StarTech.com 2-Port Dual-Monitor DisplayPort and HDMI KVM Switch, 4K
StarTech.com

2-Port Dual-Monitor DisplayPort and HDMI KVM Switch, 4K

60Hz, 1x HDMI & 1x DP Monitor, 2-Port USB 5Gbps Hub, 2x USB HID Ports, TAA Compliant

Model P2ADDH462-KVM-SWITCHEAN 065030909129

53 specifications
  • Weight750 g
  • ColourBlack
  • Number of computers controlled2
  • HD type4K Ultra HD
  • Rack mountingNo
  • Input voltage100 - 240 V
See all specifications

Overview

Weight
750 g
Colour
Black
Number of computers controlled
2
HD type
4K Ultra HD
Rack mounting
No
Input voltage
100 - 240 V
Brand
StarTech.com
Category
KVM Switch
Model
P2ADDH462-KVM-SWITCH
Part number
P2ADDH462-KVM-SWITCH
EAN / UPC
065030909129
Also known as
StarTech.com 2-Port Dual-Monitor DisplayPort and HDMI KVM Switch, 4K 60Hz, 1x HDMI & 1x DP Monitor, 2-Port USB 5Gbps Hub, 2x USB HID Ports, TAA Compliant

Specifications

53 specifications in 12 groups

Ports & interfaces

Number of computers controlled2
Keyboard port typeUSB
Mouse port typeUSB
Video port typeHDMI/DisplayPort
HDMI ports quantity2
HDMI version2.0
DisplayPorts quantity2
DisplayPort version1.2
USB 3.2 Gen 1 (3.1 Gen 1) Type-B ports quantity2
Console USB ports quantity2
Console ports3.5mm headphone, 3.5mm mic, DisplayPort, HDMI, USB A
Console DisplayPorts ports quantity1
Console HDMI ports quantity1
USB hubYes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A hub ports quantity2
Audio connectionsYes
Headphone outputs3
Number of microphone inputs3
DC-in jackYes

Performance

HD type4K Ultra HD
Maximum resolution3840 x 2160 pixels
Data transfer rate (max)5 Gbit/s
Audio channels7.1

Design

Rack mountingNo
Product colourBlack
LED indicatorsYes
Mean time between failures (MTBF)138390 h

Display

Built-in displayNo

Power

Input voltage100 - 240 V
Input current1 A
Output voltage12 V
Output current3 A
Compatible power plug typesAU, EU, UK, US
Power consumption (typical)36 W
Power plug typeType M

Sustainability

Compliance certificatesRoHS, Trade Agreements Act (TAA)

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-20 - 60 °C
Operating relative humidity (H-H)0 - 90%

Weight & dimensions

Width100 mm
Depth163 mm
Height66 mm
Weight750 g

Packaging data

Package width332 mm
Package depth162 mm
Package height128 mm
Package weight128 g

Packaging content

Quick installation guideYes

Other features

IP controlNo

Logistics data

Master (outer) case width513 mm
Master (outer) case length352 mm
Master (outer) case height301 mm
Products per master (outer) case6 pc(s)
