5 Port Seamless Multiview KVM Switch
Model 32330EAN 4002888323307
45 specifications
- Weight1.3 kg
- ColourBlack
- Keyboard port typeUSB
- Ethernet LAN (RJ-45) ports1
- HD type4K Ultra HD
- Built-in displayNo
Overview
- Weight
- 1.3 kg
- Colour
- Black
- Keyboard port type
- USB
- Ethernet LAN (RJ-45) ports
- 1
- HD type
- 4K Ultra HD
- Built-in display
- No
- Brand
- Lindy
- Category
- KVM Switch
- Model
- 32330
- Part number
- 32330
- EAN / UPC
- 4002888323307
- Also known as
- Lindy 5 Port Seamless Multiview KVM Switch
Specifications
45 specifications in 12 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Keyboard port type | USB |
| Mouse port type | USB |
| Video port type | HDMI |
| HDMI ports quantity | 6 |
| HDMI version | 2.0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| Console USB ports quantity | 2 |
| Console ports | 3.5mm headphone, HDMI, USB A |
| Console HDMI ports quantity | 2 |
| USB connector type | USB Type-A, USB Type-B |
| Audio connections | Yes |
| DC-in jack | Yes |
Network
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 1 |
Performance
| Specification | Value |
|---|---|
| HD type | 4K Ultra HD |
| Maximum resolution | 4096 x 2160 pixels |
| Video bandwidth | 60 Hz |
| Audio channels | 7.1 |
| Audio decoding technologies | DTS-HD |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Housing material | Metal |
| Display switch button | Yes |
| Push button | Yes |
| Certification | California Proposition 65 |
Display
| Specification | Value |
|---|---|
| Built-in display | No |
Power
| Specification | Value |
|---|---|
| Power source | DC |
| Input voltage | 12 V |
| Input current | 2.5 A |
Sustainability
| Specification | Value |
|---|---|
| Compliance certificates | CE, Federal Communications Commission (FCC), REACH, RoHS, UKCA |
| Sustainability compliance | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 10 - 70% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 219 mm |
| Depth | 146 mm |
| Height | 44 mm |
| Weight | 1.3 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 360 mm |
| Package depth | 260 mm |
| Package height | 75 mm |
| Package weight | 1.8 kg |
| Package type | Box |
Packaging content
| Specification | Value |
|---|---|
| Manual | Yes |
| Packaging content | 5 Port HDMI 4K60 Seamless Multiview KVM Switch IR remote control 4-Pin Terminal Block 2x Mounting ears with screws Multi-Country Power Supply (EU, UK, US & AUS) Lindy Manual |
Other features
| Specification | Value |
|---|---|
| Power requirements | 12VDC 2.5A |
| Warranty period | 2 year(s) |
