DSR4010 KVM Switch - Digital KVM switch
Model DSR4010 KVM Switch - Digital KVM switchPart no. DSR4010-EU
10 specifications
- Weight3.6 kg
- Maximum resolution1600 x 1280 pixels
- Operating temperature (T-T)0 - 40 °C
Overview
- Weight
- 3.6 kg
- Maximum resolution
- 1600 x 1280 pixels
- Operating temperature (T-T)
- 0 - 40 °C
- Brand
- Vertiv
- Category
- KVM Switch
- Model
- DSR4010 KVM Switch - Digital KVM switch
- Part number
- DSR4010-EU
- Also known as
- Vertiv DSR4010 - Digital KVM switch
Specifications
10 specifications in 4 groups
Performance
| Specification | Value |
|---|---|
| Maximum resolution | 1600 x 1280 pixels |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 70 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 3.6 kg |
Other features
| Specification | Value |
|---|---|
| Data link protocols | Support – Major server platforms and VT100 serial-based devices |
| Power supply type | 100~240V, Auto Sensing, 40W (max) |
| Compatibility | PS/2, Sun, USB and VT-100 serial-based devices |
| Compliance industry standards | EN55022 Class A,EN55024,EN6200-3-2,EN6100-3-3,FCC15 Class A, VCCI Class A, IEC950,EN60950,UL 1950 third edition,CSA C22.2 No.950 |
| Dimensions (WxDxH) | 431.8 x 279.4 x 44.5 mm |
| I/O ports | Supported Hardware: Monitors - VGA, SVGA (XGA, XGA-II with adaptor) Maximum resolution Local Port: 1600 x 1280 @75Hz, Digital Port Maximum: 1280 x 1024 @75Hz Peripherals - PS/2 keyboard, PS/2 mouse, IntelliMouse (PS/2 only), IBM Scrollpoint, Logitech Mouseman+, Logitech Marble Plus, Logitech Marble |
