Acer CB514SPN I3-1315U 8/256 TCHCHR

CB514SPN I3-1315U 8/256 TCHCHR

Model CB514SPN I3-1315U 8/256 TCHCHRPart no. NX.KWFEK.001EAN 4711721146774

112 specifications Checked today

Display35.6 cm (14")
Resolution1920 x 1200 pixels
ProcessorIntel® Core™ i3
Memory8 GB
Storage256 GB
GraphicsNot available

See all specifications

Overview

Display: 35.6 cm (14")
Resolution: 1920 x 1200 pixels
Processor: Intel® Core™ i3
Memory: 8 GB
Storage: 256 GB
Graphics: Not available

Brand: Acer
Category: Laptop
Model: CB514SPN I3-1315U 8/256 TCHCHR
Part number: NX.KWFEK.001
EAN / UPC: 4711721146774
Also known as: Acer Aspire Chromebook Plus Spin 514 CPE594-1N-39VE 2 in 1

Specifications

112 specifications in 20 groups

Design

Specification	Value
Product type	Chromebook
Product colour	Grey
Colour name	Other
Form factor	Convertible (Fold-back screen)
Country of origin	China
AI-powered	No

Display

Specification	Value
Display diagonal	35.6 cm (14")
Display resolution	1920 x 1200 pixels
Touchscreen	Yes
HD type	WUXGA
Display technology marketing name	CineCrystal
Panel type	IPS
LED backlight	Yes
Native aspect ratio	16:9
Display glass type	Gorilla Glass
Colour gamut	45%
RGB colour space	NTSC
Maximum refresh rate	60 Hz
Anti-microbial screen	Yes

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Core™ i3
Processor generation	Intel Core i3-13xxx
Processor model	i3-1315U
Processor cores	6
Processor threads	8
Processor boost frequency	4.5 GHz
Processor frequency	1.2 GHz
Processor cache	10 MB
Processor cache type	Smart Cache
Processor operating modes	64-bit
Maximum turbo power	55 W
Processor base power	15 W

Neural processor unit (NPU)

Specification	Value
Copilot+ PC	No

Memory

Specification	Value
Internal memory	8 GB
Internal memory type	LPDDR5x-SDRAM
Memory clock speed	5200 MHz
Maximum internal memory	16 GB

Storage

Specification	Value
Total storage capacity	256 GB
Storage media	SSD
Total SSDs capacity	256 GB
Number of SSDs installed	1
SSD capacity	256 GB
NVMe	Yes
SSD interface	PCI Express 4.0
SSD form factor	M.2
Optical drive type	No

Graphics

Specification	Value
On-board graphics card	Yes
Discrete graphics card	No
Discrete graphics card model	Not available
On-board GPU manufacturer	Intel
On-board graphics card model	Intel® UHD Graphics

Audio

Specification	Value
Built-in speaker(s)	Yes
Number of built-in speakers	2
Built-in microphone	Yes
Number of microphones	2

Camera

Specification	Value
Front camera	Yes
Front camera HD type	Quad HD
Front camera resolution	2560 x 1440 pixels
Video capturing speed	30 fps
Privacy camera	Yes
Privacy type	Privacy shutter

Network

Specification	Value
Wi-Fi	Yes
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
Wi-Fi standards	Wi-Fi 6E (802.11ax), Wi-Fi 6 (802.11ax), Wi-Fi 5 (802.11ac), Wi-Fi 4 (802.11n)
Antenna type	2x2
WLAN controller manufacturer	Intel
WLAN controller model	Intel Wi-Fi 6E AX211
Ethernet LAN	No
Ethernet LAN data rates	1000 Mbit/s
Bluetooth	Yes
Bluetooth version	5.2
MIMO	Yes
MIMO type	Multi User MIMO

Ports & interfaces

Specification	Value
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	2
HDMI ports quantity	1
HDMI version	1.4
Combo headphone/mic port	Yes
Line-in	No
Charging port type	USB Type-C
HDCP	Yes
HDMI	Yes
Line-out	No
USB ports quantity	3

Keyboard

Specification	Value
Pointing device	Touchpad
Keyboard backlit	Yes
Numeric keypad	No
Keyboard language	UK English
Keyboard special features	White Backlight
Touchpad features	OceanGlass Touchpad

Software

Specification	Value
Operating system installed	ChromeOS

Battery

Specification	Value
Battery technology	Lithium-Ion (Li-Ion)
Number of battery cells	3
Battery capacity	53 Wh
Battery life (max)	10 h

Power

Specification	Value
USB Type-C charging port	Yes
USB Type-C required charging power (max)	65 W
USB Type-C required charging power (min)	65 W

Security

Specification	Value
Cable lock slot	Yes
Cable lock slot type	Kensington
Fingerprint reader	Yes
Trusted Platform Module (TPM)	Yes

Sustainability

Specification	Value
Sustainability certificates	ENERGY STAR

Weight & dimensions

Specification	Value
Weight	1.5 kg
Width	319.9 mm
Depth	229.9 mm
Height	20.9 mm

Packaging content

Specification	Value
AC adapter included	No
Keyboard included	Yes

Other features

Specification	Value
Security features	Fingerprint reader with on-chip matching design for ChromeOS Discrete H1 Trusted Platform Module (TPM) solution for Chromebook Kensington lock (Nano-type) Camera shutter
Chipset	Intel®
Manufacturer	Acer, Inc
