16-Port PS/2-USB VGA KVM Switch
Model KVM-3216EAN 846359058619
57 specifications
- Weight1.97 kg
- ColourBlack
- Number of computers controlled16
- Maximum resolution2048 x 1536 pixels
- Rack capacity1U
- Built-in displayNo
Overview
- Weight
- 1.97 kg
- Colour
- Black
- Number of computers controlled
- 16
- Maximum resolution
- 2048 x 1536 pixels
- Rack capacity
- 1U
- Built-in display
- No
- Brand
- LevelOne
- Category
- KVM Switch
- Model
- KVM-3216
- Part number
- KVM-3216
- EAN / UPC
- 846359058619, 4015867229392
- Also known as
- LevelOne 16-Port PS/2-USB VGA KVM Switch
Specifications
57 specifications in 13 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Number of computers controlled | 16 |
| Keyboard port type | USB, PS/2 |
| Mouse port type | USB, PS/2 |
| Video port type | VGA |
| VGA (D-Sub) ports quantity | 16 |
| Console USB ports quantity | 2 |
| Console ports | PS/2, VGA (D-Sub), USB A |
| PS/2 ports quantity | 2 |
| DC-in jack | Yes |
Performance
| Specification | Value |
|---|---|
| Maximum resolution | 2048 x 1536 pixels |
| Scan interval | 35,70,10,40,80,15,45,90,20,50,25,55,30,60 s |
| Auto scan delay (min) | 10 s |
| Auto scan delay (max) | 95 s |
Design
| Specification | Value |
|---|---|
| Rack capacity | 1U |
| Rack mounting | Yes |
| Product colour | Black |
| Housing material | Metal |
| Cascadable | Yes |
| LED indicators | Power |
| Push button | Yes |
| Hot keys | Yes |
Display
| Specification | Value |
|---|---|
| Built-in display | No |
| On Screen Display (OSD) | Yes |
Power
| Specification | Value |
|---|---|
| Power source | DC |
| Input voltage | 9 V |
| Input current | 1 A |
| External power adapter | Yes |
System requirements
| Specification | Value |
|---|---|
| Windows operating systems supported | Windows 7 Professional x64, Windows Vista Enterprise x64, Windows 7 Starter, Windows Vista Home Basic, Windows 7 Starter x64, Windows Vista Home Basic x64, Windows 7 Ultimate, Windows 95, Windows Vista Home Premium, Windows 2000, Windows 7 Ultimate x64, Windows 98, Windows Vista Home Premium x64, Wi |
| Linux operating systems supported | Yes |
| Mac operating systems supported | Yes |
Sustainability
| Specification | Value |
|---|---|
| Compliance certificates | Federal Communications Commission (FCC), UKCA, WEEE, CE |
| Sustainability compliance | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -10 - 70 °C |
| Operating relative humidity (H-H) | 0 - 85% |
| Storage relative humidity (H-H) | 0 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 410 mm |
| Depth | 165 mm |
| Height | 44.5 mm |
| Weight | 1.97 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 567 mm |
| Package depth | 245 mm |
| Package height | 106 mm |
| Package weight | 3.01 kg |
| Package type | Box |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
| Manual | Yes |
Logistics data
| Specification | Value |
|---|---|
| Master (outer) cases per pallet (air) | 24 pc(s) |
| Master (outer) case width | 585 mm |
| Master (outer) case length | 270 mm |
| Master (outer) case height | 545 mm |
| Master (outer) case gross weight | 15.7 kg |
| Products per master (outer) case | 5 pc(s) |
| Country of origin | Taiwan |
Technical details
| Specification | Value |
|---|---|
| Pallet gross length | 110 cm |
| Pallet gross width | 120 cm |
| Pallet height (air) | 11.5 cm |
