2-Port Dual-Monitor DisplayPort KVM Switch, 4K
60Hz, 2x USB 5Gbps Hub Ports, 2x USB 2.0 HID Ports, Hotkey and Push-Button Switching, TAA Compliant
Model P2DD46A2-KVM-SWITCHEAN 065030899505
53 specifications
- Weight800 g
- ColourBlack
- Number of computers controlled2
- HD type4K Ultra HD
- Rack mountingNo
- Power sourceDC
Overview
- Weight
- 800 g
- Colour
- Black
- Number of computers controlled
- 2
- HD type
- 4K Ultra HD
- Rack mounting
- No
- Power source
- DC
- Brand
- StarTech.com
- Category
- KVM Switch
- Model
- P2DD46A2-KVM-SWITCH
- Part number
- P2DD46A2-KVM-SWITCH
- EAN / UPC
- 065030899505
- Also known as
- StarTech.com 2-Port Dual-Monitor DisplayPort KVM Switch, 4K 60Hz, 2x USB 5Gbps Hub Ports, 2x USB 2.0 HID Ports, Hotkey and Push-Button Switching, TAA Compliant
Specifications
53 specifications in 12 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Number of computers controlled | 2 |
| Keyboard port type | USB |
| Mouse port type | USB |
| Video port type | DisplayPort |
| DisplayPorts quantity | 4 |
| DisplayPort version | 1.2 |
| Console USB ports quantity | 4 |
| Console ports | 3.5mm headphone, 3.5mm mic, DisplayPort, USB A |
| Console DisplayPorts ports quantity | 2 |
| Audio connections | Yes |
| Headphone outputs | 3 |
| Number of microphone inputs | 3 |
| DC-in jack | Yes |
Performance
| Specification | Value |
|---|---|
| HD type | 4K Ultra HD |
| Maximum resolution | 3840 x 2160 pixels |
| Data transfer rate (max) | 5 Gbit/s |
| Scan interval | 10,20,30,40,50,60 s |
| Plug and Play | Yes |
| Daisy chain | No |
Design
| Specification | Value |
|---|---|
| Rack mounting | No |
| Product colour | Black |
| Maximum cable length | 7.5 m |
| LED indicators | Yes |
| Push button | Yes |
| Hot keys | Yes |
| Mean time between failures (MTBF) | 173052 h |
Display
| Specification | Value |
|---|---|
| Built-in display | No |
| On Screen Display (OSD) | No |
Power
| Specification | Value |
|---|---|
| Power source | DC |
| Input voltage | 100 - 240 V |
| Input current | 1 A |
| Output voltage | 12 V |
| Output current | 3 A |
| Compatible power plug types | EU, JP, UK, US |
Sustainability
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
| Sustainability compliance | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 100 mm |
| Depth | 163 mm |
| Height | 66 mm |
| Weight | 800 g |
Packaging data
| Specification | Value |
|---|---|
| Package width | 336 mm |
| Package depth | 168 mm |
| Package height | 139 mm |
| Package weight | 1.3 kg |
Packaging content
| Specification | Value |
|---|---|
| Quick installation guide | Yes |
Other features
| Specification | Value |
|---|---|
| IP control | No |
Logistics data
| Specification | Value |
|---|---|
| Master (outer) case width | 522 mm |
| Master (outer) case length | 364 mm |
| Master (outer) case height | 308 mm |
| Products per master (outer) case | 6 pc(s) |
