2-Port True 4K HDMI Splitter
Model VS4812-ATEAN 4711581521612
40 specifications
- Weight30 g
- ColourBlack
- Keyboard port typeNo
- HD type4K Ultra HD
- Power sourceUSB
- Operating temperature (T-T)0 - 40 °C
Overview
- Weight
- 30 g
- Colour
- Black
- Keyboard port type
- No
- HD type
- 4K Ultra HD
- Power source
- USB
- Operating temperature (T-T)
- 0 - 40 °C
- Brand
- ATEN
- Category
- KVM Switch
- Model
- VS4812-AT
- Part number
- VS4812-AT
- EAN / UPC
- 4711581521612
- Also known as
- ATEN 2-Port True 4K HDMI Splitter
Specifications
40 specifications in 9 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Keyboard port type | No |
| Mouse port type | No |
| Video port type | HDMI |
| HDMI ports quantity | 3 |
| USB connector type | USB Type-C |
Performance
| Specification | Value |
|---|---|
| HD type | 4K Ultra HD |
| Maximum resolution | 3840 x 2160 pixels |
| Video bandwidth | 60 Hz |
| Data transfer rate (max) | 18 Gbit/s |
| HDCP | Yes |
| HDCP version | 2.2 |
| Maximum operating distance | 3 m |
Design
| Specification | Value |
|---|---|
| Rack mounting | No |
| Product colour | Black |
| LED indicators | Yes |
Display
| Specification | Value |
|---|---|
| Built-in display | No |
Power
| Specification | Value |
|---|---|
| Power source | USB |
| Input voltage | 5 V |
| Input current | 1 A |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
| Storage relative humidity (H-H) | 0 - 80% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 56.5 mm |
| Depth | 61 mm |
| Height | 15.2 mm |
| Weight | 30 g |
Packaging content
| Specification | Value |
|---|---|
| Cables included | USB Type-A to USB Type-C |
| Packaging content | 1x 2-Port True 4K HDMI Splitter 1x USB power cable (Type-C to Type-A) (1 m) |
| Quick installation guide | Yes |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85437090 |
| Master (outer) case net weight | 1.2 kg |
| Master (outer) case width | 213 mm |
| Master (outer) case length | 320 mm |
| Master (outer) case height | 156 mm |
| Master (outer) case gross weight | 2.37 kg |
| Master (outer) case volume | 0.38 cm³ |
| Products per master (outer) case | 20 pc(s) |
| Country of origin | China |
| Case or master carton dimensions (W x D x H) | 213 x 320 x 156 mm |
