StarTech.com 16 Port 1U Rackmount USB KVM Switch with OSD - TAA

StarTech.com 16 Port 1U Rackmount USB KVM Switch with OSD - TAA

Model SV1631DUSBUEAN 5054484325055

42 specifications
  • Weight3.1 kg
  • ColourBlack
  • Number of computers controlled16
  • Maximum resolution1920 x 1440 pixels
  • Rack capacity1U
  • Built-in displayNo
See all specifications

Overview

Weight
3.1 kg
Colour
Black
Number of computers controlled
16
Maximum resolution
1920 x 1440 pixels
Rack capacity
1U
Built-in display
No
Brand
StarTech.com
Category
KVM Switch
Model
SV1631DUSBU
Part number
SV1631DUSBU
EAN / UPC
5054484325055, 065030837224, 115971584432, 132017610238 +9 more
Also known as
StarTech.com 16 Port 1U Rackmount USB KVM Switch with OSD - TAA

Specifications

42 specifications in 11 groups

Ports & interfaces

Number of computers controlled16
Keyboard port typeUSB
Mouse port typeUSB
Video port typeVGA
Console USB ports quantity2
Console portsUSB A, VGA (D-Sub)
Audio connectionsNo
DC-in jackYes

Performance

Maximum resolution1920 x 1440 pixels
Plug and PlayYes
Daisy chainYes

Design

Rack capacity1U
Rack mountingYes
Product colourBlack
Housing materialSteel
LED indicatorsYes

Display

Built-in displayNo

Power

Input voltage110-240 V
Input current0.8 A
Output voltage12 V
Output current1.5 A
Power plug typeType M

Operational conditions

Operating temperature (T-T)5 - 40 °C
Storage temperature (T-T)-20 - 60 °C
Operating relative humidity (H-H)5 - 80%

Weight & dimensions

Width540 mm
Depth180 mm
Height45 mm
Weight3.1 kg

Packaging data

Package width597 mm
Package depth265 mm
Package height91 mm
Package weight3.53 kg

Packaging content

AC adapter includedYes
ManualYes

Other features

Audio supportNo
IP controlNo

Logistics data

Harmonized System (HS) code85176200
Master (outer) case width613 mm
Master (outer) case length290 mm
Master (outer) case height412 mm
Products per master (outer) case4 pc(s)
