ATEN KN1132V KVM switch Rack mounting Black, Grey

ATEN KN1132V KVM switch Rack mounting Black, Grey

Model KN1132VEAN 672792007354

46 specifications
  • Weight5.54 kg
  • ColourBlack, Grey
  • Number of computers controlled32
  • Ethernet LANYes
  • HD typeFull HD
  • Rack capacity1U
See all specifications

Overview

Weight
5.54 kg
Colour
Black, Grey
Number of computers controlled
32
Ethernet LAN
Yes
HD type
Full HD
Rack capacity
1U
Brand
ATEN
Category
KVM Switch
Model
KN1132V
Part number
KN1132V
EAN / UPC
672792007354
Also known as
ATEN KN1132V KVM switch Rack mounting Black, Grey

Specifications

46 specifications in 11 groups

Ports & interfaces

Number of computers controlled32
Keyboard port typeUSB
Mouse port typeUSB
Video port typeDVI-D/VGA
DVI-D ports quantity1
VGA (D-Sub) ports quantity1
Console USB ports quantity2
Console portsDVI-D, RJ–45, USB A, VGA (D-Sub)
USB connector typeMini-USB, USB Type-A
Audio connectionsYes

Network

Ethernet LANYes
Ethernet LAN (RJ-45) ports2
Cabling technology10/100/1000Base-T(X)

Performance

HD typeFull HD
Maximum digital resolution1920 x 1200 pixels
Maximum resolution1920 x 1200 pixels
Scan interval1,255 s
Firmware upgradeableYes

Design

Rack capacity1U
Rack mountingYes
Product colourBlack, Grey
Housing materialMetal
CascadableYes
LED indicatorsYes
Push buttonYes
Hot keysYes

Display

Built-in displayNo

Power

Power sourceAC
Input voltage100 - 240 V
AC input frequency50 - 60 Hz
Input current1 A
Power consumption (typical)26.5 W

System requirements

Windows operating systems supportedYes
Linux operating systems supportedYes
Mac operating systems supportedYes

Sustainability

Compliance certificatesRoHS

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-20 - 60 °C
Operating relative humidity (H-H)0 - 80%

Weight & dimensions

Width433.6 mm
Depth412.1 mm
Height44 mm
Weight5.54 kg

Packaging content

Cables includedAC
ManualYes
Rack mount kitYes
