KL1516Ai KVM switch Rack mounting Black
Model KL1516AiPart no. KL1516AIMEAN 5055309627880
31 specifications
- Display48.3 cm (19")
- ConnectivityWired
- Weight16.2 kg
- ColourBlack
- Number of computers controlled16
- Ethernet LANYes
Overview
- Display
- 48.3 cm (19")
- Connectivity
- Wired
- Weight
- 16.2 kg
- Colour
- Black
- Number of computers controlled
- 16
- Ethernet LAN
- Yes
- Brand
- ATEN
- Category
- KVM Switch
- Model
- KL1516Ai
- Part numbers
- KL1516AIM, KL1516AIN
- EAN / UPC
- 5055309627880, 672792401114, 4710423777859, 672792401091 +1 more
- Also known as
- ATEN KL1516Ai KVM switch Rack mounting Black
Specifications
31 specifications in 10 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Number of computers controlled | 16 |
| Keyboard port type | USB, PS/2 |
| Mouse port type | USB, PS/2 |
| Video port type | VGA |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 16 |
| Cabling technology | 10/100Base-T(X) |
| Networking standards | IEEE 802.3, IEEE 802.3u |
Performance
| Specification | Value |
|---|---|
| Maximum resolution | 1600 x 1200 pixels |
Design
| Specification | Value |
|---|---|
| Rack capacity | 1U |
| Rack mounting | Yes |
| Product colour | Black |
| Housing material | Metal |
| LED indicators | Yes |
Display
| Specification | Value |
|---|---|
| Built-in display | Yes |
| Display | LCD |
| Display diagonal | 48.3 cm (19") |
Power
| Specification | Value |
|---|---|
| Input voltage | 120-230 V |
| AC input frequency | 50 - 60 Hz |
| Power consumption (typical) | 36 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
| Storage relative humidity (H-H) | 0 - 80% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 480 mm |
| Depth | 701.2 mm |
| Height | 44 mm |
| Weight | 16.2 kg |
Packaging content
| Specification | Value |
|---|---|
| Manual | Yes |
Other features
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| I/O ports | 1 x DB-25 1 x RJ-11 |
