient cores | 8 |
| Low Power Efficient-cores | 2 |
| Performance-core Max Turbo Frequency | 5.1 GHz |
| Efficient-core Max Turbo Frequency | 4.4 GHz |
| Low Power Efficient-core Max Turbo Frequency | 2.5 GHz |
| Performance-core base frequency | 2 GHz |
| Efficient-core base frequency | 1.5 GHz |
| Low Power Efficient-core Base Frequency | 700 MHz |
| Processor cache | 24 MB |
| Maximum turbo power | 115 W |
| Processor base power | 28 W |
Neural processor unit (NPU)
| Specification | Value |
|---|---|
| Copilot+ PC | No |
| Neural processor unit (NPU) | Intel AI Boost |
| Sparsity support | Yes |
| Windows Studio effects support | Yes |
| AI software frameworks supported by NPU | DirectML, OpenVINO, Windows ML, ONNX RT, WebNN |
| Total processor performance up to | 96 TOPs |
| NPU performance up to | 13 TOPs |
| GPU performance up to | 74 TOPs |
Memory
| Specification | Value |
|---|---|
| Internal memory | 32 GB |
| Internal memory type | LPDDR5x-SDRAM |
| Memory layout (slots x size) | 1 x 32 GB |
| Maximum internal memory | 32 GB |
Storage
| Specification | Value |
|---|---|
| Total storage capacity | 1 TB |
| Storage media | SSD |
| Total SSDs capacity | 1 TB |
| Number of SSDs installed | 1 |
| SSD capacity | 1 TB |
| NVMe | Yes |
| SSD interface | PCI Express 4.0 |
| SSD form factor | M.2 |
| Optical drive type | No |
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash) |
Graphics
| Specification | Value |
|---|---|
| On-board graphics card | Yes |
| Discrete graphics card | Yes |
| Discrete GPU manufacturer | NVIDIA |
| Discrete graphics card model | NVIDIA GeForce RTX 5070 |
| Discrete graphics card memory | 8 GB |
| Discrete graphics memory type | GDDR7 |
| On-board GPU manufacturer | Intel |
| On-board graphics card family | Intel Arc Graphics |
| On-board graphics card model | Intel Arc 140T |
Audio
| Specification | Value |
|---|---|
| Number of built-in speakers | 2 |
| Built-in microphone | Yes |
Camera
| Specification | Value |
|---|---|
| Front camera | Yes |
| Front camera HD type | Full HD |
Network
| Specification | Value |
|---|---|
| Mobile network connection | No |
| Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
| Wi-Fi standards | Wi-Fi 6E (802.11ax) |
| Antenna type | 2x2 |
| WLAN controller manufacturer | Killer |
| WLAN controller model | Killer Wi-Fi 6E 1675i |
| Ethernet LAN | Yes |
| Bluetooth | Yes |
| Bluetooth version | 5.3 |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 2 |
| Ethernet LAN (RJ-45) ports | 0 |
| HDMI ports quantity | 1 |
| Combo headphone/mic port | Yes |
Keyboard
| Specification | Value |
|---|---|
| Pointing device | Touchpad |
| Keyboard backlit | Yes |
| Numeric keypad | No |
| Keyboard backlit colour | RGB |
| Keyboard backlit zone | 3-zone RGB |
| Copilot key | Yes |
Software
| Specification | Value |
|---|---|
| Operating system installed | Windows 11 Home |
| Operating system architecture | 64-bit |
Battery
| Specification | Value |
|---|---|
| Battery technology | Lithium-Ion (Li-Ion) |
| Battery life (max) | 13 h |
Power
| Specification | Value |
|---|---|
| AC adapter power | 230 W |
| USB Type-C charging port | Yes |
| USB Type-C required charging power (min) | 90 W |
Security
| Specification | Value |
|---|---|
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Fingerprint reader | No |
| Trusted Platform Module (TPM) | Yes |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 1.9 kg |
| Width | 323.9 mm |
| Depth | 254.7 mm |
| Height | 20.8 mm |
| Height (rear) | 2.08 cm |
Packaging data
| Specification | Value |
|---|---|
| Package width | 480 mm |
| Package depth | 310 mm |
| Package height | 73 mm |
| Package weight | 3.6 kg |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
