16 Port KVM over IP switch, 2 IP users 1 Local User
Model KN2116VBEAN 672792014024
53 specifications
- ConnectivityWired
- Weight5.18 kg
- ColourBlack
- Number of computers controlled16
- Ethernet LANYes
- HD typeFull HD
Overview
- Connectivity
- Wired
- Weight
- 5.18 kg
- Colour
- Black
- Number of computers controlled
- 16
- Ethernet LAN
- Yes
- HD type
- Full HD
- Brand
- ATEN
- Category
- KVM Switch
- Model
- KN2116VB
- Part number
- KN2116VB
- EAN / UPC
- 672792014024
- Also known as
- ATEN 16 Port KVM over IP switch, 2 IP users 1 Local User
Specifications
53 specifications in 12 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Number of computers controlled | 16 |
| Keyboard port type | USB |
| Mouse port type | USB |
| Display connection | Yes |
| Console USB ports quantity | 2 |
| Console ports | HDMI, VGA (D-Sub) |
| Console HDMI ports quantity | 1 |
| Console RJ-45 ports quantity | 16 |
| USB 2.0 Type-A hub ports quantity | 3 |
| USB connector type | USB Type-A |
| Serial port type | RJ-45 |
| Serial ports quantity | 1 |
| Audio connections | Yes |
| Headphone outputs | 1 |
| AC-in ports quantity | 2 |
| DC-in jack | No |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 2 |
| Cabling technology | 10/100/1000Base-T(X) |
Performance
| Specification | Value |
|---|---|
| HD type | Full HD |
| Maximum resolution | 1920 x 1200 pixels |
| Number of users | 3 user(s) |
| Audio channels | 2.0 |
Design
| Specification | Value |
|---|---|
| Rack capacity | 1U |
| Rack mounting | Yes |
| Product colour | Black |
| Housing material | Metal |
| Cascadable | Yes |
| LED indicators | Operation, Power, WAN |
| Display switch button | Yes |
| Push button | No |
| Hot keys | Yes |
Display
| Specification | Value |
|---|---|
| Built-in display | No |
Power
| Specification | Value |
|---|---|
| Power source | AC |
| Input voltage | 100 - 240 V |
| External power adapter | Yes |
| Power plug type | Type G |
Certificates
| Specification | Value |
|---|---|
| Waste Electrical and Electronic Equipment (WEEE) compliance | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 433.6 mm |
| Depth | 412.1 mm |
| Height | 440 mm |
| Weight | 5.18 kg |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
| Quick installation guide | Yes |
| Rack mount kit | Yes |
| Rubber feet | Yes |
Other features
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| IP control | Yes |
| Warranty period | 3 year(s) |
Logistics data
| Specification | Value |
|---|---|
| Country of origin | Taiwan |
