1-Local/4-Remote Shared Access 32-Port Multi-Interface Cat 5 KVM over IP Switch
Model RCM432VA-AX-GEAN 4710469346576
37 specifications
- Weight5.22 kg
- ColourBlack
- Number of computers controlled4
- Ethernet LANYes
- HD typeWUXGA
- Rack capacity1U
Overview
- Weight
- 5.22 kg
- Colour
- Black
- Number of computers controlled
- 4
- Ethernet LAN
- Yes
- HD type
- WUXGA
- Rack capacity
- 1U
- Brand
- ATEN
- Category
- KVM Switch
- Model
- RCM432VA-AX-G
- Part number
- RCM432VA-AX-G
- EAN / UPC
- 4710469346576
- Also known as
- ATEN 1-Local/4-Remote Shared Access 32-Port Multi-Interface Cat 5 KVM over IP Switch
Specifications
37 specifications in 10 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Number of computers controlled | 4 |
| Keyboard port type | USB, PS/2 |
| Mouse port type | USB, PS/2 |
| Console USB ports quantity | 2 |
| Console ports | HDMI, VGA (D-Sub), USB A |
| Console HDMI ports quantity | 1 |
| Console RJ-45 ports quantity | 2 |
| USB connector type | USB Type-A, USB Type-B |
| AC-in ports quantity | 1 |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 2 |
| Cabling technology | 10/100/1000Base-T(X) |
Performance
| Specification | Value |
|---|---|
| HD type | WUXGA |
| Maximum resolution | 1920 x 1200 pixels |
| Video bandwidth | 60 Hz |
Design
| Specification | Value |
|---|---|
| Rack capacity | 1U |
| Rack mounting | Yes |
| Product colour | Black |
| Housing material | Metal |
| LED indicators | Yes |
| Push button | Yes |
Display
| Specification | Value |
|---|---|
| Built-in display | No |
Power
| Specification | Value |
|---|---|
| Power source | AC |
| Input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Input current | 1 A |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
| Storage relative humidity (H-H) | 0 - 80% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 412.1 mm |
| Depth | 433.6 mm |
| Height | 44 mm |
| Weight | 5.22 kg |
Packaging content
| Specification | Value |
|---|---|
| Quick installation guide | Yes |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85235190 |
| Country of origin | Taiwan |
