StarTech.com 2 Port DisplayPort KVM Switch - 4K
StarTech.com

2 Port DisplayPort KVM Switch - 4K

60Hz - Single Display - Dual Port UHD DP 1.2 USB KVM Switch with Integrated USB 3.0 Hub & Audio - Dell HP Apple

Model SV231DPU34KEAN 065030880121

55 specifications
  • Weight1.1 kg
  • ColourBlack
  • Number of computers controlled2
  • HD type4K Ultra HD
  • Built-in displayNo
  • Input voltage100 - 240 V
See all specifications

Overview

Weight
1.1 kg
Colour
Black
Number of computers controlled
2
HD type
4K Ultra HD
Built-in display
No
Input voltage
100 - 240 V
Brand
StarTech.com
Category
KVM Switch
Model
SV231DPU34K
Part number
SV231DPU34K
EAN / UPC
065030880121, 650308801214
Also known as
StarTech.com 2 Port DisplayPort KVM Switch - 4K 60Hz - Single Display - Dual Port UHD DP 1.2 USB KVM Switch with Integrated USB 3.0 Hub & Audio - Dell HP Apple

Specifications

55 specifications in 12 groups

Ports & interfaces

Number of computers controlled2
Keyboard port typeUSB
Mouse port typeUSB
Video port typeDisplayPort
DisplayPorts quantity3
DisplayPort version1.2
USB 3.2 Gen 1 (3.1 Gen 1) Type-B ports quantity2
Console USB ports quantity6
Console ports3.5mm headphone, DisplayPort, USB A
USB connector typeUSB Type-A, USB Type-B
Audio connectionsYes
Headphone outputs3
DC-in jackYes

Performance

HD type4K Ultra HD
Maximum resolution3840 x 2160 pixels
HDCPYes
Daisy chainNo
Number of users1 user(s)
Audio channels2.0

Design

Product colourBlack
Housing materialSteel
LED indicatorsYes
Hot keysYes
Mean time between failures (MTBF)60000 h
CertificationCE, FCC, TAA, REACH

Display

Built-in displayNo
On Screen Display (OSD)No

Power

Input voltage100 - 240 V
Input current0.6 A
Output voltage12 V
Output current1.5 A
Compatible power plug typesAU, EU, JP, UK, US
External power adapterYes
Power consumption (typical)18 W
Power plug typeType M

Sustainability

Compliance certificatesRoHS

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-10 - 60 °C
Operating relative humidity (H-H)0 - 80%

Weight & dimensions

Width160 mm
Depth100 mm
Height40 mm
Weight1.1 kg

Packaging data

Package width186 mm
Package depth243 mm
Package height92 mm

Packaging content

AC adapter includedYes
Quick installation guideYes
Rubber feetYes

Other features

IP controlNo

Logistics data

Harmonized System (HS) code85176200
Master (outer) case width403 mm
Master (outer) case length268 mm
Master (outer) case height315 mm
Products per master (outer) case6 pc(s)
