4 Port USB DisplayPort KVM Switch with Audio - TAA
Model SV431DPUAEAN 5052461656499
57 specifications
- Weight1 kg
- ColourBlack
- Number of computers controlled4
- Maximum digital resolution2560 x 1600 pixels
- Built-in displayNo
- Input voltage100 - 240 V
Overview
- Weight
- 1 kg
- Colour
- Black
- Number of computers controlled
- 4
- Maximum digital resolution
- 2560 x 1600 pixels
- Built-in display
- No
- Input voltage
- 100 - 240 V
- Brand
- StarTech.com
- Category
- KVM Switch
- Model
- SV431DPUA
- Part number
- SV431DPUA
- EAN / UPC
- 5052461656499, 065030837545, 132017609904, 132017927756 +10 more
- Also known as
- StarTech.com 4 Port USB DisplayPort KVM Switch with Audio - TAA
Specifications
57 specifications in 12 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Number of computers controlled | 4 |
| Keyboard port type | USB |
| Mouse port type | USB |
| Video port type | DisplayPort |
| Console USB ports quantity | 4 |
| Console ports | DisplayPort, 3.5mm headphone, 3.5mm mic, USB A |
| USB hub | Yes |
| Audio connections | Yes |
| Headphone outputs | 5 |
| Number of microphone inputs | 5 |
| DC-in jack | Yes |
Performance
| Specification | Value |
|---|---|
| Maximum digital resolution | 2560 x 1600 pixels |
| Maximum resolution | 3840 x 2400 pixels |
| DDC2B support | Yes |
| Hot-Plug support | Yes |
| Plug and Play | Yes |
| Daisy chain | No |
| Number of users | 1 user(s) |
| Audio channels | 7.1 |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Housing material | Steel |
| LED indicators | Yes |
| Push button | Yes |
| Hot keys | Yes |
| Mean time between failures (MTBF) | 136000 h |
| Certification | CE, FCC, UL, TAA, REACH |
Display
| Specification | Value |
|---|---|
| Built-in display | No |
| On Screen Display (OSD) | No |
Power
| Specification | Value |
|---|---|
| Input voltage | 100 - 240 V |
| Input current | 0.8 A |
| Output voltage | 12 V |
| Output current | 1.5 A |
| Compatible power plug types | AU, EU, UK, US |
| External power adapter | Yes |
| Power plug type | Type M |
Sustainability
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 221 mm |
| Depth | 130.6 mm |
| Height | 44 mm |
| Weight | 1 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 412 mm |
| Package depth | 214 mm |
| Package height | 92 mm |
| Package weight | 1.6 kg |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
| Manual | Yes |
| Rubber feet | Yes |
Other features
| Specification | Value |
|---|---|
| Audio support | Yes |
| IP control | No |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85176200 |
| Master (outer) case width | 553 mm |
| Master (outer) case length | 438 mm |
| Master (outer) case height | 257 mm |
| Products per master (outer) case | 6 pc(s) |
