Cybex SC 885
Model Cybex SC 885Part no. SC885-001EAN 636430082059
34 specifications
- Weight2.5 kg
- ColourBlack
- Number of computers controlled8
- HD type4K Ultra HD
- Rack capacity1U
- Built-in displayNo
Overview
- Weight
- 2.5 kg
- Colour
- Black
- Number of computers controlled
- 8
- HD type
- 4K Ultra HD
- Rack capacity
- 1U
- Built-in display
- No
- Brand
- Vertiv
- Category
- KVM Switch
- Model
- Cybex SC 885
- Part number
- SC885-001
- EAN / UPC
- 636430082059
- Also known as
- Vertiv SC885 Cybex SC800 Series Secure Desktop KVM Switch, 8 Port, DVI-I, CAC
Specifications
34 specifications in 7 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Number of computers controlled | 8 |
| Keyboard port type | USB |
| Mouse port type | USB |
| Video port type | DVI-I |
| DVI-I ports quantity | 9 |
| DisplayPorts quantity | 8 |
| DisplayPort version | 1.2 |
| USB 2.0 Type-B ports quantity | 16 |
| Console ports | 3.5mm headphone, DVI-I, DisplayPort, USB A, USB B |
| USB 2.0 Type-A hub ports quantity | 3 |
| PS/2 ports quantity | 2 |
| Audio connections | Yes |
| Headphone outputs | 8 |
| DC-in jack | Yes |
Performance
| Specification | Value |
|---|---|
| HD type | 4K Ultra HD |
| Maximum resolution | 2560 x 1600 pixels |
| Video bandwidth | 60 Hz |
Design
| Specification | Value |
|---|---|
| Rack capacity | 1U |
| Rack mounting | Yes |
| Product colour | Black |
| LED indicators | Yes |
| Certification | CE, RCM, FCC class B, VCCI, TUV US, TUV Canada |
Display
| Specification | Value |
|---|---|
| Built-in display | No |
Power
| Specification | Value |
|---|---|
| Power source | AC |
| Input voltage | 100 - 240 V |
| Input current | 1.2 A |
| Power consumption (typical) | 45 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 439 mm |
| Depth | 185.4 mm |
| Height | 43 mm |
| Weight | 2.5 kg |
