Acer Chromebook CB514-1HT-P1BM Intel® Pentium® N4200

35.6 cm (14") Touchscreen Full HD 8 GB LPDDR4-SDRAM 64 GB eMMC Wi-Fi 5 (802.11ac) ChromeOS Silver QWERTZ Ge

Model CB514-1HT-P1BMPart no. NX.H1LEG.001EAN 4713883913348

135 specifications Checked 2 days ago

Display35.6 cm (14")
Resolution1920 x 1080 pixels
ProcessorIntel® Pentium®
Memory8 GB
Storage64 GB
GraphicsNot available

See all specifications

Overview

Display: 35.6 cm (14")
Resolution: 1920 x 1080 pixels
Processor: Intel® Pentium®
Memory: 8 GB
Storage: 64 GB
Graphics: Not available

Brand: Acer
Category: Laptop
Model: CB514-1HT-P1BM
Part number: NX.H1LEG.001
EAN / UPC: 4713883913348
Also known as: Acer Chromebook CB514-1HT-P1BM Intel® Pentium® N4200 35.6 cm (14") Touchscreen Full HD 8 GB LPDDR4-SDRAM 64 GB eMMC Wi-Fi 5 (802.11ac) ChromeOS Silver QWERTZ Ge

Specifications

135 specifications in 19 groups

Design

Specification	Value
Product type	Chromebook
Product colour	Silver
Form factor	Clamshell

Display

Specification	Value
Display diagonal	35.6 cm (14")
Display resolution	1920 x 1080 pixels
Touchscreen	Yes
HD type	Full HD
Touch technology	Multi-touch
Panel type	IPS
LED backlight	Yes
Native aspect ratio	16:9
Display surface	Matt
Dual-screen	No

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Pentium®
Processor model	N4200
Processor cores	4
Processor threads	4
Processor boost frequency	2.5 GHz
Processor frequency	1.1 GHz
Processor cache	2 MB
Processor cache type	L2
Processor socket	BGA 1296
Processor lithography	14 nm
Processor operating modes	64-bit
Processor series	Intel Pentium Processor N4000 Series for Mobile
Processor codename	Apollo Lake
Thermal Design Power (TDP)	6 W
Scenario Design Power (SDP)	4 W
Tjunction	105 °C
Maximum number of PCI Express lanes	6
PCI Express configurations	1x2, 1x2+2x1
PCI Express slots version	2.0
ECC supported by processor	No

Memory

Specification	Value
Internal memory	8 GB
Internal memory type	LPDDR4-SDRAM
Memory form factor	On-board
Memory layout (slots x size)	1 x 8 GB

Storage

Specification	Value
Total storage capacity	64 GB
Storage media	eMMC
Optical drive type	No
Card reader integrated	No

Graphics

Specification	Value
On-board graphics card	Yes
Discrete graphics card	No
Discrete graphics card model	Not available
On-board graphics card family	Intel® HD Graphics
On-board graphics card model	Intel® HD Graphics 505
Maximum on-board graphics card memory	8 GB
Number of execution units	18
On-board graphics card base frequency	200 MHz
On-board graphics card burst frequency	750 MHz
On-board graphics card ID	0x5A84

Audio

Specification	Value
Number of built-in speakers	2
Built-in microphone	Yes

Camera

Specification	Value
Front camera	Yes

Network

Specification	Value
Wi-Fi	Yes
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Ethernet LAN	No
Bluetooth	Yes
Bluetooth version	4.2
MIMO	Yes

Ports & interfaces

Specification	Value
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	2
Headphone outputs	1
Combo headphone/mic port	Yes

Keyboard

Specification	Value
Pointing device	Touchpad
Keyboard backlit	Yes
Numeric keypad	No
Windows keys	Yes
Keyboard layout	QWERTZ
Keyboard language	German

Software

Specification	Value
Operating system installed	ChromeOS

Processor special features

Specification	Value
Intel® Wireless Display (Intel® WiDi)	No
CPU configuration (max)	1
Embedded options available	No
Enhanced Intel SpeedStep Technology	Yes
Execute Disable Bit	Yes
Idle States	Yes
Intel 64	Yes
Intel Clear Video Technology	Yes
Intel Enhanced Halt State	Yes
Intel Identity Protection Technology version	1.00
Intel Rapid Storage Technology	No
Intel Secure Boot	Yes
Intel Secure Boot Technology version	1.00
Intel Secure Key Technology version	1.00
Intel Small Business Advantage (SBA) version	0.00
Intel Smart Connect Technology	No
Intel Smart Connect Technology version	0.00
Intel Smart Response Technology version	0.00
Intel Stable Image Platform Program (SIPP)	No
Intel Stable Image Platform Program (SIPP) version	0.00
Intel Trusted Execution Technology	No
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Intel® Anti-Theft Technology (Intel® AT)	No
Intel® Clear Video HD Technology (Intel® CVT HD)	Yes
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)	Yes
Intel® High Definition Audio (Intel® HD Audio)	Yes
Intel® Hyper Threading Technology (Intel® HT Technology)	No
Intel® Identity Protection Technology (Intel® IPT)	Yes
Intel® InTru™ 3D Technology	No
Intel® Insider™	No
Intel® OS Guard	Yes
Intel® Quick Sync Video Technology	Yes
Intel® Secure Key	Yes
Intel® Small Business Advantage (Intel® SBA)	No
Intel® Smart Response Technology	No
Intel® Turbo Boost Technology	No
Processor ARK ID	95592
Processor package size	24 x 31 mm
Thermal Monitoring Technologies	Yes
UART	Yes
Conflict-Free processor	Yes

Battery

Specification	Value
Battery technology	Lithium-Ion (Li-Ion)
Number of battery cells	3
Battery capacity	3900 mAh
Battery capacity	45 Wh
Battery life (max)	12 h

Power

Specification	Value
AC adapter power	45 W
AC adapter frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
DC-in jack	Yes

Security

Specification	Value
Cable lock slot	Yes
Cable lock slot type	Kensington

Sustainability

Specification	Value
Sustainability certificates	ENERGY STAR

Weight & dimensions

Specification	Value
Weight	1.4 kg
Width	323 mm
Depth	232 mm
Height	16.9 mm

Packaging content

Specification	Value
AC adapter included	Yes
Manual	Yes
