ATEN KN4124VA KVM switch Rack mounting Black, Grey

ATEN KN4124VA KVM switch Rack mounting Black, Grey

Model KN4124VAEAN 672792403699

53 specifications
  • Weight5.51 kg
  • ColourBlack, Grey
  • Number of computers controlled24
  • Ethernet LANYes
  • HD typeFull HD
  • Rack capacity1U
See all specifications

Overview

Weight
5.51 kg
Colour
Black, Grey
Number of computers controlled
24
Ethernet LAN
Yes
HD type
Full HD
Rack capacity
1U
Brand
ATEN
Category
KVM Switch
Model
KN4124VA
Part number
KN4124VA
EAN / UPC
672792403699
Also known as
ATEN KN4124VA KVM switch Rack mounting Black, Grey

Specifications

53 specifications in 11 groups

Ports & interfaces

Number of computers controlled24
Keyboard port typeUSB, PS/2
Mouse port typeUSB, PS/2
Video port typeDVI-I
DVI-I ports quantity1
Console USB ports quantity3
Console portsDVI-I, USB A
USB 2.0 ports quantity3
USB connector typeUSB Type-A
USB version2.0
Audio connectionsYes
DC-in jackNo

Network

Ethernet LANYes
Ethernet LAN (RJ-45) ports2
Cabling technology10/100/1000Base-T(X)
Networking standardsIEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Security algorithms3DES, 128-bit RC4, 256-bit AES, DES, FIPS 140-2, RSA, SSL/TLS

Performance

HD typeFull HD
Maximum digital resolution1920 x 1200 pixels
Maximum resolution1920 x 1200 pixels
Data transfer rate (max)1000 Gbit/s
Scan interval1,255 s
Number of users64 user(s)
Firmware upgradeableYes

Design

Rack capacity1U
Rack mountingYes
Product colourBlack, Grey
Housing materialMetal
Wired remote switchYes
CascadableYes
LED indicatorsYes
Push buttonYes

Display

Built-in displayNo

Power

Power sourceAC
Input voltage100 - 240 V
AC input frequency50 / 60 Hz
Input current1 A
External power adapterNo
USB poweredNo

System requirements

Windows operating systems supportedYes
Linux operating systems supportedYes
Mac operating systems supportedYes

Sustainability

Compliance certificatesRoHS

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-20 - 60 °C
Operating relative humidity (H-H)0 - 80%

Weight & dimensions

Width433.6 mm
Depth412.1 mm
Height44 mm
Weight5.51 kg

Packaging content

Cables includedAC
ManualYes
Rack mount kitYes
