US7220-AT-E KVM switch Grey
Model US7220-AT-E
37 specifications
- Weight780 g
- ColourGrey
- Number of computers controlled2
- Ethernet LANYes
- HD type4K Ultra HD
- Built-in displayNo
Overview
- Weight
- 780 g
- Colour
- Grey
- Number of computers controlled
- 2
- Ethernet LAN
- Yes
- HD type
- 4K Ultra HD
- Built-in display
- No
- Brand
- ATEN
- Category
- KVM Switch
- Model
- US7220-AT-E
- Part number
- US7220-AT-E
- Also known as
- ATEN US7220-AT-E KVM switch Grey
Specifications
37 specifications in 11 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Number of computers controlled | 2 |
| Keyboard port type | USB |
| Mouse port type | USB |
| Video port type | HDMI |
| HDMI ports quantity | 1 |
| Console ports | USB A |
| USB hub | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A hub ports quantity | 3 |
| USB connector type | USB Type-A |
| Audio connections | Yes |
| Headphone outputs | 1 |
| Number of microphone inputs | 1 |
| DC-in jack | Yes |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Cabling technology | 10/100/1000Base-T(X) |
Performance
| Specification | Value |
|---|---|
| HD type | 4K Ultra HD |
| Maximum resolution | 3840 x 2160 pixels |
Design
| Specification | Value |
|---|---|
| Product colour | Grey |
| Housing material | Aluminium |
| Push button | Yes |
Display
| Specification | Value |
|---|---|
| Built-in display | No |
Power
| Specification | Value |
|---|---|
| Output voltage | 12 V |
| Power consumption (typical) | 90 W |
System requirements
| Specification | Value |
|---|---|
| Windows operating systems supported | Yes |
| Mac operating systems supported | Yes |
Sustainability
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 97.5 mm |
| Depth | 57 mm |
| Height | 191.9 mm |
| Weight | 780 g |
Packaging content
| Specification | Value |
|---|---|
| Cables included | Thunderbolt |
| AC adapter included | Yes |
| Manual | Yes |
