4 Port KVM Switch with OSD for USB and PS/2
Model KVM-0420EAN 4014619103409
26 specifications
- ColourBlack
- Number of computers controlled4
- Maximum resolution1920 x 1440 pixels
- Rack capacity1U
- On Screen Display (OSD)Yes
- Output voltage12 V
Overview
- Colour
- Black
- Number of computers controlled
- 4
- Maximum resolution
- 1920 x 1440 pixels
- Rack capacity
- 1U
- On Screen Display (OSD)
- Yes
- Output voltage
- 12 V
- Brand
- LevelOne
- Category
- KVM Switch
- Model
- KVM-0420
- Part number
- KVM-0420
- EAN / UPC
- 4014619103409, 4015867105832, 5054629234303, 5711045099960
- Also known as
- LevelOne 4 Port KVM Switch with OSD for USB and PS/2
Specifications
26 specifications in 7 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Number of computers controlled | 4 |
| Keyboard port type | USB, PS/2 |
| Mouse port type | USB, PS/2 |
| Video port type | VGA |
| VGA (D-Sub) ports quantity | 4 |
| Console ports | PS/2, VGA (D-Sub) |
| Audio connections | No |
| DC-in jack | Yes |
Performance
| Specification | Value |
|---|---|
| Maximum resolution | 1920 x 1440 pixels |
| Scan interval | 3,8,15,30 s |
| Maximum operating distance | 30 m |
Design
| Specification | Value |
|---|---|
| Rack capacity | 1U |
| Rack mounting | Yes |
| Product colour | Black |
| Cascadable | Yes |
| LED indicators | Ready |
| Push button | Yes |
| Hot keys | Yes |
| Certification | CE |
Display
| Specification | Value |
|---|---|
| On Screen Display (OSD) | Yes |
Power
| Specification | Value |
|---|---|
| Output voltage | 12 V |
| Output current | 0.5 A |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 404 mm |
| Depth | 40 mm |
| Height | 114 mm |
Logistics data
| Specification | Value |
|---|---|
| Country of origin | Taiwan |
